  • Page 1 Slimdrive SL EN Pre-installation instructions Product family 200278-00...
  • Page 2 Slimdrive SL product family Contents Introduction................................3 Symbols and illustrations....................................3 Revisions and validity......................................3 Product liability .........................................3 Reference documents .....................................3 Fundamental safety precautions ........................4 Intended use........................................4 Safety instructions ......................................4 Safety-conscious working .....................................5 Environmentally conscious working .................................5 Safety instructions related to transportation and storage .......................5 Qualification ........................................5...
  • Page 3 If there are several actions to be taken, keep to the given order. Revisions and validity Version 00: valid for Slimdrive SL product family from date of manufacture 2021. Product liability In compliance with the liability of the manufacturer for his products as defined in the German “Product Liability Act”, compliance with the information contained in this brochure (product information and intended use, misuse,...
  • Page 4 à in the installation variants / types of installation documented by GEZE à within the tested/approved area of application (climate / temperature / IP rating) Any other use is considered non-intended and will lead to the exclusion of all liability and warranty claims to GEZE. Safety instructions à...
  • Page 5 Slimdrive SL product family Fundamental safety precautions Safety-conscious working à Secure workplace against unauthorised entry. à Use only the cables specified on the cable plan provided. Cables must be shielded in compliance with the wir- ing diagram. à Secure loose, internal drive cables with cable ties.
  • Page 6 About this document Slimdrive SL product family About this document These instructions describe the pre-mounting of the Slimdrive SL product family automatic sliding door drive. Overview 4. 1 Diagrams Number Type Name 70484-0-030 Drive drawing Slimdrive SL, drive 70494-0-010 Drive drawing...
  • Page 7 Slimdrive SL product family Overview Components and assembly groups These illustrations show the equipment of a standard drive in 2-leaf and 1-leaf version. The structure of the assembly groups can vary depending on the drive equipment or version. Precise details about positioning of the individual components can be found on the drive diagram.
  • Page 8 Pre-mounting Slimdrive SL product family Pre-mounting The up-to-date drive diagram is applicable for the pre-mounting work to be carried out. All components must be identified and installed in accordance with the drive diagram. 5. 1 Machining track, cover and mounting profile Check profiles for damage.
  • Page 9 Slimdrive SL product family Pre-mounting Preparing the track cap Slide earthing jumpers (1) into the mount- ing groove in accordance with the drive drawing. Screw on the earth jumpers (1) using the screw (2) (torque 4 Nm). Installing the track cap WARNING! Risk of fatal injury due to electric shock! The track is not sufficiently functionally earthed if there is a poor connection between cap (1) and track (3).
  • Page 10 Pre-mounting Slimdrive SL product family Unscrew the device flat plug (6) with screw (7) and two toothed discs (8) from the ground connector (2). Install the device flat plug (6) with screw (7) and two toothed discs (8) into the provided drill hole on the cap (1) (torque 1.5 Nm).
  • Page 11 Slimdrive SL product family Pre-mounting Installing the drive components The exact positioning of the components is given on the drive drawings. 2-leaf 1-leaf, right hand slide to open 1-leaf, left hand slide to open Legend: Drive length without extension Extension right...
  • Page 12 Pre-mounting Slimdrive SL product family Installing cable guides Cables can be cut! Lay cables in such a way that there are no cables near the moving parts. Distance approx. 200 mm. Fix the cable guide (1) on the track (2).
  • Page 13 Slimdrive SL product family Pre-mounting Route the transformer cable (1) between the control unit (2) and track (5). Route the transformer cable (1) from the control unit through the cable guides and (4) to the transformer. Fit the transformer cable (1) to terminal (6)
  • Page 14 Slimdrive SL-FR Lay rotary encoder cable (2), motor connection cable (3) and motor connection cable of the sec- ond Slimdrive SL NT-FR motor gear unit (1) to the control unit. Insert the connector into the control unit (4). Do not plug rechargeable battery cable into the control unit yet.
  • Page 15 Slimdrive SL product family Pre-mounting 5. 1 1 Connecting the tooth belt locking mechanism (optional) and control unit Plug the cable for tooth belt locking mecha- nism (1) in at the control unit (2). Lay the cable for tooth belt locking mecha-...
  • Page 16 Pre-mounting Slimdrive SL product family 5. 1 1. 1 Fitting the toothed belt 1-leaf Thread the tooth belt on the motor pulley and deflection pulley, shorten if necessary. Insert the ends of the tooth belt (1) into the clamping piece (4) (3 teeth per side) and fix in place using a counter piece (2) and hollow screws (3).
  • Page 17 Slimdrive SL product family Pre-mounting 5. 1 2 Installing the transformer ground The transformer must be positioned according to the drawing so that it covers the track, thereby fulfilling electrical safety requirements. Connect the earthing cable (2) from the trans- former to the device flat plug (1).
  • Page 18 Device safety test and production test Slimdrive SL product family Device safety test and production test WARNING! Risk of fatal injury due to electric shock! The electrical system (230 V/115 V) may only be Action connected and disconnected by a professional electri- cian or specialist electrician.
  • Page 19 Slimdrive SL product family Preparation for installation Preparation for installation During preparation for installation the drive unit is prepared for later installation. The current drive drawing is applicable for carrying out the installation work. All components must be identified and installed in accordance with the drive diagram.
  • Page 20 Preparation for installation Slimdrive SL product family Installing the cover earthing Knock the mounting bolts for the cover ground- ing (2) flush into the groove on the cover (1) on the left end of the cover (1). approx. 30 mm 7.2. 1...
  • Page 21 Slimdrive SL product family Preparation for installation Installing the side plates The side plate on the left is always mounted onto the cap. The side plate on the right is mounted directly onto the track. Insert a sliding block (2) for side plate (1) and clamp with setscrew M6 x 12.
  • Page 22 Preparation for installation Slimdrive SL product family...
  • Page 23 Slimdrive SL product family Preparation for installation...
