Main Screen Description - Tech Controllers EU-T-3.2 User Manual

EU-T-3.2
1. Display
2. EXIT – press this button to display the room temperature/ floor temperature or to disable manual mode.
3. – press this button to decrease the edited value.
4. – press this button to increase the edited value.
5. MENU – hold this button to enable manual mode and to set calibration. Press the MENU button to move on to
edit next parameters.
1. MAIN SCREEN DESCRIPTI ON
4
3
2
1
1. Battery level
2. Maximum/minimum floor temperature - this icon is displayed only when the floor sensor is enabled in the
controller menu.
3. Hysteresis
4. Night mode
5. Day mode
6. Manual mode
7. Current time
8. Cooling/heating
9. Current temperature
10. Button lock
11. Pre-set temperature
5
6 7
11
11
8
9
10
