BENDIX Wingman Advanced FLR20 Service Data page 59

How to Read Key System Indicators and Reset Alignment Values
Read System Key Indicators (Confi guration)
1. Start Bendix ACom Diagnostics and connect to vehicle.
® ®
2. Select "Advanced" and Click "Start with ECU" to display the "Advanced Status" window.
3. Select "Confi g" to display the indicators
System Key Indicators
Attribute Description
This value should equal 0 if the radar sensor is mounted on the center line of the vehicle.
If the service technician believes the radar sensor should be mounted offset from center,
Mounting Offset
call 1-800-AIR-BRAKE (1-800-247-2725, option 2).
This is a status indicator for the function of stationary object warning. Available for use
Stationary Object
Warning Indicator in Bendix
Trouble code will be set if
Lateral Alignment
value is less than -1.5º
Value
This indicates the distance setting and following distance alert that are confi gured for
Confi guration
the vehicle. Refer to
Number
How To Reset The (Lateral) "Alignment Value"
4. From the confi guration window shown above, click "Modify."
5. From the Change Confi guration window, select "Reset Alignment Value."
6. Cycle the vehicle ignition power to complete the process.
Call the Bendix Tech Team at 1-800-AIR-BRAKE (1-800-247-2725, option 2) for troubleshooting assistance.
Appendix H
system versions since 2010.
® ® ™
Wingman Advanced
Table 7 for setting information.
Take Note of:
Model #,
Software Version,
Software P/N,
Active DTCs
Normal operation Trouble code will be set if
-1.5º to 1.5º value is more than 1.5º
Appendix H
See Section:
6.2
1.7
6.8
5.4
