Figure 5. The front left rail attaching to the rack
5. Insert the right rear of the rail. You can adjust the length of the rail by sliding
6. Secure the right rear of the rail. Repeat step 3 on page 14 to secure the right
7. Insert the right front of the rail. Repeat step 4 on page 14 to insert the right
Securing the appliance in the rack
1. Slide the appliance into the rack. From the front of the rack, slide the appliance
b
the rear mounting mechanism back and forth to align it to your rack. When
you release the locking mechanism, the whole mounting mechanism then slides
on the rail. Repeat step 2 on page 13 to insert the right rear of the rail.
rear of the rail to the rack.
front of the rail.
onto the mounting rails. Do not slide until it locks into place.
Chapter 3. Installing the appliance in a rack
15
