aerauliqa QCmev Instructions For Installation, Use And Maintenance Manual page 15

5.6 Additional electric wirings
The installation and service of the unit and complete ventilation system must be performed
by an authorized installer and in accordance with local rules and regulations.
The unit must be earthed.
Fig. 5.k Single speed operation
Fig. 5.m Variable speed operation with CTRL-M remote manual controller
Make sure that the mains supply to the unit is disconnected before
performing any installation, service, maintenance or electrical work!
+
U
-
Fig. 5.o Three-speed operation with SEL-3V speed selector
WARNING
Fig. 5.l Two speed operation with remote two-position switch/sensor
Fig. 5.n Variable speed operation through external domotic (BMS) system or
ballast potentiometer
INTERRUTTORE 3
THREE POSITION
POSIZIONI
SWITCH
THREE POSITION SWITCH
INTERRUTTORE
3 STUFEN SCHALTER
3 POSIZIONI
INTERRUPTEUR À 3
POSITIONS
DEVIATORE O SENSORE
TWO POSITION
ESTERNO
SWITCH OR
TWO POSITION SWITCH OR
REMOTE SENSOR
REMOTE SENSOR
DEVIATORE O
WECHSELSCHALTER
SENSORE ESTERNO
INVERSEUR OU CAPTEUR
EXTERNE
1-10V
BALLAST
+
-
15
