Pantry
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damages occurring to the parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure
a completed product as it was designed.
E.
Side Panel
1 pc.
For assembly see instructions in carton 88 5523 692
Home Styles Consumer Assistance Line 888-680-7460 and 877-831-0319
A.
Door
2 pcs.
servicedesk@homestyles-furniture.com
B.
Door
2 pcs.
F.
Side Panel
1 pc.
C.
Side Panel
1 pc.
D.
Side Panel
1 pc.
