4.3 TABLE OF BENDIX
NOTE: FLR10 RADAR SENSORS USE DIFFERENT DTCS — SEE SD-61-4962.
Refer to column one for the DTC(s) found and determine the Service Action Code(s) to take. See Tables 6A and 6B below:
Table of Diagnostic Trouble Codes (DTCs), Causes and Recommended Actions for FLR20 Radars
DTC SPN FMI
1-2 886 14
3 886 14
4 886 4
5 886 3
6-10 886 14
11 886 14
12-15 886 14
16 886 14
17-27 886 14
29 886 14
30 886 14
31 886 14
32 886 14
33 886 14
34 886 14
35 886 14
36 886 14
37 886 14
38 886 14
41 886 14
42 886 14
43 886 14
44 886 14
45 886 14
46 886 7
47-77 886 14
78 886 14
79-81 886 14
82 3839 16
83 898 13
84-85 886 14
86 886 14
87 886 14
88 886 14
92 886 14
93 886 14
94 886 14
95 886 14
TABLE 6A - REFER TO COLUMN ONE FOR EACH DTC CODE FOUND AND FIND ITS SERVICE ACTION CODE.
® WINGMAN ® ADVANCED
Internal radar sensor error
Antenna is dirty or partially blocked
Battery voltage too low
Battery voltage too high
Internal radar sensor error
J1939 wiring harness error or other device DTC
Internal radar sensor error
Antenna is dirty or partially blocked
Internal radar sensor error
J1939 Signal Error: Missing AEBS2 message
J1939 Signal Error: Missing CCVS message
J1939 Signal Error: Missing CVW message
J1939 Signal Error: Missing EBC1 message
J1939 Signal Error: Missing EBC2 message
J1939 Signal Error: Missing EBC5 message
J1939 Signal Error: Missing EEC1 message
J1939 Signal Error: Missing EEC2 message
J1939 Signal Error: Missing ERC1_DR message
J1939 Signal Error: Missing ERC1_XR message
J1939 Signal Error: Missing TD message
J1939 Signal Error: Missing VDC2 message
J1939 Signal Error: Missing VDHR message
J1939 Signal Error: Missing EBC3 message
Internal radar sensor error
Radar sensor is misaligned
Internal radar sensor error
Bendix ABS J1939 Proprietary message signal missing or error state
Internal radar sensor error
Adaptive Cruise Control braking overuse
J1939 Signal ACC1 Engine not properly confi gured for Wingman Advanced
Internal radar sensor error
Confi guration mismatch between brake controller and radar sensor
J1939 Signal Error: Missing VDC1 message
CMT braking overuse
J1939 Signal Error: Invalid CCVS1 wheel speed
J1939 Signal Error: Error in CCVS1 wheel speed
J1939 Signal Error: Not available CCVS1 wheel speed
J1939 Signal Error: Invalid CCVS1 CC speed
™

DIAGNOSTIC TROUBLE CODES (DTCs)

Description
Go to the Service
Action Code List
in Table 6B
A
C
B
B
A
K
A
C
A
M
M
M
M
M
M
M
M
M
M
M
M
M
M
A
D
A
E
A
F
G
A
H
M
J
P
N
O
P
