IV. MAIN SCREEN DESCRIPTION
1
2
3
4
1. Current CH boiler operation mode
2. Current time and day of the week – tap on this icon to set time and day of the week.
3. CH boiler icon:
- flame in the CH boiler – CH boiler is active
- no flame – CH boiler is damped
4. Current and pre-set DHW temperature – tap on this icon to change the pre-set temperature of domestic hot
water
5. Current and pre-set room temperature – tap on this icon to change the pre-set room temperature.
6. External temperature
7. Enter controller menu
8. WiFi signal– tap on this icon to check the signal strength, IP number and view WiFi module settings.
8
7
7
6
5
