Slimdrive EMD
GB Mounting and service instructions
Invers
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Slimdrive EMD Invers and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for GEZE Slimdrive EMD Invers

Summary of Contents for GEZE Slimdrive EMD Invers

  • Page 1 Slimdrive EMD GB Mounting and service instructions Invers...

  • Page 2: Table Of Contents

    Slimdrive EMD Invers Contents Symbols and means of representation ......................3 Product liability ................................3 Safety ...................................3 Proper use ...........................................3 Standards ..........................................4 Additional applicable documents ................................4 Safety instructions ......................................4 Safety-conscious working .....................................4 Inspection of the mounted system................................4 Environmentally-conscious working ................................4 Transportation and storage ..........................5 Tools .....................................5...

  • Page 3: Symbols And Means Of Representation

    3. 1 Proper use The Slimdrive EMD Invers door drive is designed for the automatic opening and closing of swing-door single ac- tion doors. The door opens mechanically in case of a power failure or an alarm. The Slimdrive EMD Invers is suitable: solely for use in dry rooms à...

  • Page 4: Standards

    à GEZE shall not be liable for injuries or damage resulting from unauthorized modification of the system. à GEZE shall not be liable if products from other manufacturers are used with GEZE equipment. Only original GEZE parts may be used for repair and maintenance work as well.

  • Page 5: Transportation And Storage

    The Slimdrive EMD Invers is a swing door drive operating fully automatically that is actuated by sensors or switches. The Slimdrive EMD Invers operates with a motor during opening and closing. In the case of a power failure or triggered alarm it opens mechanically.

  • Page 6: Basic Structure And Extension

    Product description Slimdrive EMD Invers 6.2 Basic structure and extension Drive Motor-gearing unit Transformer Side elements Base plate EMD Invers control Drive axle, continuous Power storage Hood anodised or coloured (for 2-leaf version available also continuous or with intermediate hood) RollerXguideXrailXwithXlever Mounting depends on the type of stop selected. Lever Roller Rail End piece EMDXInversXlinkXarm For soffit depth SD: 0–100 mm 100–200 mm 200–300 mm...

  • Page 7: Types Of Mounting, Stops

    The 2-leaf version corresponds to that of the 1-leaf mounting type. The opening angle of the door has to be limited by a door stop. The Slimdrive EMD Invers allows the following types of stop, each for doors DIN left and doors DIN right: HingeXside...

  • Page 8: Mounting

    Open all the packaging units. Check whether the scope of delivery is complete. Familiarise yourself with the parts. The Slimdrive EMD Invers door drive with roller guide rail or link arm consists of: à Drive unit à 1 drive à 1 set of fastening screws à...

  • Page 9: Fitting Template For Drive, Roller Guide Rail And Link Arm (Invers Version)

    Slimdrive EMD Invers Mounting 7.2 Fitting template for drive, roller guide rail and link arm (Invers version) The top of the door must be aligned exactly horizontally, both in the closed and in the open position. Pick up the correct fitting template in accordance with the mounting type (Section 7.3). Take the type of fastening into account (direct fastening or with mounting plate, see Section 7.3).

