Leaving Chilled Liquid Temperature Cycling
Offset - Restart
Access Level Required: OPERATOR
This value allows the user to specify the Leaving Chilled
Liquid Temperature at which the chiller will restart af-
ter a shutdown on a LEAVIng CHILLED LIQUID
– LOW TEMPERATURE cycling shutdown. This is
done by defining an offset above the Leaving Chilled
Liquid Temperature setpoint. It is programmable over a
range of 0°F to 70°F above the setpoint, to a maximum
restart value of 80°F. The chiller will automatically re-
start when this temperature is reached. This setpoint can
be used to reduce chiller cycling by delaying the chiller
restart until the cooling load has increased.
Brine Low Evaporator Cutout
Access Level Required: SERVICE
This value is only available in Brine mode. It allows
the user to specify the Evaporator Pressure at which a
safety shutdown is initiated. Service Technicians refer
to YORK Service Manual 160.54-M1.
Sensitivity
Access Level Required: SERVICE
This value allows the user to adjust the sensitivity of the
Leaving Chilled Liquid Temperature control. Service
Technicians refer to YORK Service Manual 160.54-
M1.
JOHNSON CONTROLS
Smart Freeze (Off / On)
Access Level Required: SERVICE
This value is only available if the chiller is not in Brine
mode. It allows the user to enable the Smart Freeze Point
Operation which allows the chiller to run closer to the
freeze point without shutting down. Service Technicians
refer to YORK Service Manual 160.54-M1.
Refrigerant (Enabled / Disabled)
Access Level Required: SERVICE
When an Evaporator Refrigerant Sensor has been installed
it must be enabled via this toggle before the system will
utilize the new, enhanced resolution input. Service Tech-
nicians refer to YORK Service Manual 160.54-M1.
NaVigatioN
Home
Access Level Required: VIEW
Causes an instant return to the Home Screen.
