Maintenance Manual
dynabook
T*5/TX/EX/BX/AX/AZ*5/BZ*5
Series
(P-No. PS59*)
T*/T*/CZ*5 Series
(P-No. PS59R)
File Number (960-922)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T 5 Series and is the answer not in the manual?

Questions and answers

Related Manuals for dynabook T 5 Series

Summary of Contents for dynabook T 5 Series

  • Page 1 Maintenance Manual dynabook T*5/TX/EX/BX/AX/AZ*5/BZ*5 Series (P-No. PS59*) T*/T*/CZ*5 Series (P-No. PS59R) File Number (960-922)
  • Page 2 (DBH)[DT](SYD) Dang Fengzhi Copyright © 2023 Dynabook Inc. All rights reserved. Under the copyright laws, this manual cannot be reproduced in any form without the prior written permission of Dyanbook. No patent liability is assumed, with respect to the use of the information contained herein.
  • Page 3 Please read. A note is a hint or advice that helps you make best use of your equipment. Improper repair of the computer may result in safety hazards. Dynabook requires service technicians and authorized dealers or service providers to ensure the following safety precautions are adhered to strictly.
  • Page 4 The manual is divided into the following parts: Chapter 1 Hardware Overview describes the system unit and each FRU. Chapter 2 Troubleshooting Procedures explains how to diagnose and resolve FRU problems. Chapter 3 Test and Diagnostics describes how to perform test and diagnostic operations for maintenance service.

  • Page 5: Table Of Contents

    Table of Contents Hardware Overview Chapter 1 1.1 Features and System Unit Block Diagram ........1-1 1.2 HDD & SSD ..................1-7 1.3 Optical Disc Drive (ODD) ............1-11 1.4 Keyboard ..................1-14 1.5 Display ..................1-15 1.6 Power Supply ................1-16 1.7 Batteries ..................
  • Page 6 3.6 Memory Test ..................3-9 3.7 Hard Disk (&SSD) Test ..............3-10 3.8 Keyboard Test ................... 3-12 3.9 LCD Panel Test................. 3-13 3.10 Battery Charge Test ..............3-13 3.11 Fan Test ................... 3-14 3.12 Acceleration sensor test ............3-13 3.13 Log Utility ..................
  • Page 7 Board Layout Appendix B B.1 SYSTEM board (FTL5SY*/F4L7SY*) Front View ......B-1 B.2 SYSTEM board (FTL5SY*/F4L7SY*) Back View ... . B-2 B.3 USB 2.0/Audio board (FTL5U2*/F4L7A3*) Front View..B-3 B.4 USB2.0/Audio board (FTL5U2*) Back View.
  • Page 8 List of Figures Figure 1-1 System unit configurations ..............1-2 Figure 1-2 System unit block diagram ..............1-2 Figure 1-3 Keyboard ....................1-14 Figure 1-4 LCD module ..................... 1-15 Figure 1-5 Power supply output rating ..............1-16 Figure 2-1 Troubleshooting flowchart (1/2) .............. 2-3 Figure 2-2 Troubleshooting flowchart (2/2) ..............
  • Page 9 Figure 4-30 Removing the DC Fan (2) ..............4-31 Figure 4-31 Removing the DC Fan (3) ..............4-31 Figure 4-32 Removing the DC Fan (4) ..............4-32 Figure 4-33 Arrange DC-IN harness ................ 4-32 Figure 4-34 Arrange LCD harness(for HD Web Camera Model) ......4-33 Figure 4-35 Arrange LCD harness(for IR Camera Model) ........
  • Page 10 List of Tables Table 1-1 2.5-inch HDD specifications (HGST) ............1-7 Table 1-2 2.5-inch HDD specifications ..............1-8 Table 1-3 2.5-inch HDD specifications (Seagate) ............. 1-9 Table 1-4 2.5-inch HDD specifications (WD) ............. 1-9 Table 1-5 M.2 SATA SSD specifications ..............1-10 Table 1-6 M.2 PCIe SSD specifications ..............
  • Page 11 Table C-14 CN5391 IR Camera Harness interface connector (4-pin) ....C-18 Table C-15 CN6331 Tweeter Speaker interface connector (4-pin) ....... C-18 Table C-16 CN6330 Speaker interface connector (4-pin)........C-18 Table C-17 CN8001 DC-IN connector (2-pin)............C-18 Table C-18 CN8020 RTC battery connector 3-pin) ..........C-18 Table C-19 CN9530 FTL5U2*/F4L7A3* interface connector .........

  • Page 12: Chapter 1 Hardware Overview

    Chapter 1 Hardware Overview 1.1 Features and System Unit Block Diagram This Personal Computer uses extensive Large Scale Integration (LSI), and Complementary Metal-Oxide Semiconductor (CMOS) technology extensively to provide compact size, minimum weight, low power usage and high reliability. This computer incorporates the following features/major components.

