3 Diagnostic Programs
Space Size Error. xx:
Note:
If you need to test USB storage on different USB port, before the test, please prepare some USB storage and then
insert them into all the USB ports you want to test, or insert it into different USB port and start over the test if you have
only one USB storage.
4) Test file
WinPETD.exe: Test program.

4-2-5 SD STORAGE Test

This test checks if the connec�on of the SD Port on the PC works by using a SD storage card. You need to prepare a SD storage card.
The test writes some data to the SD storage card. The SD storage card needs at least 12 MB free space.
1) Test contents
The test detects a SD storage card plugged to the SD port on your PC. Then the test copies some data to the SD storage card, read the
data back from the SD storage card and compare it to the original data. If the comparison is OK, the test will say that the port is passed.
Important Note:
Do not take SD storage card out during SD STORAGE Test trying to check the port that SD storage card plugged in.
2) Test screen
▼ Drive informa�on ... The drive le�er of the SD storage card being tested
▼Test item ... The test item being executed: File Access test.
▼ Progress status ... The test progress
3) Test result
■ In case of PASS
"OK" is shown in the "Result" field on the "Diagnos�cs" dialog.
■ In case of FAIL
"NG" is shown in the "Result" field on the "Diagnos�cs" dialog.
The detail of the error will be recorded to the WPETD log file as below.
Message
File Access Error. xx:.
Space Size Error. xx:
4) Test file
3-26
XX is the USB drive le�er.
There is no free space for crea�ng the
file. XX is the USB drive le�er.
Test item
Explana�on
Failed in accessing the file.
XX is the SD storage card drive letter.
There is no free space for crea�ng the file. XX is the SD storage card drive letter.
Maintenance Manual
Drive information
Progress status
Remarks
SATELLITE PRO C40-J/C50-J
