Exam/Procedure Light
Service Manual
Halogen Exam Light III with
Fiberoptic Light Pipe
Model #'s - 48700, 48722, 48724, 48726, 48728
Halogen Exam Light III with
Fiberoptic Light Cable
Model #'s - 48780, 48782, 48784, 48786, 48788
Halogen Exam Light III with
Neonate Light Pipe
Model #'s - 48760, 48762, 48764, 48766, 48768
Halogen Exam Light III Light Box
with Power Cord
Model #'s - 48740, 48742, 48744, 48746, 48748
Operating
Instruction
Manual
488068 Rev. B
Advertisement
Table of Contents
Related Manuals for Welch Allyn 48700
Summary of Contents for Welch Allyn 48700
- Page 1 Exam/Procedure Light Service Manual Halogen Exam Light III with Fiberoptic Light Pipe Model #’s - 48700, 48722, 48724, 48726, 48728 Halogen Exam Light III with Fiberoptic Light Cable Model #’s - 48780, 48782, 48784, 48786, 48788 Halogen Exam Light III with Neonate Light Pipe Model #’s - 48760, 48762, 48764, 48766, 48768...
- Page 2 Thank you for purchasing the Welch Allyn Halogen Exam Light III. The Exam Light III is a positional light source which can be used for topical examinations of the skin and vaginal area. We believe that it is the highest quality product of its kind available in the world today.
-
Page 3: Table Of Contents
Table of Contents SYMBOL DESCRIPTIONS ......1 WARNINGS AND PRECAUTIONS ....2 COMPONENTS . - Page 4 TROUBLESHOOTING ......21 MAINTENANCE AND REPAIR ..... 22 WARRANTY .
-
Page 5: Symbol Descriptions
SYMBOL DESCRIPTIONS Attention: Consult user’s manual for additional information. Warning: Risk of fire. Replace fuses as marked. Caution: High Temperatures Caution: High Intensity Light... -
Page 6: Warnings And Precautions
CAUTION: Electric Shock Hazard - Remove power cord from electrical outlet and allow lamp to cool before replacing (Welch Allyn lamp # 04200). DANGER: Risk of explosion if used in the presence of flammable anesthetics. - Page 7 WARNING: Do not perform neonatal trans-illumination without the use of the #48210 neonatal trans-illuminator (with U.V. filter). Do not remove the focusing sleeve from the light pipe and use the light pipe for trans-illumination. Severe burns may result. General practices to minimize risk of harm to the skin from optical radiation hazards include: minimizing illumination intensity at the tissue examination site, minimizing exposure times,...
-
Page 8: Components
Model 48746 (Australia) Model 48748 (Japan) Fiberoptic Light Pipe (shown with focusing sleeve) Model 48200 (Included only with Model #’s 48700, 48722, 48724, 48726, and 48728) Fiberoptic Light Cable (shown with focusing sleeve) Model 48220 (Included only with Model #’s 48780, 48782, 48784,... -
Page 9: Accessories
Accessories Fiberoptic Light Pipe (Shown with Focusing Sleeve) Model 48200 Fiberoptic Light Cable (Shown with Focusing Sleeve) Model 48220 Focusing Sleeve Model 48605 Neonatal Transilluminator Model 48210 The optional neonatal Light Pipe/transilluminator is used to assist in the diagnosis of pneumothorax, to locate blood vessels, etc. - Page 10 Accessories (cont’d) Table Mount Bracket Model 48859 Mobile Stand Model 48850 Disposable Sheaths Model 52640 Disposable Sheath Dispenser Model 52641 35W Halogen Replacement Lamp Model 04200...
-
Page 11: Mounting
MOUNTING Use one of the following three mounting options in order to ensure proper operation of the light box. Wall Mount Choose appropriate mounting location. The length of the light pipe is 4 feet totally extended (fiberoptic light cable is 7 .5 feet). When choosing a mounting location, keep these dimensions in mind in addition to accounting for the actual application the light will be used for and what portion of the examination table will need to be... - Page 12 3. Mount the Light Box to the plate by inserting the pins on the back of the light box into the slots on the mounting plate. Let the light box drop down to position the pins into the narrow portion of the mounting slots ! ! ! ! . 4.
- Page 13 Table Mount (Model #48859) NOTE: Some exam table manufacturers supply mounting hardware for installation of the Exam Light III. Check with your table supplier for availability. 1. Determine the side of the table that will be most optimal for mounting the light. Consideration should be taken as to the location of the nearest power outlet and patient traffic.
