8.1 Terminal Positions
Warning: Before connecting or disconnecting the unit check that power and control cables
are isolated from voltage sources.
8.2 Power Terminals
Terminal
Description
L1
Line Input Phase 1
T1
Load Output Phase 1
L2
Line Input Phase 2
T2
Load Output Phase 2
L3
Line Input Phase 3
T3
Load Output Phase 3
21
User's manual