  • Page 10: Mounting Dimensions For The Mounting Types

    Mounting Slimdrive EMD Invers 7.3 Mounting dimensions for the mounting types 7.3. 1 Transom mounting hinge side with roller guide rail (single-leaf) The drilling images DIN left and DIN right are mirrored. Use suitable fitting templates (see Section 7.2). Fixing with mounting plate Direct fixing Low-voltage connection for sensors, door opener, programme switch and bolt switch contact (line-feed Ø 15–20 mm) Dimensional reference hinge middle Covered power supply 230 V / 50 Hz for power supply cable (line-feed Ø 15–20 mm) Use 8 screws Use at least 2 screws for each drilling row FasteningXmeans à...
  • Page 11 Slimdrive EMD Invers Mounting 7.3.2 Transom mounting opposite hinge side with roller guide rail (single-leaf) The drilling images DIN left and DIN right are mirrored. Use suitable fitting templates (see Section 7.2). Fixing with mounting plate Direct fixing Low-voltage connection for sensors, door opener, programme switch and bolt switch contact (line-feed Ø 15–20 mm) Dimensional reference hinge middle Covered power supply 230 V / 50 Hz for power supply cable (line-feed Ø 15–20 mm) Use 8 screws Use at least 2 screws for each drilling row FasteningXmeans à Mounting plate = M5 à...
  • Page 12 Mounting Slimdrive EMD Invers 7.3.3 Transom mounting opposite hinge side with link arm (single-leaf) The drilling images DIN left and DIN right are mirrored. Use suitable fitting templates (see Section 7.2). Fixing with mounting plate Direct fixing Low-voltage connection for sensors, door opener, programme switch and bolt switch contact (line-feed Ø 15–20 mm) Dimensional reference hinge middle Covered power supply 230 V / 50 Hz for power supply cable (line-feed Ø 15–20 mm) For mounting dimensions of the link arm refer to the instructions "Mounting instructions for link arm EMD Invers", Drwg. 70106-9-9551 Mat. No. 118268 Use 8 screws Use at least 2 screws for each drilling row FasteningXmeans à Mounting plate = M5 à...
  • Page 13 Slimdrive EMD Invers Mounting 7.3.4 Door panel mounting hinge side (single-leaf) à The drilling images DIN left and DIN right are mirrored. Check whether there is enough space to open the door sufficiently. Connect all the cables with door transmission to the junction boxes (concealed/surface mounting).
  • Page 14 Mounting Slimdrive EMD Invers 7.3.5 Transom mounting hinge side with roller guide rail (double-leaf) Use suitable fitting templates as for the single-leaf version (see Section 7.2). FasteningX2xXEMDXInversXwithXintermediateXmountingXplate FasteningX2xXEMDXInversXwithXcontinuousXmountingXplateX B3 /2 B3 /2 DirectXfasteningX2xXEMDXInvers Covered power supply 230 V / 50 Hz for Moving leaf power supply cable (line-feed Ø 15–20 mm) Fixed leaf Low-voltage connection for sensors, door Dimensional reference hinge middle opener, programme switch and bolt switch Door leaf width contact (line-feed Ø 15–20 mm) Hinge distance B3...
  • Page 15 Slimdrive EMD Invers Mounting 7.3.6 Transom mounting opposite hinge side with roller guide rail (double-leaf) Use suitable fitting templates as for the single-leaf version (see Section 7.2). FasteningX2xXEMDXInversXwithXintermediateXmountingXplate FasteningX2xXEMDXInversXwithXcontinuousXmountingXplateX DirectXfasteningX2xXEMDXInvers Covered power supply 230 V / 50 Hz for Dimensional reference hinge middle power supply cable (line-feed Ø 15–20 mm) Moving leaf Low-voltage connection for sensors, door Fixed leaf opener, programme switch and bolt switch Door leaf width contact (line-feed Ø 15–20 mm) Hinge distance B3...
  • Page 16 Mounting Slimdrive EMD Invers 7.3.7 Transom mounting opposite hinge side with link arm (double-leaf) Use suitable fitting templates as for the single-leaf version (see Section 7.2). FasteningX2xXEMDXInversXwithXintermediateXmountingXplate FasteningX2xXEMDXInversXwithXcontinuousXmountingXplateX DirectXfasteningX2xXEMDXInvers Low-voltage connection for sensors, door Dimensional reference hinge middle opener, programme switch and bolt switch Moving leaf contact (line-feed Ø 15–20 mm) Fixed leaf Covered power supply 230 V / 50 Hz for Door leaf width power supply cable (line-feed Ø 15–20 mm) Hinge distance B3...
  • Page 17 Slimdrive EMD Invers Mounting 7.3.8 Door panel mounting hinge side with guide rail (double-leaf) Use suitable fitting templates as for the single-leaf version (see Section 7.2). FasteningX2xXEMDXInversXwithXcontinuousXmountingXplateX DirectXfasteningX2xXEMDXInvers Covered power supply 230 V / 50 Hz for Fixed leaf power supply cable (line-feed Ø 15–20 mm) Door leaf width Low-voltage connection for sensors, door Hinge distance B3 opener, programme switch and bolt switch contact (line-feed Ø 15–20 mm) Dimensional reference hinge middle Moving leaf...

  • Page 18: Mounting The Drive

    Mounting the lever (for mounting with roller guide rail) WARNING! Danger of injury, danger of damage to the Slimdrive EMD Invers! The mounted and possibly tension lever is braked electrically. Disconnecting a motor cable releases the stored energy of a tensioned lever in unbraked form and accelerates the lever back to the initial position.
  • Page 19 Slimdrive EMD Invers Mounting 7.7. 1 Use of the roller lever types depending on the mounting type Mounting type Mounting side Roller lever Transom mounting hinge side DIN left Standard DIN right Standard Transom mounting opposite hinge DIN left Door leaf DIN left side DIN right Door leaf DIN right...

  • Page 20: Mounting The Link Arm (Alternatively To Lever With Roller Guide Rail)

    Mounting Slimdrive EMD Invers 7.7.4 Door panel mounting hinge side with roller guide rail Ensure that the correct lever DIN right or DIN left conforming to the order is installed. See stamp on the roller lever. Open the door (6) to the maximum opening width, fix it there.

  • Page 21: Electrical Connection

    Slimdrive EMD Invers Electrical connection Electrical connection 8. 1 Mains connection à In accordance with the valid regulations it must be possible to deenergize the door drive at a suitable point. In the case of a fixed connection by the customer, provide an upstream master switch.

  • Page 22: Settings

    Settings Slimdrive EMD Invers Settings 9. 1 Setting the opening force The opening force must always be set for all the operating modes at the power storage. The assignment depends on the mounting type in accordance with Section 6.3. 9. 1 . 1 Factory setting 9.

  • Page 23: Opening Speed In Deenergized State

    Reteach the drive. Service and maintenance The following prescribed maintenance work at the Slimdrive EMD Invers must be carried out at least once a year by properly trained personnel. If there is a display programme switch, the service display lights up in the display.

  • Page 24: Maintenance Work

    Let the motor cool down. 10.2 Maintenance work The Slimdrive EMD Invers is free of maintenance to a great extent and no extensive work has to be carried out with the exception of that specified below: Check fastening screws for firm seating.
  • Page 25 Slimdrive EMD Invers Service and maintenance...
  • Page 26 Service and maintenance Slimdrive EMD Invers...
  • Page 27 Slimdrive EMD Invers Service and maintenance...
  • Page 28 Høje Taastrup Boulevard 53 E-Mail: office-india@geze.com Niederlassung West China 2630 Taastrup Italy Tel. +45(0)46-323324 Nordsternstraße 65 GEZE Industries (Tianjin) Co., Ltd. Fax +45(0)46-323326 45329 Essen Shuangchenzhong Road GEZE Italia Srl Tel. +49 (0) 201-83082-0 Beichen Economic Development Via Giotto, 4 E-Mail: danmark.se@geze.com...
