Simplex 4100-1314 Installation Instructions Manual page 3

Figure 1 depicts the 100 W amplifier.
EXPANSION
NAC PORT 1
OUTPUT
TROUBLE LED
BAUD RATE/
ADDRESS DIP
SWITCH (SW1)
COMMS
TROUBLE LED
INPUT TROUBLE
LED (LED3)
For LED descriptions, see the section on
page 3
(P1)
(LED2)
(LED1)
Figure 1: The 100 W Amplifier
LED Indications.
Digital/Analog Amplifiers Installation Instructions
NAC (SPEAKER CIRCUIT)
TERMINAL BLOCK (TB1)
EXPANSION
NAC PORT 2
(P3)
NAC TROUBLE
LEDS (LEDs 5
through 10)
DIGITAL
AUDIO
DECODER
PORT (P2)
AC POWER
LED (LED4)
BACKUP
AUDIO
TERMINAL
BLOCK (TB2)
579-174 Rev. Q
