Option and MICROS Ports

You can find the Workstation 6 Option ports and the MICROS port shown in Figure 2
and Figure 3 under the Rear Cover and they contain the following ports:
•
•
•

Figure 2 - Option I/O Ports

Figure 3 –MICROS Port

Adjustable Stand

The Workstation 6 comes with an adjustable stand that provides mounting and
expansion options. The adjustable stand contains the following features:
•
•
•
•
•
•

Printer Power Supply Storage

The Workstation 6 adjustable stand includes a bracket that allows mounting of the Epson
PS-180 Power Supply. An internal "Y" case provides AC power to the Epson PS-180
Power Supply.
Introduction to the Workstation 6
MICROS
The MICROS port provides connectivity to the system through a number of
industry standards, including Serial (UART), SDIO, USB, and PCIe. A standard
connector and dedicated footprint provide future-proofing of devices such as
wireless modules and storage devices.
Micro USB 2.0 x3
Left and Right Speaker Output
USB 3.0 port
Printer Power Supply Storage/expansion module location
AC power cable
DC power cable
3 security screws
2 for the adjustable cover
o
1 for the Workstation 6
o
Hex key
