REVEX
3PH from 120A to 210A
17.1 Fuses Replacement
Open the cover and remove the screws, then replace it with the correct fuse, use the screws with a proper
suggested torque indicated below:
Type
120A
150-210A
Torque
Screw
Lb-in (N-m)
M6
44.2 (5.0)
M6
44.2 (5.0)
Screw
+
M5
59
User's manual
Torque
Lb-in (N-m)
31 (3.5)