  • Page 13: Figure 1-1 System Unit Configurations

    Hardware Overview Figure 1-1 System unit configurations Figure 1-2 is a block diagram of the system unit. Figure 1-2 System unit block diagram Maintenance Manual (960-922)
  • Page 14 Hardware Overview Microprocessor ■ ® The computer is equipped with an Intel Processor. Maintenance Manual (960-922)
  • Page 15 Hardware Overview The PC comes in with one of the following speeds: Number of L3 Cache Core Frequency Turbo cores/number Size of threads Kaby lake-U Core i7-7500U 3.5GHz (2.70GHz) Non-vPro Keby lake-U Core i5-7200U 3.1GHz (2.50GHz) Non-vPro Kaby lake-U Core i3-7130U 2.7GHz (2.70GHz) Non-vPro Kaby Lake-U Celeron...
  • Page 16 Hardware Overview Display ■ The PC comes in with one of the following two types: 15.6”HD(1366x768) Non CSV ■ 15.6” FHD(1920x1080) CSV ■ Interface ■ To external monitor HDMI out port Keyboard ■ The computer’s keyboard layouts are compatible with a 104/105-key enhanced keyboard - by pressing some keys in combination, all of the 104/105-key enhanced keyboard functions can be performed on the computer.
  • Page 17 Hardware Overview Sound system ■ The sound system is equipped with the following features: Stereo speakers ■ Built-in microphone (provided with some models) ■ Headphone/Microphone jack ■ Internal LAN ■ The computer has built-in support for Ethernet LAN (10 megabits per second, 10BASE-T), Fast Ethernet LAN (100 megabits per second, 100BASE-TX) and Gigabit Ethernet LAN (1000 megabits per second, 1000BASE-T).

  • Page 18: Hdd & Ssd

    Hardware Overview 1.2 HDD & SSD 1.2.1 2.5-inch Hard Disk Drive The removable HDD is a random access non-volatile storage device. It has a non-removable 2.5-inch magnetic disk and mini-Winchester type magnetic heads. The HDD specifications are listed in tables below. Table 1-1 2.5-inch HDD specifications (HGST) Items Specifications...

  • Page 19: Table 1-2 2.5-Inch Hdd Specifications

    Hardware Overview Table 1-2 2.5-inch HDD specifications Items Specifications G8BC0009A502 G8BC0008B1A4 Width (mm) 69.85 69.85 Height mm) Depth (mm) 100.0 100.0 Weight (g) 92 Max 117 Max Storage size 500G 1000G (formatted) Speed (RPM) 5,400 5,400 Data transfer rate 1469.7 1068.1 (Mb/s) Buffer-host data...

  • Page 20: Table 1-3 2.5-Inch Hdd Specifications (Seagate)

    Hardware Overview Table 1-3 2.5-inch HDD specifications (Seagate) Items Specifications G8BC000BX1A0 G8BC000BX2A0 Width (mm) 69.85 69.85 Height mm) Depth (mm) 100.35 100.35 Weight (g) 92 Max 96 Max Storage size (formatted) Speed (RPM) 5,400 5,400 Data transfer rate 140MB/s 140MB/s Positioning Time (read and seek 13 typ/18 max...

  • Page 21: Table 1-5 M.2 Sata Ssd Specifications

    Hardware Overview Table 1-5 M.2 SATA SSD specifications Items Specifications G8BC000BZ250 G8BC000BZ510 Width (mm) 22.00 ± 0.15 22.00 ± 0.15 Height mm) 2.23 Max 2.23 Max Depth (mm) 80.0 ± 0.15 80.0 ± 0.15 Weight (g) 6.9 typ. 6.9 typ. Storage size 256GB 512GB...

  • Page 22: Optical Disc Drive (Odd)

    Hardware Overview Table 1-8 M.2 PCIe SSD specifications (Samsung) Items Specifications G8BC000BU250 G8BC000BU510 G8BC000BUA10 Width 22.00 ± 0.15 22.00 ± 0.15 22.00 ± 0.15 (mm) Height 2.38 Max 2.38 Max 2.38 Max Depth 80.0 ± 0.15 80.0 ± 0.15 80.0 ± 0.15 (mm) Weight (g) 8 Max...

  • Page 23: Table 1-9 Dvd-Rom Drive Specifications

    Hardware Overview The write-disable tool document no.: 360074226. Table 1-9 DVD-ROM drive specifications Specifications Item G8CC0006BZ50 G8CC0006BZ60 128 ± 0.2 (excluding 128 ± 0.2 (excluding Width (mm) projections) projections) Outline 9.5 ± 0.4 (excluding 9.5+0.5/-0.2 (excluding Height (mm) projections) projections) dimensions 127 ±...