-
Page 14: Mobile Stand
Mobile Stand (Model # 48850) Caster/Base Assembly Instructions ! ! ! ! : Base Push casters into the holes of the base until they “snap” into place. Alternate casters as shown. Locking Caster Base/Column Assembly Instructions " " " " : Locking Caster ! ! ! ! - Page 15 Exam Light/Mounting Plate Instructions # # # # : 1. Place the keyhole pins on the back of the Exam Light into the slots on the top of the mounting plate and slide down. 2. Line up the screw holes on the bottom of the Exam Light with the screw holes on the mounting plate.
-
Page 16: Set-Up And Operation
SET -UP AND OPERATION Set Up 1. Secure the Light Box to one of the mounting options per the appropriate instructions. 2. Insert the Fiberoptic Light Pipe, Fiberoptic Light Cable, or Neonate Light Pipe into the light pipe receptacle on the top of the Light Box. -
Page 17: Operation Of Light Pipe
Over a period of time and use, it is normal for the Light Pipe positioning capability to reduce and soften becoming less obedient. Abnormal softening or occurrence of noise upon articulation should be reported to Welch Allyn Technical Service (315-685-4560) immediately. Operation of Focusing Sleeve... -
Page 18: Lamp Replacement
6. Grasp the lamp connector and pull the lamp straight out of its holder. $ $ $ $ Pull the lamp from its connector and replace it with Welch Allyn Replacement Lamp #04200.% % % % 8. Push the lamp back into the holder. - Page 19 ! ! ! ! " " " " # # # # $ $ $ $ % % % %...
-
Page 20: Fuse Replacement
" " " 4. Reinsert the fuse holder by pressing it into the power connector until it snaps into place. 5. If the new fuses blow, immediately contact Welch Allyn Technical Service (315-685-4560). ! ! ! ! " " " "... -
Page 21: Cleaning
CLEANING Focusing Sleeve For best results, use the disposable sheath model #52640. 1. Remove the focusing sleeve from the Fiberoptic Light Pipe or Fiberoptic Light Cable by rotating it counterclockwise to unthread. 2. Use a cotton swab soaked in warm water and mild detergent to clean the distal end of the Fiberoptic Light Pipe or Light Cable, the proximal side of the Focusing Sleeve (small end), and distal window on the large end on the Focusing Sleeve. -
Page 22: Light Box
Light Box Note: The Light Box should not be sterilized or immersed. 1. Prior to cleaning, turn power off and disconnect the power cord from both the wall outlet and the Light Box. 2. The external surfaces may be cleaned by wiping with a cloth dampened with mild soap and water or by using the following cleaning/disinfecting solutions. -
Page 23: Specifications
SPECIFICATIONS Electrical Input Output Fuse Model 48740 120VAC∼60Hz, 12VAC, 3.0A T500mAL, 250V 400mA 48742 230VAC∼50Hz, 12VAC, 3.0A T315mAL, 250V 250mA 48744 230/240VAC∼50Hz, 12VAC, 3.0A T315mAL, 250V 250mA 48748 100VAC∼50/60Hz, 12VAC, 3.0A T630mAL, 250V 500mA Power Cord #18AWG, 3 wire grounded cord set, 8 feet (2.5 meters) long. Physical Characteristics Weight: 4.75 lb (2.16 Kg), light box only... -
Page 24: Approvals
The CE mark on this product indicates that it has been tested to and conforms with the provisions noted within the 93/42/EEC Medical Device Directive. Authorized European Representative Address: European Regulatory Manager Welch Allyn Ltd., Kells Road, Navan, County Meath, Republic of Ireland. Tel.: 353-46-79060 Fax: 353-46-27128... - Page 25 Light Box to an authorized repair center. Power cord is damaged. Replace the power cord with This may cause a new Welch Allyn power intermittent operation. cord. No power is supplied to Verify that the wall outlet has the wall outlet.
- Page 26 315-685-4560. Tampering with the unit will automatically void all warranties expressed or implied. WARRANTY Light Box - Welch Allyn guarantees that the Light Box is free of any manufacturing defects or Welch Allyn will repair or replace, free of charge, any parts proven to be defective through causes other than misuse, neglect, damage in shipment and normal wear and tear.
