Instruction Manual
Ride on SUV w/ DIY License Plate (12V) (Fun Letters)
Item number: 060-ROT-10
JC111B
*Product appearance and colors may vary from the photo.
ATTENTION
This vehicle is packed with the battery disconnected. Connect
the battery before use.
This manual contains important safety, performance and
maintenance information. Read the manual thoroughly before
allowing your child to ride your new electric ride-on toy. Failure
to read the user manual can result in property damage or bodily
injuries. Keep this user manual for future reference.
Advertisement
Table of Contents
Related Manuals for Kidzone JC111B
Summary of Contents for Kidzone JC111B
- Page 1 Instruction Manual Ride on SUV w/ DIY License Plate (12V) (Fun Letters) Item number: 060-ROT-10 JC111B *Product appearance and colors may vary from the photo. ATTENTION This vehicle is packed with the battery disconnected. Connect the battery before use. This manual contains important safety, performance and maintenance information.
-
Page 2: Safety Instruction
Safety Instruction When using electrical product, basic safety precaution should always be followed including the following: Read all Instruction before operating this product WARNING: • To Protect against electrical shock, do not immerse cord, charger, transformer, battery, or the product in water or other liquid. •... -
Page 3: Prevent Fire
WARNING: PREVENT FIRE injury and could also ruin the electrical system. in serious injury. • The battery must be handled by adults only. The battery is heavy and contains sulfuric acid(electrolyte). Dropping the battery could result in serious injury. • Never allow children to charge the battery. Battery charging must be done by adults only. - Page 4 WARNING FAILURE TO FOLLOW THE SAFETY INSTRUCTIONS LISTED BELOW MAY RESULT IN SERIOUS INJURY OR DEATH. The owner’s manual contains assembly, use and maintenance instructions. Child Safety Warnings • Adults supervising children must read and understand this entire manual before allowing any child to use this product.
- Page 5 WARNING 5• If necessary, adults and supervisors are always responsible for setting up gates and barriers to ensure a safe riding environment for the child rider. 6• Be aware that this ride-on toy does not have braking capabilities. Allowing use of this ride-on toy in areas that require braking may cause rolls, crashes, serious injury, or death to the child rider.
- Page 6 WARNING Battery and Charging Warnings The following safety hazards may result in serious injury or death to the user of the ride-on: Do not mix old and new batteries. • , ) c • Corrosive Material Warnings Battery posts, terminals and related accessories contain lead and lead •...
- Page 7 WARNING • Regularly check charger, supply cord and connector for wear and damage. Look for frayed or kinked wires, any exposed inner wires, any missing insulation. If any damage is observed do not plug in the charger and do not charge the battery.
- Page 8 Model No.: 060-ROT-10 Battery: 12V 4.5AH x 1 Charger input: 100 - 240V AC Charger output: 12V 500mA Speed: 1.86 - 3.1 mph (3 - 5 km/h) Suitable Age: 37 - 95 months Maximum User Weight: 66 lb / 30 kg Dimension: 39.4”...
- Page 9 Parts and Feature A. Car Body B. Windshield C. Steering Wheel D. Wheel E. Small Wheel Cover F. Rear Spring Holder G. Rearview Mirror Holder H. Rearview Mirror I. Door J. Motor K. Search Light Holder L. Search Light M. Front Spring N.
- Page 10 Parts and Feature P. Seat Q. Spanner R. M4 x 14 Screw S. Nut ( 2pcs pre-installed on the front axle) T. Remote Control U. Charger V. Flat Iron Y. MP3 Cable W. Big Washer X . Small Washer (For front axle inner side) ( 2pcs pre-installed on the front axle) Tool Required: Screwdriver...
-
Page 11: Assembly Instruction
Assembly Instruction (The following diagrams for reference only, the photos may vary from actual product.) Attach the Flat Iron as arrow. then turn the whole front axle assembly upside down (S) Nut ( V ) Flat Iron (Q) Front Axle (X) Small Washer (M) Front Spring (X) Small Washer... - Page 12 Assembly Instruction Front wheel assembly: (D) Wheel (X) Small Washer (S) Nut (E) Small Wheel Cover Parts and Feature Tool required: (W) Big Washer P. Seat Q. Spanner R. M4 x 14 Screw • Insert a Big Washer (W) to a side of the Front Axle, follow by the Wheel (D), then secure a Small washer (X) and Nut (S) by the spanner.
- Page 13 Assembly Instruction (J) Motor (N) Rear Axle (D) Wheel (X) Small Washer (S) Nut Parts and Feature Tool required: P. Seat Q. Spanner (E) Small Wheel Cover • Insert Rear Axle (N) through the opening hole of the Rear Spring Holders. •...
- Page 14 Assembly Instruction (G) Rearview Mirror Holder (I) Door (R) M4 x 14 Screw • Insert the Door (I) into the side of the car body. • Assemble a Rearview Mirror Holder (G) on the door and car body using M4 x 14 Screws (R). •...
- Page 15 Assembly Instruction (H) Rearview Mirror (B) Windshield (K) Search Light Holder (L) Search Light • Insert Windshield (B), Rearview Mirrors (H), Search Light Holder (K), and Search Light (L) to the car body in their corresponding position. • The search light holder marked with L / R , please ensure them assemble in correspoinding position ( L to Left side, R to Right side).
- Page 16 Assembly Instruction (P) Seat (R) M4 x 14 Screw Align and assemble the Seat (P) to the car body and secure using 2 M4 x 14 screws (R).
- Page 17 User Instruction (Control Panel) Voltage Display Increase Volume/ Next track Button High/low speed Forward Button Reverse Button Horn Button Play / Pause Decrease Volume / Previous Track Button MP3 Port Charging Port USB Port Power / Lamp button Control the vehicle A.
- Page 18 User Instruction (Remote Control) Speed button Stop button Foward Button Right Button Reverse Button Left Button Light Indicator Remote Control Buttons 1. Forward Button Press to move the vehicle forward. Do not switch between forward and reverse until the vehicle comes to a complete stop. 2.
- Page 19 User Instruction (Remote Control) Using the remote control The remove control should only be used by adult or under adult supervision. ATTENTION: The remote control will override all control input from the vehicle. Insert / Changing Battery 1. Open the battery cover on the back of the remote control. 2.
- Page 20 User Instruction (Charging) WARNING: The battery should only be charged by an adult. Charging the battery 1. Locate the charging port on the control panel. 2. Connect the charger to the charging port. 3. Plug the charger into a wall outlet. The battery will start charging. 4.
-
Page 21: Care And Maintenance
Care and Maintenance • Check the product regularly and make sure there is no missing or loose parts. Re-tighten any loose parts if necessary. • Make sure there is no cracked or broken plastic parts. • Keep away the product from heat and humid area, cover it with trap when not in use. •... - Page 22 Troubleshooting Problem Possible Reason Solution Check if the battery connectors Poor wire connection Contact Customer service if Vehicle needs a push to go necessary forward “Dead spot” on motor Contact customer service Loud grinding sound or clicking Damaged motor or gear box Contact customer service sound from the motor or gear box Disconnected / Badly connected...
- Page 23 Model: JC111B, 060-ROT-10 FCC ID: 2AX5C-JC111B This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
-
Page 24: Warranty Terms
It is the retailer’s responsibility consumer, or other parties not authorized by to contact KIDZONE with a claim. We will not KIDZONE will void this warranty. handle claims from consumers directly; all 3.