  • Page 24: Table 1-10 Blu-Ray™ Writer Drive Bdxl™ Outline Dimensions

    Hardware Overview 1.3.2 Blu-ray™ Writer drive BDXL™ The drive supports the following formats: CD-ROM, DVD-ROM, DVD Video, CD-DA, CD-Text, Photo CD™ (single/multi-session), CD-ROM Mode1/Mode 2, CD-ROM XA Mode 2 (Form1, Form2), Enhanced CD (CDE XTRA), Addressing Method 2, DVD-R, DVD-RW, DVD+R, DVD+RW, DVD- RAM, DVD-R DL (Format1), DVD+R DL, BD-ROM, BD-ROM DL, BDR, BD-R DL, BD-RE, BD-RE DL,BD-R TL, BD-R QL BD-RE TL and BD-RE The specifications are listed in Table below.

  • Page 25: Keyboard

    Hardware Overview 1.4 Keyboard The keyboard is mounted 104(US)/105(UK) keys that consist of character key and control key, and in conformity with JIS. The keyboard is connected to membrane connector on the system board and controlled by the keyboard controller. Figure 1-3 is a view of the keyboard.

  • Page 26: Display

    Hardware Overview 1.5 Display The display consists of 15.6-inch HD LCD module or 15.6-inch FHD LCD module. 1.5.1 LCD Module The LCD module used for the display uses a backlight as the light source and can display a maximum of 16M colors with15.6-inch HD (1366x768) resolutions or 15.6-inch FHD (1980x1080) resolutions.

  • Page 27: Power Supply

    Hardware Overview Table 1-11 LCD module specifications Item G33C0009A110 G33C00097110 G33C0009G110 Maker Number 1366(W) × 768(H) 1920(W) × 1080(H) 1920(W) × 1080(H) of Dots Dot pitch 0.252(H)×0.252(V) 0.179(H)×0.179(V) 0.179(H)×0.179(V) (mm) Active area 344.23(W) × 193.54(H) 344.16(W) × 193.54(H) 344.16(W) × 193.59(H) (mm) 359.5(W) ×...

  • Page 28: Batteries

    Hardware Overview (*1)×: C9,C10 State (*2)×: Power saving mode (*3)O: Wake up Disable (*4)O: USB Wake up Enable 1.7 Batteries The computer has two types of batteries as follows: Main battery pack ■ RTC battery ■ The battery specifications are listed in Table 1-10.

  • Page 29: Table 1-12 Battery Specifications

    Hardware Overview Table 1-12 Battery specifications Material Output Battery name Parts Code Capacity voltage Main battery G71C000JM510 Lithium-Ion 14.8 V 45Wh, 4 cell (PS59* model) G71C000L6110 Lithium-Ion 14.8 V 45Wh, 4 cell G71C000KV110 Lithium-Ion 14.8 V 45Wh, 4 cell G71C000LA110 Lithium-Ion 14.6 V 45Wh, 4 cell...

  • Page 30: Ac Adaptor

    Hardware Overview Table 1-14 Data preservation time Battery type Sleep Mode Shut Down Mode Battery(45Wh, 4 cell) about 6 days about 100 days (PS59* model) about 40 days (PS59R model) 1.7.3 RTC battery The RTC battery provides power to keep the current date, time and other setup information in memory while the computer is turned off.

  • Page 31: Troubleshooting Procedures

    Chapter 2 Troubleshooting Procedures 2.1 Troubleshooting This chapter describes how to determine which Field Replaceable Unit (FRU) in the computer is causing the computer to malfunction. (The “FRU” means the replaceable unit in the field.) The FRUs covered here are as follows: 1.

  • Page 32: Troubleshooting Flowchart

    Troubleshooting Procedures Before exchanging a system board, the DMI information on TOP Menu is written down. Please register DMI information after exchanging a system board. Also update with the latest EC/KBC as described in Appendix H “EC/KBC Rewrite Procedures” After replacing the LCD, update with the latest EC/KBC as described in Appendix H “EC/KBC Rewrite Procedures”...

  • Page 33: Figure 2-1 Troubleshooting Flowchart (1/2)

    Troubleshooting Procedures Figure 2-1 Troubleshooting flowchart (1/2) START Connect the AC Adapter Follow the power supply DC IN/Battery indicator on? Diagnostic Procedure Turn the power on. Follow the system board Any error message is displayed? Diagnostic Procedure No Follow the display Startup logo Diagnostic Procedure is displayed?

  • Page 34: Figure 2-2 Troubleshooting Flowchart (2/2)

    Troubleshooting Procedures Figure 2-2 Troubleshooting flowchart (2/2) ① Follow the keyboard Keyboard works well? Diagnostic Procedure Follow the touch pad Touch pad works well? Diagnostic Procedure Set the device containing the test program for maintenance to the PC, and start the test program. (The reboot of the PC is required.) Diagnostic Program Follow the Diagnostic Procedure...
  • Page 35 Troubleshooting Procedures If the diagnostics program cannot detect an error, the problem may be intermittent. The Test program should be executed several times to isolate the problem. Check the Log Utilities function to confirm which diagnostic test detected an error(s), and then perform the appropriate troubleshooting procedures as follows: 1.

