Summary of Contents for AGFA DX-D 600

  • Page 1 DX-D 600 5430/110 5430/120 User Manual 0240H EN 20181119 0940...

  • Page 2: Table Of Contents

    | DX-D 600 | Contents Contents Legal Notice ................5 Introduction to this Manual ........... 6 Scope .................7 About the safety notices in this document ....8 Disclaimer ..............9 Introduction to the DX-D 600 ..........10 Intended Use of the DX-D 600 ........
  • Page 3 DX-D 600 | Contents | iii Cleaning and Disinfecting ........45 Cleaning ............46 Disinfecting ..........47 Approved disinfectants ........ 48 Patient data security ..........49 Maintenance ............50 Environmental protection ........51 Safety Directions ............52 Emergency stop button for automatic movements ................55...
  • Page 4 | DX-D 600 | Contents Remarks for HF-emission and immunity ......95 Immunity to RF wireless communication equipment ..Record of X-ray exposure parameters ......... 100 0240H EN 20181119 0940...

  • Page 5: Legal Notice

    Agfa and the Agfa rhombus are trademarks of Agfa-Gevaert N.V., Belgium or its affiliates. NX and DX-D 600 are trademarks of Agfa NV, Belgium or one of its affiliates. All other trademarks are held by their respective owners and are used in an editorial fashion with no intention of infringement.

  • Page 6: Introduction To This Manual

    6 | DX-D 600 | Introduction to this Manual Introduction to this Manual Topics: • Scope • About the safety notices in this document • Disclaimer 0240H EN 20181119 0940...

  • Page 7: Scope

    DX-D 600 | Introduction to this Manual | 7 Scope This User Manual describes the features of the DX-D 600 System, an integrated X-Ray imaging system. It explains how the different components of the DX-D 600 System work together. 0240H EN 20181119 0940...

  • Page 8: About The Safety Notices In This Document

    8 | DX-D 600 | Introduction to this Manual About the safety notices in this document The following samples show how warnings, cautions, instructions and notes appear in this document. The text explains their intended use. DANGER: A danger safety notice indicates a hazardous situation of direct, immediate danger for a potential serious injury to a user, engineer, patient or any other person.

  • Page 9: Disclaimer

    DX-D 600 | Introduction to this Manual | 9 Disclaimer Agfa assumes no liability for use of this document if any unauthorized changes to the content or format have been made. Every care has been taken to ensure the accuracy of the information in this document.

  • Page 10: Introduction To The Dx-D 600

    10 | DX-D 600 | Introduction to the DX-D 600 Introduction to the DX-D 600 Topics: • Intended Use of the DX-D 600 • Intended User • Configuration • Operation Controls • System Documentation • Options and Accessories • Product Complaints •...

  • Page 11: Intended Use Of The Dx-D 600

    DX-D 600 | Introduction to the DX-D 600 | 11 Intended Use of the DX-D 600 • The DX-D 600 system is a ceiling mounted General Radiography X-Ray imaging system used in hospitals, clinics and medical practices by physicists, radiographers and radiologists to make, process and view static...

  • Page 12: Intended User

    12 | DX-D 600 | Introduction to the DX-D 600 Intended User This manual has been written for trained users of Agfa products and trained diagnostic X–Ray clinical personnel who have received proper training. Users are those persons who actually handle the equipment and those who have authority over the equipment.

  • Page 13: Configuration

    • semi-automatic configuration, supporting auto-tracking functionality (type 5430/110) DX-D 600 supports the Full Leg Full Spine application on the RAD Wall Stand or the RAD Table using the integrated 4343R DR Detector or a portable DR Detector in the DR Detector bucky.
  • Page 14 14 | DX-D 600 | Introduction to the DX-D 600 Figure 1: DX-D 600 configuration 1. NX workstation 2. X-ray generator control box 3. Automatic positioning control box 4. Ceiling suspension 5. RAD Table 6. RAD Wall Stand 7. Automatic collimator 8.

