EXPLODED-VIEW ASSEMBLY DRAWING
PARTS LIST
NO.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
PART LIST
DESCRIPTION
Main Frame
Handle Bar
Support Tube
Hold Plate
M10x95 Hex Bolt
M10 Washer
M10 Nylon Nut
D Lock
Rotating Bolt
M8*90 Bolt
M8 Washer
Nylon Pipe
-7-
QTY
1
1
1
1
2
4
2
1
1
6
6
6
