Bermuda
Entertainment Console
IMPORTANT NOTE
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damages occuring to the parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure a
completed product as it was designed.
Part List
A.
Top
1 pc.
E.
Base
1 pc.
Shelf
4 pcs.
I.
Back Panel
2 pcs.
Hardware List
Cam Lock Screw
19 pcs.(+1 extra)
Cam Lock
19 pcs.(+4 extra)
Tools required for assembly : Phillips screwdriver
Home Styles Consumer Assistance: www.homestyles-furniture.com,
servicedesk@homestyles-furniture.com, 888-680-7460, 877-831-0319
B.
Side Panel
1 pc
.
F.
J.
Back Panel
1 pc.
Wood Screw
for Back Panel
12 pcs.(+1 extra)
Adjustable Pin
24 pcs.(+1 extra)
C.
Side Panel
1 pc.
H.
G.
Plinth
Shelf
1 pc.
2 pcs.
K.
Door
1 pc.
Wood Screw
for Wood Block
Magnet
12 pcs.(+1 extra)
2 pcs.
Wood Screw
for Magnet
4 pcs.(+1 extra)
Tools recommended for assembly :Level
D1.
Middle Panel
Middle Panel
1 pc
.
L.
M.
N.
Door
Leg
Wood Block
1 pc.
4 pcs.
4 pcs.
Pull Handle
2 pcs.
Machine Screw
2 pcs.
D2.
1 pc
.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Home Styles Bermuda 88 5543 09
Summary of Contents for Home Styles Bermuda 88 5543 09
- Page 1 Wood Screw for Magnet Adjustable Pin Cam Lock Machine Screw 4 pcs.(+1 extra) 24 pcs.(+1 extra) 19 pcs.(+4 extra) 2 pcs. Tools required for assembly : Phillips screwdriver Tools recommended for assembly :Level Home Styles Consumer Assistance: www.homestyles-furniture.com, servicedesk@homestyles-furniture.com, 888-680-7460, 877-831-0319...
- Page 2 Assembly Instructions 2/4 IMPORTANT * Do not tighten up all the screws until each part is properly assembled. * After assembly , item must be level to work properly. Use the included adjustable levelers to level. * Use a soft cloth between these parts and the floor. STEP 1 Attach 2X Wood Blocks (N) to Top (A) and Base (E) by using Wood Screws for Wood Block into the pre-drilled holes.
- Page 3 Assembly Instructions 3/4 STEP 2 Attach Middle Panels (D1) and (D2) Cam Lock onto Base (E) with Cam Locks. (see Figure 1) STEP 3 Attach Plinth (H) to Base (E) with Cam Locks. Cam Lock Attach Side Panel (B) and (C) to unit with Cam Locks.
- Page 4 Assembly Instructions 4/4 STEP 5 Slide Back Panels (I) and (J) into place. Attach Doors (K) and (L) by sliding the door lift hinges into the side panels lift hinges. (see Figure 2) Assemble Pull Handles to Doors (K) and (L) with Machine Screws. (see Figure 3) Cam Lock Figure 2...