  • Page 15: Operation Controls

    DX-D 600 | Introduction to the DX-D 600 | 15 Operation Controls The main operation controls of the DX-D 600: Topics: • NX Application on the NX Workstation • Software Console on the NX Workstation • DR Detector Switch on the NX Workstation •...

  • Page 16: Nx Application On The Nx Workstation

    16 | DX-D 600 | Introduction to the DX-D 600 NX Application on the NX Workstation The NX application is used to define patient information, select exposures and process images. Figure 2: NX application The operation of the NX application is described in the NX User Manual, document 4420..

  • Page 17: Software Console On The Nx Workstation

    DX-D 600 | Introduction to the DX-D 600 | 17 Software Console on the NX Workstation The Software Console is used to control X-Ray generator settings and X-Ray system position. The software console has two screens: 0240H EN 20181119 0940...
  • Page 18 18 | DX-D 600 | Introduction to the DX-D 600 Figure 3: X-Ray generator controls Figure 4: X-Ray system automatic po- sitioning controls 0240H EN 20181119 0940...

  • Page 19: Dr Detector Switch On The Nx Workstation

    DX-D 600 | Introduction to the DX-D 600 | 19 DR Detector Switch on the NX Workstation The DR Detector Switch is available in the title bar of the NX application. The DR Detector Switch shows which DR Detector is active and shows its status.
  • Page 20 20 | DX-D 600 | Introduction to the DX-D 600 Meaning DR Detec- DR Detector is DR Detector is DR Detector is tor is ready initializing for off or discon- inactive (no for expo- exposure nected or in thumbnail se-...

  • Page 21: X-Ray Generator Control In The Operator Room

    DX-D 600 | Introduction to the DX-D 600 | 21 X-Ray generator control in the operator room The X-Ray generator control box contains buttons to switch on and off the X- Ray generator and a handswitch to make exposures. Figure 5: the X-Ray generator control box...

  • Page 22: Automatic Positioning Control Box In The Operator Room

    22 | DX-D 600 | Introduction to the DX-D 600 Automatic positioning control box in the operator room The automatic positioning control box contains buttons to move the X-Ray system to the default position for the selected exposure or to the parking position.

  • Page 23: Control Panel Of The Ceiling Suspension

    DX-D 600 | Introduction to the DX-D 600 | 23 Control panel of the ceiling suspension The control panel contains control buttons to control the position of the tube- collimator assembly. Figure 7: Control Panel 0240H EN 20181119 0940...

  • Page 24: Control Panel Touch Screen Console

    24 | DX-D 600 | Introduction to the DX-D 600 Control panel touch screen console The control panel touch screen console: Figure 8: Layout of the control panel touch screen console 1. Patient information 2. Collimator 3. Data area 4. Movements & workstations 5.
  • Page 25 DX-D 600 | Introduction to the DX-D 600 | 25 X-Ray system information on the 'In- X-Ray system automatic positioning fo' screen controls or 'Programmed Positions' on the 'PP' screen 0240H EN 20181119 0940...

  • Page 26: Control Panel Of The Collimator

    26 | DX-D 600 | Introduction to the DX-D 600 Control panel of the collimator The control panel of the automatic collimator: Figure 9: the control panel of the automatic collimator The display shows the dimensions of the collimated area and of the source image distance (SID) in centimeters or in inches.

  • Page 27: Rad Table Controls

    DX-D 600 | Introduction to the DX-D 600 | 27 RAD Table controls • the RAD Table pedals to control the table position (1). • the RAD Table bucky handle to control the bucky position (2). • the emergency OFF switch and table-top lock switch (3).

  • Page 28: Rad Wall Stand Controls

    28 | DX-D 600 | Introduction to the DX-D 600 RAD Wall Stand controls • the RAD Wall Stand bucky handle. Figure 11: the RAD Wall Stand CR bucky handle The button to release the brake is in the handle.
  • Page 29 DX-D 600 | Introduction to the DX-D 600 | 29 Figure 13: the RAD Wall Stand tilting controls • the RAD Wall Stand DR Detector bucky. 0240H EN 20181119 0940...

