APPENDIX A - RADAR MOUNTING
GENERAL
WARNING: Improper use of the Bendix
property damage, serious injuries, or death.
WARNING: Under no circumstances must the radar be removed or repositioned from the original production
line installation. The assembly should always be mounted in the original OEM location. If this location is not in the
center of the vehicle, the mounting offset will need to be programmed through Bendix
CAUTION: Vehicle equipment, including bumpers, deer guards, etc. must not infringe upon the zone used
by the radar sensor to emit and receive radar waves. See Appendix A3. Failure to comply with this requirement
will impair the function of the radar. Only vehicle OEM-approved covers and/or cover panels may be installed
in front of the radar.
The radar sensor assembly is mounted to the front of the vehicle using an adjustable bracket. This adjustable bracket
allows for the radar sensor to be properly aimed laterally and vertically to maximize Wingman Advanced system
performance. When mounting a radar sensor, the wire harness connector should always point towards the passenger
side of the vehicle.
A.1 VEHICLE APPLICATIONS
The radar sensor can be mounted and installed only on vehicles that have Bendix Wingman Advanced already installed.
At this time Wingman Advanced cannot be retrofi tted onto vehicles, even if that vehicle is equipped with the Bendix
ESP stability system.
®
A.2 REPLACEMENT PARTS
Replacement parts exist for all components shown below. Parts are available from any Bendix authorized parts supplier.
RADAR
SOURCE
Radar Sensor with Stand-off Assemblies
• Kit K071772
includes a specifi cally-
programmed Bendix FLR20
®
three stand-off adjustor assemblies, and six
mounting screws.
32
®
Bendix
®
ADJUSTABLE
STAND-OFF
ASSEMBLIES
(3)
Bracket (Varies) and Stand-off Assemblies
• Provide the bracket part number (see label)
radar sensor, when ordering replacements. Kits will include
™
three stand-off adjustor assemblies, and six
mounting screws.
Appendix A
™
FLR20 Radar Mounting
Wingman ® Advanced ™
Appendix A
system can result in a collision causing
ACom Diagnostics software.
® ®
ADAPTER
BRACKET
(VARIES)
Stand-off Assemblies Only
• Kit K073199
off adjustor assemblies, and six
mounting screws.
®
includes three stand-
