BENDIX Wingman Advanced FLR20 Service Data page 56

APPENDIX G - HOW TO GENERATE, READ AND RESET THE BENDIX
DIAGNOSTIC TROUBLE CODES USING BENDIX
G1: How to Generate Wingman
1. Select the Bendix ACom
®
3. Select "DTC".
For reference
5. Fill in the requested information: Company, location,
technician, date/time, VIN, and click "OK"
7. The ACom DTC report is generated. This can be saved and emailed to Bendix if desired.
Call the Bendix Tech Team at 1-800-AIR-BRAKE (1-800-247-2725, option 2) for troubleshooting assistance.
56
® Diagnostic Trouble Code Report with ACom
desktop icon
®
® ®
ACOM DIAGNOSTICS SOFTWARE
Appendix G
2. Select "Wingman" from the starter screen. Select "start with
ECU"
4. To generate the ACom report, select "Report".
6. Select how you want the report displayed or printed. Then click
"OK"
Appendix G-
® WINGMAN ® SYSTEM
® Diagnostics