  • Page 30: X-Ray System Remote Control

    30 | DX-D 600 | Introduction to the DX-D 600 X-ray system remote control The remote control to control the X-ray system. Figure 14: X-ray system remote control For detailed information about the remote control, refer to the DXD 600 X-Ray System User Manual (document 0242).

  • Page 31: Portable Dr Detector

    DX-D 600 | Introduction to the DX-D 600 | 31 Portable DR Detector When performing an exposure, keep in mind the following detector orientation aids: 1. Tube side 2. Patient orientation marker For an overview of the operation controls of the DR Detector, refer to the user manual of the DR Detector.

  • Page 32: System Documentation

    32 | DX-D 600 | Introduction to the DX-D 600 System Documentation The documentation shall be kept with the system for easy reference. The most extensive configuration is described within this manual, including the maximum number of options and accessories. Not every function, option or accessory described may have been purchased or licensed on a particular piece of equipment.

  • Page 33: The Dx-D 600 User Documentation

    DX-D 600 | Introduction to the DX-D 600 | 33 The DX-D 600 User Documentation • DX-D 600 User Manual (this document), document 0240. • DX-D 600 X-Ray System User Manual, document 0242. • DX-D Software Console User Manual, document 0189.

  • Page 34: Options And Accessories

    Anti-scatter grids are used to reduce scattered radiation and improve image quality. Grids are available as an option. Refer to the Agfa website for specifications on the anti-scatter grids that have been found compatible with the system and the DR Detectors.

  • Page 35: Product Complaints

    If the device malfunctions and may have caused or contributed to a serious injury, Agfa must be notified immediately by telephone, fax or written correspondence to the following address: Agfa Service Support - local support addresses and phone numbers are listed on www.agfa.com Agfa - Septestraat 27, 2640 Mortsel, Belgium...

  • Page 36: Compliance

    36 | DX-D 600 | Introduction to the DX-D 600 Compliance Topics: • General • Safety • Electromagnetic Compatibility • X-Ray Safety • Classification 0240H EN 20181119 0940...

  • Page 37: General

    DX-D 600 | Introduction to the DX-D 600 | 37 General • The product has been designed in accordance with the MEDDEV Guidelines relating to the application of Medical Devices and have been tested as part of the conformity assessment procedures required by 93/42/EEC Medical Device Directive (European Council Directive 93/42/EEC on Medical Devices).

  • Page 38: Classification

    38 | DX-D 600 | Introduction to the DX-D 600 Classification Type of protection against electric Class 1 Equipment shock Degree of protection against electric Type B Applied Parts shock Degree of protection against ingress IPX0 as defined in IEC60529. Ordi-...

  • Page 39: Connectivity

    DX-D 600 communicates with other devices in the hospital network using one of the following protocols: • DICOM • IHE DX-D 600 can be connected to a RIS system (input scheduling), a PACS system (output image/data management) and to a hardcopy device (output image). 0240H EN 20181119 0940...

  • Page 40: Installation

    40 | DX-D 600 | Introduction to the DX-D 600 Installation On a configuration with multiple DR Detectors of the same type, it is required to apply labeling to the DR Detector containing a unique nickname for each DR Detector. The nicknames must be configured on the NX Workstation. The DR Detector Switch shows which DR Detector is active and shows its status, by means of the nickname of the DR Detector.

  • Page 41: Labels

    DX-D 600 | Introduction to the DX-D 600 | 41 Labels Label Meaning This mark shows compliance of the equipment with Directive 93/42/EEC (for European Union). This mark indicates that this is a Type B Equipment Serial number Manufacturer Date of manufacture...

  • Page 42: Type Label

    42 | DX-D 600 | Introduction to the DX-D 600 Type label Mark Meaning The type label is located at the back of the telescopic column of the ceiling suspension. The type label information for each combi- nation of X-ray tube and X-ray generator is available in the technical data.

  • Page 43: Labeling Of The Dr Generator Sync Box

    DX-D 600 | Introduction to the DX-D 600 | 43 Labeling of the DR Generator Sync Box The type label is located on the DR Gener- ator Sync Box Figure 15: Example of type label Functional earth Medical equipotential 0240H EN 20181119 0940...