  • Page 36: Power Supply Troubleshooting

    Troubleshooting Procedures 2.3 Power Supply Troubleshooting The power supply controller controls many functions and components. To determine if the power supply is functioning properly, start with Procedure 1 and continue with the other procedures as instructed. The procedures described in this section are: 2.3.1 Procedure 1 Power Status Check 2.3.2 Procedure 2 Error Code Check 2.3.3 Procedure 3 Connection Check...

  • Page 37: Table 2-2 Error Code

    Troubleshooting Procedures “1” On for one second “0” On for half second Interval between data bits Off for half second The error code begins with the least significant digit. Example: Error code 11h (Error codes are given in hexadecimal format.) Check 1 Convert the DC IN/battery indicator blink pattern into the hexadecimal error code and compare it to the tables below.

  • Page 38: Figure 2-3 Connection Check

    Troubleshooting Procedures B power output error dur- During power off (S5) status, PCNFBV signal change to ing power off status (out- assertion. put active) P power output error dur- During power on process, PPVOK(PCNFPV) signal time- ing power on process out more than 1s after EVON signal assertion.

  • Page 39: System Board Troubleshooting

    Troubleshooting Procedures 2.3.4 Procedure 4 Charging Check Check if the power supply controller charges the battery pack properly. Perform the following procedures: 1. Check 1 Make sure the AC adaptor is firmly plugged into the DC IN jack. 2. Check 2 Make sure the battery pack is properly installed. If it is properly installed, go to Check 3.
  • Page 40 Troubleshooting Procedures 2.4.1 Procedure 1 Message Check When the power is turned on, the system performs the Initial Reliability Test (IRT) installed in the BIOS ROM. The IRT tests each IC on the system board and initializes it. If an error message is shown on the display, perform Check 1. ■...

  • Page 41: Table 2-3 Main Test Menu

    Troubleshooting Procedures If error message (18) is displayed, go to the Keyboard Troubleshooting Procedures. If error message (19), (20) or (21) is displayed, go to the HDD Troubleshooting Procedures. If error message (22) is displayed, go to the USB FDD Troubleshooting Procedures.

  • Page 42: Hdd/Ssd Troubleshooting

    Save the required contents of the HDD to other storage drive in advance. For the backup, refer to the User’s Manual. 2.5.1 Procedure 1 Partition Check (Not Used) Insert the Dynabook DOS system disk and start the computer. Perform the following checks: Check 1 Type C: and press Enter key.
  • Page 43 Troubleshooting Procedures Input FDISK and press Enter key. Choose "Display Partition Information" from the FDISK menu. If drive C is listed in the Display Partition Information, go to Check 3. If drive C is not listed, return to the FDISK menu and choose the option to create a DOS partition or a logical DOS drive on drive C.
  • Page 44 Troubleshooting Procedures 2.5.3 Procedure 3 Format Check (Not Used) The computer’s HDD is formatted using the DOS FORMAT program or the physical format program of the test program. To format the HDD, start with Check 1 below and perform the other steps as required. Format Check cannot be performed in Diagnostics Disk (CD) Refer to the DOS Manual for the operation of DOS.

  • Page 45: Keyboard Troubleshooting

    Troubleshooting Procedures If any of the connections are loose, reconnect firmly and repeat Procedure 1. If there is still an error, go to Check 2. 2. Check 2 The HDD/SSD may be damaged. Replace it with a new one following the instructions in Chapter 4, Replacement Procedures check the operation.

  • Page 46: Click Pad Troubleshooting

    Troubleshooting Procedures 2.7 Click Pad Troubleshooting To check if the computer’s Click Pad is malfunctioning or not, follow the troubleshooting procedures below as instructed. Procedure 1: Diagnostic Test Program Execution Check Procedure 2: Connector Check and Replacement Check 2.7.1 Procedure 1 Diagnostic Test Program Execution Check Execute the Click pad test in the Diagnostic Program.

  • Page 47: Display Troubleshooting

    Troubleshooting Procedures Check 3 System board may be faulty. Replace it with a new one following the instructions in Chapter 4, Replacement Procedures. 2.8 Display Troubleshooting This section describes how to determine if the computer’s display is functioning properly. Start with Procedure 1 and continue with the other procedures as instructed.

  • Page 48: Optical Disk Drive Troubleshooting

    Troubleshooting Procedures 2.8.4 Procedure 4 Replacement Check The LCD module and system board are connected to display circuits. Any of these components may be damaged. Refer to Chapter 4, Replacement Procedures. Check 1 Replace the LCD cable with a new one following the instructions in Chapter 4, and test the display Replacement Procedures...

