SmartWave LF Tool
PN: 710.0089
Revision 1.1
User Manual
© Copyright 2009
Bendix CVS Canada Inc.
Duplication of this document in whole or in part for any purposes other than those for which it was
originally intended, without the written approval of Bendix CVS Canada Inc. is strictly prohibited.
This manual may be changed by Bendix CVS Canada Inc. at any time and without notice.
Advertisement
Table of Contents
Related Manuals for BENDIX Smartwave LF Tool
Summary of Contents for BENDIX Smartwave LF Tool
- Page 1 Duplication of this document in whole or in part for any purposes other than those for which it was originally intended, without the written approval of Bendix CVS Canada Inc. is strictly prohibited. This manual may be changed by Bendix CVS Canada Inc. at any time and without notice.
-
Page 2: Table Of Contents
TABLE OF CONTENTS ..........................3 NTRODUCTION ...........................3 VERVIEW ........................5 ETTING TARTED LF T ....................5 SING THE MART ID N ...................6 ROGRAMMING ENSOR UMBERS 5.1..........................6 MART ....................7 ERIFYING ORRECT NSTALLATION 710.0089 Rev. 1.1 SmartWave LF Tool User Manual... -
Page 3: Introduction
INTRODUCTION The SmartWave LF Tool is a handheld device designed to provoke data transmissions from SmartWave sensors. The tool can be used to assist the installer during: New Installations – programming sensor ID numbers & vehicle configuration into the •... - Page 4 ON/OFF & Mode Select Button: Press and hold this button for 2 seconds to power ON the SmartWave LF tool. A beep will sound and the Initiate LED will light up when the tool is ON. Press this button without holding to toggle the SmartWave LF Tool between the Sensor Initiate and Sensor Learn function.
-
Page 5: Getting Started
GETTING STARTED The SmartWave LF Tool is powered by a standard 9 Volt battery. To install the battery, open the battery access panel on the back of the tool and connect the supplied battery to the 9 Volt battery connector. Insert the battery into the slot and close the battery access panel. Press and hold the ON/OFF button for 2 seconds to power up the tool. -
Page 6: Programming Sensor Id Numbers
ID. 3. Turn the SmartWave LF Tool ON by pressing and holding the On/Off button for 2 seconds. 4. Press the On/Off/Mode Select Button once to toggle the tool mode to the Learn sensor function. -
Page 7: Verifying Correct Installation
5. Hold the SmartWave LF Tool pointed towards the tire’s sidewall adjacent to sensor’s location approximately 2” away from the tire’s surface. The sensor should be located at the valve stem with a rim label indicating its location. Do not touch the edge of the rim. - Page 8 FCC NOTICE This device complies with Part 15 of the FCC Rules. The SmartWave LF Tool is a Part 15 Low Power transmitter below 1705 kHz. The device has a rated RF power output of less than 0.2 micro Watts. Due to the transmit frequency range and low level of output power the device is not subject to the routine RF exposure valuation as per Section 2.1093 of the FCC rules.
