CyberData 011530 Installation Quick Reference

RTFM Button
RTFM button (SW1)
Contacting CyberData
Corporate Headquarters
CyberData Corporation
Sales: 831-373-2601 ext. 334
3 Justin Court
Support: 831-373-2601 ext. 333
Monterey, CA 93940, USA
Support Website:
RMA Department Contact and Status:
Phone: 831-373-2601
Warranty Information:
Fax: 831-373-4193
https://www.cyberdata.net/
© 2022, CyberData Corporation, ALL RIGHTS RESERVED
When the device is operational and linked to a
network, you can use the Reset Test Function
Management (RTFM) button (SW1 [see picture])
to announce the device's IP address or restore
the device to the factory
default settings.
To announce the device's current IP address:
• Press and release the RTFM button within a
five second window.
Note The device will use DHCP to obtain the
new IP address (DHCP-assigned
address or default to IPv4 Link Local if a
DHCP server is not present).
To restore the device to factory default settings:
• Press and hold the RTFM button for longer
than five seconds until you hear the device
announce that it is restoring the factory
default settings.
https://support.cyberdata.net/
https://support.cyberdata.net/
https://support.cyberdata.net/
931856A Quick Reference
Installation Quick Reference
The IP Endpoint Company
SIP Hand Wave Indoor Intercom
SIP Compliant
011530
Parameter
IP Addressing
a
IP Address
Web Access Username
Web Access Password
a
Subnet Mask
a
Default Gateway
a. Default if there is not a DHCP server present.
Typical System Installation
*More installation and mounting
802.3af Compliant Ethernet Switch
options are available in the
Operations Guide.
Intercom Intercom
Getting Started
• Download the Operations Guide PDF file, from the Downloads tab at the following webpage:
https://www.cyberdata.net/products/011530
• Create a plan for the locations of your Intercoms.
• WARNING: This product should be installed by a licensed electrician according to all local electrical and building codes.
• WARNING: To prevent injury, this apparatus must be securely attached to the floor/wall in accordance with the installation
instructions.
• WARNING: The PoE connector is intended for intra-building connections only and does not route to the outside plant.
• WARNING: This enclosure is not rated for any AC voltages!
Intercom Parts
Tool required for assembly: A size #2 Phillips screwdriver
(1) Intercom Assembly
Quick Reference
Factory Default Setting
DHCP
IPv4 Link Local
admin
admin
IPv4 Link Local
IPv4 Link Local
Intercom IP Phone IP PBX Server
(1) Mounting Kit
(4) #6 X 3/8-inch,100 Deg.,
Flat Head, Self-Tapping Screw
931856A © 2022, CyberData Corporation, ALL RIGHTS RESERVED