  • Page 49: Lan Troubleshooting

    Troubleshooting Procedures Check 1 Make sure the SATA ODD is firmly connected to CN1810 on the system board. <System board> CN1810 SATA ODD If any of the connections are loose, reconnect firmly and repeat Procedure 1. If there is still an error, go to Check 2. Check 2 The SATA ODD may be damaged.

  • Page 50: Wireless Lan Or Bluetooth Troubleshooting

    Troubleshooting Procedures LAN Cable <System board> CN4050 Module Check 2 LAN cable may be faulty. Replace it with a new one. If the problem still occurs, perform Check 3. Check 3 LAN Module may be faulty. Replace it with a new one following the instruction in Chapter 4, Procedures.
  • Page 51 Troubleshooting Procedures WLAN antenna <System board> black CN2631/CN2630 white MAIN WLAN antenna cable In addition, the antenna used by Wireless LAN and Bluetooth function is common use. Any of the connections may be defective. Disassemble the computer following the steps described in Chapter 4, Procedures, and Replacement perform the following checks:...

  • Page 52: Sound Troubleshooting

    Troubleshooting Procedures 2.12 Sound Troubleshooting To check if the sound function is malfunctioning or not, follow the troubleshooting procedures below as instructed. Procedure 1: Diagnostic Test Program Execution Check Procedure 2: Connector Check Procedure 3: Replacement Check 2.12.1 Procedure 1 Diagnostic Test Program Execution Check This procedure checks if the Sound is working properly by using the function of Windows.

  • Page 53: Memory Media (Bridge Media) Slot Troubleshooting

    Troubleshooting Procedures Check 2 USB2.0(3.0)/Audio board may be faulty. Replace with a new one following the steps in Chapter 4, Procedures. If the Replacement problem still occurs, perform Check 2. Check 3 Speaker Right may be faulty. Replace it with a new one following the steps in Chapter 4, Procedures.

  • Page 54: Web Camera Troubleshooting

    Troubleshooting Procedures Check 1 SD/LED board and system board may be disconnected. Make sure the SD/LED board is firmly connected to CN9500 on the system board. If not, insert it firmly. If it is still not functioning properly, perform Check 2. Check 2 SD/LED board may be faulty.

  • Page 55: Hdmi Port Troubleshooting

    Troubleshooting Procedures Camera Module or the harness may be faulty. Replace it with a new one following the steps in Chapter 4, Replacement Procedures. If the problem still occurs, perform Check 3 Check 3 System board may be faulty. Replace it with a new one following the step in Chapter 4 Replacement Procedures.

  • Page 56: Fingerprint Sensor Troubleshooting

    Troubleshooting Procedures 2.15.2 Procedure 2 Connector Check and Replacement Check The connection of cables, boards and module may be defective. Otherwise, they may be faulty. Disassemble the computer following the steps described in Chapter 4 and perform the following checks: Check 1 Make sure HDMI cable is firmly connected to the HDMI out port on the system board.
  • Page 57 Troubleshooting Procedures 1. Fingerprint sensor 2.16.1 Procedure 1 Setting Windows sign-in password To use the fingerprint functions, registration of your fingers on “Windows Hello” after setting the Windows sign-in password and PIN. 2.16.2 Procedure 2 Registration of PIN and fingerprint 1.
  • Page 58 Troubleshooting Procedures 2.16.3 Procedure 3 Authentication of fingerprint 1. Turn on the computer to start up Windows. 2. Touch your registered finger on the fingerprint sensor and lift it. When your fingerprint is authenticated, you can sign-in Windows. If you fail this authentication continually five times, you can not use the fingerprint authentication.

  • Page 59: Chapter 3 Tests And Diagnostics

    Chapter 3 Tests and Diagnostics 3.1 Test program for maintenance The test program for maintenance consists of the following items: Check and update of ME FW information ■ Check of hardware information ■ Check and update of BIOS information ■ Check and update of EC/KBC information ■...

  • Page 60: How To Execute The Test Program

    Tests and Diagnostics 3.1.5 Diagnostic test programs There are programs to write the HW information and to check the function of HW components in the diagnostic test. You will need the following equipment to perform some of the diagnostic test programs. The diagnostic program for maintenance (USB Memory), ■...
  • Page 61 Tests and Diagnostics The Check and update of ME FW information Procedure 1: The ME FW version is checked and if the update is needed, the following message is displayed. Do you want to update ME-FW(AMT)?(Y)? Do you want to update ME-FW(NonAMT)?(Y)? When the message above is displayed, press Y.
  • Page 62 Tests and Diagnostics Procedure 4: Check and update of EC/KBC information The EC/KBC version is checked and if it is not the latest one, the message to confirm if update is needed or not. The current version is displayed at upper part of the display. Does it update EC/KBC (Vx.xx->Vx.xx)? (Y or N), or press [Enter] (Selection=Y)? When the message above appears, pressing ENTER will...