  • Page 44: Messages

    44 | DX-D 600 | Introduction to the DX-D 600 Messages Messages are displayed on the NX workstation monitor, on the touch screen console in the operator room or on the control panel. Special messages are displayed in a dialog box in the middle of the screen or in a fixed part of the screen.

  • Page 45: Cleaning And Disinfecting

    DX-D 600 | Introduction to the DX-D 600 | 45 Cleaning and Disinfecting All appropriate policies and procedures should be followed to avoid contamination of the staff, patients and equipment. All existing universal precautions should be extended to avoid potential contaminations and to avoid patients coming into (close) contact with the device.

  • Page 46: Cleaning

    46 | DX-D 600 | Introduction to the DX-D 600 Cleaning To clean the exterior of the equipment: 1. Stop the system WARNING: When the equipment is going to be cleaned, be sure to turn OFF the power of each device, and to unplug the power cord from the AC outlet.

  • Page 47: Disinfecting

    Disinfecting To disinfect the device, use only disinfectants and disinfection methods that are approved by Agfa and that correspond to the national regulation and guidelines as well as explosion protection. If you plan to use other disinfectants, approval of Agfa is needed before use, as most disinfectants can damage the device.

  • Page 48: Approved Disinfectants

    48 | DX-D 600 | Introduction to the DX-D 600 Approved disinfectants Refer to the Agfa website for specifications on the disinfectants that have been found compatible with the cover material of the device and can be used on the outer surface of the device.

  • Page 49: Patient Data Security

    DX-D 600 | Introduction to the DX-D 600 | 49 Patient data security The user must ensure that the patients’ legal requirements are met and that the security of the patient data is guarded. The user must define who can access patient data in which situations.

  • Page 50: Maintenance

    50 | DX-D 600 | Introduction to the DX-D 600 Maintenance Maintenance procedures are described in the DX-D 600 Owner’s Manual. 0240H EN 20181119 0940...

  • Page 51: Environmental Protection

    DX-D 600 | Introduction to the DX-D 600 | 51 Environmental protection Figure 16: WEEE symbol Figure 17: Battery symbol WEEE end user notice The directive on Waste Electrical and Electronic Equipment (WEEE) aims to prevent the generation of electric and electronic waste and to promote the reuse, recycling and other forms of recovery.

  • Page 52: Safety Directions

    52 | DX-D 600 | Introduction to the DX-D 600 Safety Directions WARNING: Ionizing radiation can lead to radiation injuries if handled incorrectly. When radiation is applied, the required protective measures must be complied with. WARNING: Safety is only guaranteed when an Agfa certified field service engineer has installed the product.
  • Page 53 DX-D 600 | Introduction to the DX-D 600 | 53 WARNING: There is a risk of collision or crushing for patients, operating staff, unit and objects, caused by unit movements which could be released by inadmissible actuation of operating elements by patients.
  • Page 54 54 | DX-D 600 | Introduction to the DX-D 600 CAUTION: Damaged grid. Reduced image quality. Please handle the grids with special care. CAUTION: When inserting the scattered radiation grids, it is essential that the grid corresponds to the intended source-image-distance (SID) to which the grid is focussed.

  • Page 55: Emergency Stop Button For Automatic Movements

    DX-D 600 | Introduction to the DX-D 600 | 55 Emergency stop button for automatic movements Figure 18: Emergency stop button If a system malfunction causes an emergency situation involving the patient, operating personnel or any system component, activate the emergency stop on the RAD Table, on the ceiling suspension or on the automatic positioning control box.

  • Page 56: Power Off Behaviour

    56 | DX-D 600 | Introduction to the DX-D 600 Power off behaviour After the system is stopped or if the emergency button is activated, this is the behaviour of the system: The brakes for the longitudinal and transversal axis of the ceiling suspension and the brakes for longitudinal and transversal movement of the tabletop are released.

