SitOnit Seating Focus 2.0 Assembly Instructions Manual page 3

Focus 2.0
Parts
•
Swivel-Tilt or Basic Mechanism (1)
•
⁄ " × 1½" Screw (4)
5
16
•
0.317" Washer (4)
Basic
Mechanism
SWIVEL-TILT OR BASIC
0.317" Washers
Parts: Base
•
Base Assembly (1)
•
Cylinder (1)
•
Foot Ring (1, Optional for Stool)
Cylinder
ASSEMBLY INSTRUCTIONS
Swivel-Tilt
Mechanism
⁄ " × 1½" Screws
5
16
Base Assembly
•
Enhanced Synchro Mechanism With
Optional Seat-Depth Adjustment (1)
•
⁄ " × ¾" Screw (3)
5
16
•
0.317" Washer (3)
ENHANCED SYNCHRO
0.317" Washers
C6543 Rev B
Enhanced Synchro
Mechanism
⁵ ⁄ ₁₆ " × ¾" Screws
Foot Ring
|
www.sitonit.net
|