  • Page 63: Entry Of The Dmi Information

    Tests and Diagnostics After the work for procedures 1- 4 is completed, the following test program menu (Top Menu) is displayed. (The menu below shows an example of screen.) Select Menu ( [NUm] or[↑][↓] – → [Enter] To start the DMI Entry Utility, press 1 and Enter. To start the Heatrun Test, press 2 and Enter.

  • Page 64: Heatrun Test

    Tests and Diagnostics Input the information one by one. (If you have not replaced the system board, the DMI information should not be changed.) Model Name (e.g. PORTEGE Z830) ■ Version Number (e.g. XF82BFGCTL7AA21) ■ Serial number (e.g. 7G121732H) ■ Model Number (e.g.

  • Page 65: Main Test Menu

    Tests and Diagnostics 3. Sequential Read Test To execute this test, select 2 from the test program menu (Top Menu), and press Enter. Explanation of each test: 1. Main Memory test Refer to Subtest 1 of 3.6 Memory Test 2. V-RAM Memory test Refer to Subtest 2 of 3.6 Memory Test 3.
  • Page 66 Tests and Diagnostics TEST TEST SUBTEST SUBTEST NAME NAME MEMORY Main Memory Test VRAM Memory Test HDD/SSD Sequential Read Test Test Partial Read Test Address Jump Test Address Uniqueness Test Specify Address Test Keyboard Test 1 Key-code Test Touch Pad Test LCD Panel LCD Panel Test Test...

  • Page 67: Memory Test

    Tests and Diagnostics Select Yes: if any error occurs during the test, the test is suspended and key input is required. Enter C ……Restarts the test execution Enter E…….Ends the test. The program returns to the screen to select Error Stop and Test Loop item selection. Select No: though any error occurs during the test, the test is continued.

  • Page 68: Hard Disk (&Ssd) Test

    Tests and Diagnostics If the test data and read data is not the same at comparing, this test displays the message “Data Compare error “and writes the information to the text file (errorlog.txt) as an error log. As for the details of the error log, refer to 3.13 Log utility. Subtest 2 [V-RAM Memory test] This test sets the display mode to the maximum resolution.
  • Page 69 Tests and Diagnostics T&D Test Area T&D Test Area T&D Test Area Subtest 3 [Address Jump Test] This test writes the test data (AAAAAAAAh) to 1. LBA 63 (by 512-byte) 2. LBA 22 (=63 - 41) (by 512-byte) 3. LBA 86 (=22 + 64) (by 512-byte) 4.

  • Page 70: Keyboard Test

    Tests and Diagnostics This test writes the test data up to the last address. Then it reads out the data to compare. The number of passes will be 0 (default value) unless comparing of the whole data is completed. At the beginning of the test in the second round, the number would become 1 (when Test Loop Yes is selected.

  • Page 71: Lcd Panel Test

    Tests and Diagnostics 3.9 LCD Panel Test To execute the LCD Panel Test, select 4 from the DIAGNOSTIC TEST Menu (Main Test Menu), press Enter and follow the directions on the screen. Move the highlight bar to the subtest you want to execute and press Enter.

  • Page 72: Fan Test

    Tests and Diagnostics When this test program is selected, the following message appears. The test starts by pressing ENTER. The test gets the charging status of the mounted battery pack and displays the message. To back to the main menu screen, press ENTER. 3.11 Fan Test To execute the FAN Test, select 6 from the test program menu (Top Menu), press Enter and follow the directions on the screen.

  • Page 73: Log Utility

    Tests and Diagnostics Step 3: Press ENTER. When the message is changed, rotate the PC counterclockwise by 90 degrees as the right side of the PC faces up. Step 4: Press ENTER. When the message is changed, rotate the PC counterclockwise by 90 degrees as the front of the PC faces up.

  • Page 74: Lcd Gamma Correction

    Tests and Diagnostics Write ..Write value (Memory Test/HDD Test) · Read ... Read value (Memory Test/HDD Test/ Battery Charge Test) · To clear the log information, press C. To back to the main menu screen, press ENTER. 3.14 LCD Gamma correction To execute the LCD Gamma Correction Utility, select 7 from the test program menu (Top Menu), press Enter and follow the directions on the screen.
  • Page 75 Tests and Diagnostics If any errors occurred, “FAIL” will be displayed. Select “Close” button at the lower left to back to the start screen. Any errors occurred during this program will be registered in the log. To check the content, select “LogInfo.” button. As for the details of the log, refer to section.