  • Page 57: Emergency Shutdown Power Switch

    DX-D 600 | Introduction to the DX-D 600 | 57 Emergency shutdown power switch Use the emergency shutdown power switch, if a dangerous situation cannot be eliminated by pressing the emergency stop button. WARNING: Use the emergency shutdown power switch in case of danger to patients, operators, third parties, or one of the units.

  • Page 58: Getting Started With Dx-D 600

    58 | DX-D 600 | Getting Started with DX-D 600 Getting Started with DX-D 600 Topics: • Starting DX-D 600 • Basic workflow using the DR Detector • Workflow for Full Leg Full Spine examination • Basic workflow using a CR cassette •...

  • Page 59: Starting Dx-D 600

    Starting DX-D 600 To start DX-D 600: Note: Allow the DR Detector to warm up before the DX-D 600 is used for clinical purposes. The warming-up time starts as soon as the DR Detector has been powered on and the NX workstation is running.

  • Page 60: Basic Workflow Using The Dr Detector

    60 | DX-D 600 | Getting Started with DX-D 600 Basic workflow using the DR Detector Topics: • Step 1: retrieve the patient info • Step 2: Select the exposure • Step 3: Prepare the exposure • Step 4: Check the exposure settings •...

  • Page 61: Step 1: Retrieve The Patient Info

    DX-D 600 | Getting Started with DX-D 600 | 61 Step 1: retrieve the patient info At the NX workstation: 1. When a new patient comes in, define the patient info for the exam. 2. Start the exam. 0240H EN 20181119 0940...

  • Page 62: Step 2: Select The Exposure

    62 | DX-D 600 | Getting Started with DX-D 600 Step 2: Select the exposure In the operator room at the NX workstation: 1. Select the thumbnail for the exposure in the Image Overview pane of the Examination window. RAD Table DR with integrated DR Detector...
  • Page 63 DX-D 600 | Getting Started with DX-D 600 | 63 2. To position the X-Ray system automatically, press and hold the AUTOCENTER button on the automatic positioning control box. The X-Ray system moves to the default position for the selected exposure.

  • Page 64: Step 3: Prepare The Exposure

    64 | DX-D 600 | Getting Started with DX-D 600 Step 3: Prepare the exposure 1. In the examination room, position the X-Ray system: To position the X-Ray system manually, use the control buttons on the control panel. 2. Position the DR Detector either in the DR bucky or on the RAD Table. The DR Detector Switch shows which DR Detector is active and shows its status.

  • Page 65: Step 4: Check The Exposure Settings

    DX-D 600 | Getting Started with DX-D 600 | 65 Step 4: Check the exposure settings Related Links DR Detector Switch on the NX Workstation on page 19 On the NX application: 1. Check if the DR Detector Switch displays the name of the DR Detector that's being used 2.

  • Page 66: Step 5: Execute The Exposure

    66 | DX-D 600 | Getting Started with DX-D 600 Step 5: Execute the exposure In the operator room: Press the exposure button to execute the exposure. The exposure is sent to the NX workstation. WARNING: The radiation indicator on the control console lights up during exposure release.

  • Page 67: Step 6: Perform A Quality Control

    DX-D 600 | Getting Started with DX-D 600 | 67 Step 6: Perform a quality control In the operator room at the NX workstation: 1. Select the image on which quality control is to be performed. 2. Prepare the image for diagnosis by using e.g. L/R markers or annotations.

  • Page 68: Workflow For Full Leg Full Spine Examination

    68 | DX-D 600 | Getting Started with DX-D 600 Workflow for Full Leg Full Spine examination Refer to the DR Full Leg Full Spine User Manual (document 0179). The availability of DR Full Leg Full Spine depends on the configuration of the system.

  • Page 69: Basic Workflow Using A Cr Cassette

    DX-D 600 | Getting Started with DX-D 600 | 69 Basic workflow using a CR cassette Note: Using an ID Tablet to identify cassettes before the exposure will break the communication of X-ray parameters between the NX workstation and the X-ray generator console. It is advised to identify cassettes after the exposure, as described in this workflow.

