EXPLODED-VIEW ASSEMBLY DRAWING

PART NO.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
PART LIST
DESCRIPTION
Main Frame
Handle Bar
Cushion Tube
Connect Tube
Back Cushion
Arm Cushion
Knob
Handgrip
M8x55 Hex Bolt
M8x20 Bolt
M8 Washer
M8 Nylon Nut
M8 Expansion bolt
-2-
QTY
2
2
1
1
1
2
2
4
12
2
20
8
8
