- Page 1 VERMEIREN Gemini 2 INSTALLATION MANUAL...
-
Page 3: Table Of Contents
Gemini 2 2021-06 Contents Contents Preface........................2 This product ....................3 Scope of delivery ..................4 Tools ......................4 Assembly and adjustments ................. 5 Adjusting the wheelchair to the user ............... 6 4.1.1 Seat depth ..................6 4.1.2 Footrest length (seat width 40) ............7 4.1.3... -
Page 4: Preface
If you still have questions after reading this manual, do not hesitate to contact Vermeiren. The information in this manual applies to all wheelchairs in the following list: • Gemini 2 Pictures of the product are used to clarify the instructions. Details of the shown product may deviate from your product. -
Page 5: This Product
Gemini 2 2021-06 Contents This product Push bar Backrests Safety belt Seat Footrest Footplate Steering wheels (front wheels) Driving wheels (rear wheels) Brake Frame Location identification plate Installation manual - 3 -... -
Page 6: Scope Of Delivery
Gemini 2 2021-06 Scope of delivery Scope of delivery The following items are part of the delivery. • Frame including wheels, backrest and seat, footrest, central brake • Tools • Manual • Accessories Please note that the basic configuration may differ in different European countries. Contact your specialist dealer. -
Page 7: Assembly And Adjustments
Important remark • Read the user manual of this wheelchair. • Be aware of the technical details and limits of intended use; see the user manual. • For more information, contact Vermeiren. See the website http://www.vermeiren.com/. Installation manual - 5 -... -
Page 8: Adjusting The Wheelchair To The User
Gemini 2 2021-06 Assembly and adjustments Adjusting the wheelchair to the user 4.1.1 Seat depth Seat width 32 1. Loosen the four bolts (1) on both sides of the seating plate. 2. Slide the seating plate to the front/back to the desired position (60 mm range, stepless). -
Page 9: Footrest Length (Seat Width 40)
Gemini 2 2021-06 Contents 4.1.2 Footrest length (seat width 40) The footrest can be changed in 2 different lengths (steps 35 mm: outer tube) and 4 different lengths (steps of 25 mm: inner tube). Adjustments are made as follows: 1. Loosen the screws (3) on both sides. -
Page 10: Hip Pelots
• Inflate the tyre using inflating equipment which complies to regulations and with a pressure indication in “bar”. • Only use replacement parts approved by Vermeiren. To change the tyre or inner tube, proceed as follows: 1. Let all the air out of the inner tube. - Page 11 Gemini 2 2021-06 Contents Place the rim belt in position over the air valve before inserting it into the rim. The rim belt can now be pulled over easily. Check that all spoke heads are covered (a rim belt is not required in the case of a plastic rim).
- Page 12 No part of this manual may be reproduced in any form what so ever (print, photocopy, microfilm or any other process) without written permission of the publisher, or processed, duplicated or distributed by using electronic systems. © Vermeiren Group 2021...
