When the initialization sequence is complete, the following screen is displayed for approximately 3 seconds
to indicate the features available to the driver.
Next, the DIU will enter normal operation. Under normal operation, the screen is:
If the Bendix ® Wingman
Test" screen. Also, the audible distance alerts will activate, followed by a screen indicating that the self-test
has run. Below left is the screen that will be briefl y displayed if the self-test runs and passes. Below right is
the screen that will be briefl y displayed if the self-test runs and fails. If the self-test fails, a diagnostic trouble
code (DTC) will be set. The driver should turn off the vehicle, wait 15 seconds and then turn it back on again.
If the problem persists, a qualifi ed technician will be necessary for troubleshooting. See the "Power-Up Self-
Test" in this service data sheet Section 3.1: Troubleshooting Basics for further information.
Single Yellow LED
Illuminated
F1.2 Menu Operation
Pressing the "OK" button at any time will enter the "Menu Operation Mode". The following selections will
appear in a scrollable window. Some items may not appear if the feature is not confi gured or not allowed as
shown below.
• Volume
• Radar
• Dist. Setting (Distance Setting)
• Dist. Units (Distance Units)
• US/Metric
• Object Speed
• Brightness
• System Status
• Diag. Display (Diagnostic Display)
• Demo (Demonstration. Note: Demo is available only when vehicle is not moving)
The desired menu item is highlighted using the up (
with the "OK" button. The following sections describe each menu item.
®
Bendix Driver Interface Unit (DIU): Displays & Alerts
(No LEDs
Wingman ACB
Illuminated)
Wingman Adv.
(No LEDs
Illuminated)
goes into self-test mode, the DIU may briefl y display the "Bendix Self-
® Advanced ™
Bendix
Self Test
Appendix F
Bendix
(Followed
by a Single
Orange
LED
Illuminated)
) or down (
Appendix F
Bendix
Self Test Failed
) arrow buttons and selected