  • Page 70: Step 1: Retrieve The Patient Info

    70 | DX-D 600 | Getting Started with DX-D 600 Step 1: retrieve the patient info At the NX workstation: 1. When a new patient comes in, define the patient info for the exam. 2. Start the exam. 0240H EN 20181119 0940...

  • Page 71: Step 2: Select The Exposure

    DX-D 600 | Getting Started with DX-D 600 | 71 Step 2: Select the exposure In the operator room at the NX workstation: 1. Select the thumbnail for the exposure in the Image Overview pane of the Examination window. RAD Table DR with cassette in the DR bucky...
  • Page 72 72 | DX-D 600 | Getting Started with DX-D 600 Note: When working in a PACS environment, the preferred workflow is to have only one image per cassette. This is needed for optimal use of hanging protocols. However, in particular cases (e.g.

  • Page 73: Step 3: Prepare The Exposure

    DX-D 600 | Getting Started with DX-D 600 | 73 Step 3: Prepare the exposure 1. In the operator room, position the X-Ray system, the patient and the cassette: a) To position the X-Ray system automatically, press and hold the AUTOCENTER button on the automatic positioning control box.

  • Page 74: Step 4: Check The Exposure Settings

    74 | DX-D 600 | Getting Started with DX-D 600 Step 4: Check the exposure settings In the operator room at the software console, or in the examination room at the touch screen console: 1. Check if the exposure settings displayed on the console are suitable for the exposure.

  • Page 75: Step 5: Execute The Exposure

    DX-D 600 | Getting Started with DX-D 600 | 75 Step 5: Execute the exposure In the operator room: Press the exposure button to execute the exposure. WARNING: The radiation indicator on the control console lights up during exposure release.

  • Page 76: Step 6: Repeat Steps 2 To 5 For The Next Subexposures

    76 | DX-D 600 | Getting Started with DX-D 600 Step 6: repeat steps 2 to 5 for the next subexposures 0240H EN 20181119 0940...

  • Page 77: Step 7: Digitize The Image

    DX-D 600 | Getting Started with DX-D 600 | 77 Step 7: digitize the image In the examination room: Take the exposed cassette. In the operator room: 1. Insert the cassette in the digitizer. 2. Click ID in the examination window of NX.

  • Page 78: Step 8: Perform A Quality Control

    78 | DX-D 600 | Getting Started with DX-D 600 Step 8: perform a quality control In the operator room at the NX workstation: 1. Select the image on which quality control is to be performed. 2. Prepare the image for diagnosis by using e.g. L/R markers or annotations.

  • Page 79: Stopping Dx-D 600

    DX-D 600 | Getting Started with DX-D 600 | 79 Stopping DX-D 600 To stop DX-D 600: 1. Stop NX. NX can be stopped in two ways, either by logging out of Windows or without logging out of Windows. For detailed information on stopping NX, refer to the NX User Manual, document 4420.

  • Page 80: Problem Solving

    80 | DX-D 600 | Problem solving Problem solving Topics: • Problem with automatic movements of the X-ray system • DR Detector is Exceeding the Maximum Working Temperature • DR Detector must be Recalibrated • DR Detector Problem 0240H EN 20181119 0940...

  • Page 81: Problem With Automatic Movements Of The X-Ray System

    DX-D 600 | Problem solving | 81 Problem with automatic movements of the X-ray system Details The automatic centering or auto-tracking is not working as expected. Cause Brief Solution Use the emergency stop button to reset the system: 1. Press the emergency stop button.

  • Page 82: Dr Detector Is Exceeding The Maximum Working Temperature

    82 | DX-D 600 | Problem solving DR Detector is Exceeding the Maximum Working Temperature Details A message is displayed on NX indicating that the DR De- tector is exceeding the maximum working temperature. Cause Due to ambient temperature conditions and the number of acquired images, the DR Detector’s internal tempera-...

  • Page 83: Dr Detector Must Be Recalibrated

    DX-D 600 | Problem solving | 83 DR Detector must be Recalibrated Details A message is displayed on NX indicating that the DR De- tector must be recalibrated. Cause A DR Detector must be recalibrated at regular interval. Brief Solution...