  • Page 76: Wireless Module Test

    PC system information. On this model, a combo module which has both wireless LAN and Bluetooth function is mounted. <How to display PC system information screen> 1) Click Start button. 2) Click [dynabookサービスステーション(dynabook service station]-[システム情報(System information)]. Check the content of “ネットワーク(Netwrok)”. If “Wireless**”...

  • Page 77: Sound Test

    Tests and Diagnostics Click the icon. If the computer can find any AP (Access Point), the network names like below will appear. It shows the antenna cables are surely connected to the wireless module. If the antenna cables are not connected to the wireless module or no available AP is found, the following icon will appear.
  • Page 78 Tests and Diagnostics < PS59* model > Main menu System Time (System time) ■ System Date (System time) ■ CPU Type ■ CPU Speed ■ HDD/SSD ■ Total Memory Size ■ System BIOS Version ■ EC Version ■ Language ■ Security menu BIOS Password ■...
  • Page 79 Tests and Diagnostics Power Management menu Wake-up on LAN ■ Wake-up on LAN on Battery ■ Wake-up on Keyboard ■ Critical Battery Wake-up ■ Panel Open – Power On ■ Power on by AC ■ Dynamic CPU Frequency Mode ■ Core Multi-Processing ■...
  • Page 80 Tests and Diagnostics Advanced menu Virtualization Technology ■ Trusted Execution Technology ■ SW Guard Extensions (SGX) ■ Select Owner EPOCH input type ■ Beep Sound ■ Sleep and charge ■ System ON CDP Charge Mode ■ USB Power in Off State ■...
  • Page 81 Tests and Diagnostics CPU Speed ■ HDD/SSD ■ Total Memory Size ■ System BIOS Version ■ EC Version ■ AMT Setup Prompt (*2) ■ Language ■ Security menu BIOS Password ■ User ■ Supervisor ■ BIOS Access Rights (*1) ■ HDD/SSD Password (*2) ■...
  • Page 82 Tests and Diagnostics Power Management menu Wake-up on LAN ■ Wake-up on LAN on Battery ■ Wake on Keyboard ■ Critical Battery Wake-up ■ Panel Open – Power On ■ Power on by AC ■ Intel Turbo Boost Technology (*2) ■...
  • Page 83 Tests and Diagnostics ■ Start HDD/SSD Test HDD/SSD Test Mode ■ Start Memory Test ■ Boot menu Priority ■ Boot Option #1 ■ Boot Option #2 ■ Boot Option #3 ■ Boot Option #4 ■ Priority for devices ■ Exit menu Exit Saving Changes ■...
  • Page 84 Tests and Diagnostics Power Management menu screen Advanced menu screen Maintenance Manual (960-922) 3-26...
  • Page 85 Tests and Diagnostics Exit menu screen Main menu screen Security menu screen Maintenance Manual (960-922) 3-27...
  • Page 86 Tests and Diagnostics Power Management menu screen Advanced menu screen Boot menu screen Exit menu screen Maintenance Manual (960-922) 3-28...
  • Page 87 Tests and Diagnostics Moving Within the SETUP Menu and Changing Values 1. Press ← and → to move between the two columns. Press ↑ and ↓ to move between items in a column. 2. Press the [Enter] Key to change the value. Accepting Changes and Exiting the SETUP Window 1.

  • Page 88: Battery Off Mode Setting Tool

    Tests and Diagnostics 3.18 Battery Off mode setting tool 3.18.1 Outline “Battery Off mode” state will be set before returning the PC to the user. Check the [Advanced] – [System Configuration] in the BIOS setup screen to set the “Battery Off mode” state. When [Battery disconnect] item is shown, connect the AC adapter and execute it.

  • Page 89: Sensor Calibration Tool (Not Used)

    Tests and Diagnostics Vx.xx Select test Menu [1] Set – Battery Off Mode [0] Exit ====================================== Input key of 1 or 0. Step 4: When you press 1, the Battery Off mode should be set and display the result. When the result shows “OK”, the Battery Off mode should be set surely. Press any key to turn off the PC.
  • Page 90 Tests and Diagnostics The following explains how to operate the tool. 3.19.2 Preparation Decompress the following file (***.iso) with any application software. AltairME30SensorCalibrationToolV***.iso ■ Step 1 Select iso file and right-click to execute “Mount”. A virtual ODD is mounted and files are shown. Step 2 Copy all the files to the root drive of a USB memory.
  • Page 91 Tests and Diagnostics Procedure 4: Remove the USB memory. Procedure 5: Change the PC to be tested into Tablet style and lay it on the horizontal and stable table as the screen faces up. Procedure 6: Touch “Start Test Now “ button to start the test. ■...
  • Page 92 Tests and Diagnostics When “STEP 1 XXXXXX” is displayed, go to the next step. Step 2: Make the side with the power button bottom side slowly. When “STEP 2 XXXXXX” is displayed, go to the next step. Step 3: Rotate the PC 90 degrees counterclockwise slowly. When “STEP 3 XXXXXX”...
  • Page 93 Tests and Diagnostics When “STEP 4 XXXXXX” is displayed, the Acceleration calibration test is completed. 3.19.4 Result [PASS] If this test ends successfully, “PASS” is displayed. Tap “OK” button to back to the start screen. [FAIL] If any problem occurred, “FAIL“ will be displayed. Tap “OK”...
  • Page 94 Tests and Diagnostics 3.19.5 Log < To check the log contents without save > Select "Log Info." to display the “Log Information Display”. < To save the log contents in an external memory device > The log contents can’t be saved in the internal disk to keep the user files. 1.
  • Page 95 Tests and Diagnostics The log file named “wintndx.log” or “wintndx64.log” will be output to (saved in) the specified folder. 3.19.6 How to terminate this tool Select “Close” on the tart screen. The computer is powered off. Maintenance Manual (960-922) 3-37...

