ITEM PART NO. DESCRIPTION
1 ST-BASE08 BALLAST TRAY
2 SBT07 POLE BASE PLATE
3 STBOG4001 POLE, 40' BALLAST
4 STBOG2001 POLE TOP, 20' BALLAST
5 STBSP60HK HARDWARE KIT
D
6 ST-BASE08EXT EXTENSION KIT
C
B
A
NOTE: FOR ASSEMBLY INSTRUCTIONS
SEE SHEETS 2, 3, 4 AND 5
8
7 6
QTY. WEIGHT NOTE NO.
1 1857.70 LBS
1 108.07 LBS
1 838.69 LBS
1 228.87 LBS
1 99.12
1 266.47
7 6
5 4
B
B
4
3
6
2
1