  • Page 84: Dr Detector Problem

    84 | DX-D 600 | Problem solving DR Detector Problem Details An error message is displayed on NX indicating a prob- lem related to the DR detector. Cause Brief Solution 1. Power off the DR detector. 2. Stop the NX workstation.

  • Page 85: Technical Data

    DX-D 600 | Technical Data | 85 Technical Data Topics: • DX-D 600 Technical Data • DX-D 600 X-Ray System Technical Data • Fixed DR Detector Technical Data • Fixed DR Detector Technical Data • Portable DR Detector Technical Data •...

  • Page 86: Dx-D 600 Technical Data

    86 | DX-D 600 | Technical Data DX-D 600 Technical Data The technical data are provided in this chapter or in the User Manual of the component. Table 1: Environmental conditions for the X-ray system Environmental Conditions (during storage and transport)

  • Page 87: Dx-D 600 X-Ray System Technical Data

    DX-D 600 | Technical Data | 87 DX-D 600 X-Ray System Technical Data Refer to the DX-D 600 X-Ray System User Manual (document 0242) for technical data of the X-Ray system. 0240H EN 20181119 0940...

  • Page 88: Fixed Dr Detector Technical Data

    88 | DX-D 600 | Technical Data Fixed DR Detector Technical Data Manufacturer Manufacturer DR Detector Varex Imaging Corporation, 1678 So. Pioneer Rd, Salt Lake City, UT 84104, USA Supported models 4343R (part number 7965) CsI conversion screen 4343R (part number 7964)
  • Page 89 DX-D 600 | Technical Data | 89 Reliability Estimated product life (if regularly serviced 100 000 RAD and maintained according to Agfa instruc- tions) 0240H EN 20181119 0940...

  • Page 90: Fixed Dr Detector Technical Data

    90 | DX-D 600 | Technical Data Fixed DR Detector Technical Data Manufacturer Manufacturer DR Detector THALES AVS FRANCE SAS 460 Rue du Pommarin – BP122 38346 MOIRANS France Supported models Pixium RAD 4343 C-E CsI conversion screen Pixium RAD 4343 G-E...

  • Page 91: Fixed Dr Detector Environmental Conditions

    DX-D 600 | Technical Data | 91 Fixed DR Detector environmental conditions Pixium RAD 4343 C-E Environmental Conditions (during normal operation) Temperature (ambient) between 15° and 35° Celsius Refer to environmental conditions of the X-ray sys- Humidity Atmospheric pressure Maximum altitude...

  • Page 92: Portable Dr Detector Technical Data

    92 | DX-D 600 | Technical Data Portable DR Detector Technical Data Refer to the DR Detector User Manual. 0240H EN 20181119 0940...

  • Page 93: Dr Generator Sync Box Technical Data

    DX-D 600 | Technical Data | 93 DR Generator Sync Box Technical Data Model name DR Generator Sync Box Type number 5400/516 Labeling Dimensions Depth 21.5 cm Width 33.5 cm Height 6.5 cm Weight 3.2 kg Electrical connection 100-240 V AC, 50/60 Hz Power consumption 40 W (max.

  • Page 94: Nx Workstation Technical Data

    94 | DX-D 600 | Technical Data NX Workstation Technical Data Electrical connection Operating voltage 90 – 263VAC Mains fuse protection 5.5A Mains frequency 47 – 63 Hz Power consumption Maximum power consumption 320W 0240H EN 20181119 0940...
  • Page 95 DX-D 600 | Remarks for HF-emission and immunity | 95 Remarks for HF-emission and immunity This equipment generates, uses, and can radiate radio frequency energy. CAUTION: The equipment may cause radio frequency interference to other medical or non medical devices and to radio communications.
  • Page 96 The DX-D 600 system is intended for use in the electromagnetic environment specified below. The customer or the user of this DX-D 600 system should assure that it is used in such an environment. Table 2: Guidance and manufacturer's declaration on electromagnetic...
  • Page 97 DX-D 600 | Remarks for HF-emission and immunity | 97 Table 3: Guidance and manufacturer's declaration on electromagnetic immunity Immunity IEC 60601-1-2 Compliance Electromagnetic en- Test Test Level Level vironment - guid- ance Electrostatic ± 8 kV contact ± 8 kV contact...
  • Page 98 98 | DX-D 600 | Remarks for HF-emission and immunity Magnetic field 30 A/m 30 A/m Magnetic field at the at the supply network frequency frequency should correspond to (50/60 Hz) the typical values as they are in a commer-...
  • Page 99 DX-D 600 | Remarks for HF-emission and immunity | 99 (80% AM at (80% AM 1 kHz) at 1 kHz) Note: The ISM (industrial, scientific and medical) bands between 0.15 MHz and 80 MHz are 6.765 MHz to 6.795 MHz; 13.553 MHz to 13.567 MHz;...
  • Page 100 100 | DX-D 600 | Record of X-ray exposure parameters Record of X-ray exposure parameters Patient size - X-ray exposure parameters Body region Adult - small Adult - medium Adult - large organ/projec- tion Skull kV mAs mA s kV mAs mA s...
  • Page 101 DX-D 600 | Record of X-ray exposure parameters | 101 Patient size - X-ray exposure parameters Body region Pediatric - small Pediatric - medium Pediatric - large organ/ projection Skull kV mAs mA s kV mAs mA s kV mAs mA s...
  • Page 102 102 | DX-D 600 | Record of X-ray exposure parameters Patient size - X-ray exposure parameters Body region Adult - small Adult - medium Adult - large organ/projec- tion Thorax kV mAs mA s kV mAs mA s kV mAs mA s...
  • Page 103 DX-D 600 | Record of X-ray exposure parameters | 103 Patient size - X-ray exposure parameters Body region Pediatric - small Pediatric - medium Pediatric - large organ/ projection Thorax kV mAs mA s kV mAs mA s kV mAs mA s...
  • Page 104 104 | DX-D 600 | Record of X-ray exposure parameters Patient size - X-ray exposure parameters Body region Pediatric - small Pediatric - medium Pediatric - large organ/ projection Spine kV mAs mA s kV mAs mA s kV mAs mA s...
  • Page 105 DX-D 600 | Record of X-ray exposure parameters | 105 Patient size - X-ray exposure parameters Body region Adult - small Adult - medium Adult - large organ/projec- tion Abdomen/ kV mAs mA s kV mAs mA s kV mAs mA s...
  • Page 106 106 | DX-D 600 | Record of X-ray exposure parameters Patient size - X-ray exposure parameters Body region Pediatric - small Pediatric - medi- Pediatric - large organ/ projection Abdomen/ kV mAs mA s kV mAs mA s kV mAs mA s...
  • Page 107 DX-D 600 | Record of X-ray exposure parameters | 107 Patient size - X-ray exposure parameters Body region Adult - small Adult - medium Adult - large organ/projec- tion Lower extrem- kV mAs mA s kV mAs mA s kV mAs mA s...
  • Page 108 108 | DX-D 600 | Record of X-ray exposure parameters Patient size - X-ray exposure parameters Body region Pediatric - small Pediatric - medium Pediatric - large organ/ projection Lower ex- kV mAs mA s kV mAs mA s kV mAs mA s...
  • Page 109 DX-D 600 | Record of X-ray exposure parameters | 109 Patient size - X-ray exposure parameters Body region Adult - small Adult - medium Adult - large organ/projec- tion Upper extrem- kV mAs mA s kV mAs mA s kV mAs mA s...
  • Page 110 110 | DX-D 600 | Record of X-ray exposure parameters Patient size - X-ray exposure parameters Body region Pediatric - small Pediatric - medi- Pediatric - large organ/ projection Upper ex- kV mAs mA s kV mAs mA s kV mAs mA s...

This manual is also suitable for:

Dx-d 600 generic5430/1105430/120

Table of Contents