  • Page 96: Chapter 4 Replacement Procedures

    Chapter 4 Replacement Procedures This chapter describes the procedure for removing and replacing the field replaceable units (FRUs) in the PC. It may not be necessary to remove all the FRUs in order to replace one. The chart below provides a guide as to which other FRUs must be removed before a particular FRU can be removed.

  • Page 97: Table 4-1 The Case For The Following Example

    Replacement Procedures Table 4-1 the case for the following example 4.10 Battery pack 4.11 Cover assembly and base assembly Base Cover 4.25 LCD assembly Maintenance Manual (960-922)

  • Page 98: Safety Precautions

    Please read the following safety instructions before disassembling the computer and always follow the instructions while working on the computer. 1. Always use the genuine battery that is authorized by Dynabook or compatible with the unit. Since other battery packs have different specifications, they may be incompatible with the unit, and may burst or explode.

  • Page 99: Before You Begin

    4. If you use AC power, be sure to use the cable that came with the computer or one recommended by Dynabook. 5. Make sure that all replacement components meet the specifications for the computer and that all cables and connectors are securely fastened, in order to avoid the risk of electric shock.

  • Page 100: Disassembly Procedure

    Replacement Procedures 8. When re-assembling, ensure that you use the correct screws and fit parts in the correct position. Screw sizes are noted in the text and figures. 9. As all parts have sharp edges and corners, take care not to cut yourself. 10.

  • Page 101: Tools And Equipment

    Replacement Procedures Take note of the following general points when assembling the computer. Take your time and follow the instructions carefully. Hurrying the ■ assembly work will only introduce new problems. Check that all cables and connectors are securely connected. ■...

  • Page 102: Grip Color

    Replacement Procedures Dynabook recommends that you use an electric screw driver for quick and easy operations. (2mm) 0.167 N•m (1.7 kgf cm) ■ M2.5 (2.5mm) 0.294 N•m (3.0 kgf cm) (When, securing the HDD and ■ HDD holder) (3mm) 0.549 N•m (5.6 kgf cm) ■...

  • Page 103: Screw Notation

    Replacement Procedures 4.8 Screw Notation To make maintenance of the computer easier, markings of the kinds of the screws including the types and lengths of the screws are indicated on the computer body. Screw type + Screw length (mm) Screw shape B: Bind screw F: Flat head screw S: Super thin head screw...

  • Page 104: Battery Pack

    Replacement Procedures 4.9.2 Removing the Memory media To remove memory media, follow the steps as detailed below. 1. Open the Safely Remove Hardware and Eject Media icon on the Windows Taskbar. 2. Select memory media. 3. Push the memory media until you hear a click to partially release it. 4.

  • Page 105: Cover Assembly And Base Assembly

    Dispose always the used battery pack in accordance with the laws and ordinances of your local authority. Use only the batteries approved by Dynabook. Check the battery’s terminals visually. If they are dirty, wipe them clean with a dry cloth.

  • Page 106: Figure 4-5 Removing The Base Assembly (1)

    Replacement Procedures The colour of screw might vary depending on the model's colour you purchased. White or Gold: F2.5 x 6CT Red or Black : F2.5 x 6BT White or Gold: F2.5 x 8CT Red or Black : F2.5 x 8BT Figure 4-5 Removing the base assembly (1) 15 16 4.

  • Page 107: Figure 4-6 Removing The Base Assembly (2)

    Replacement Procedures Figure 4-6 Removing the base assembly (2) Base assembly Cover assembly Latches Maintenance Manual (960-922) 4-12...
  • Page 108 Replacement Procedures 4.11.2 Installing the Base assembly When replacing the Base Assembly for HDD model, stick a new INSU CUSHION on the new Base Assembly in place. To install the base assembly, follow the steps below. 1. Set the cover assembly on the base assembly while securing the latches.

  • Page 109: Battery Lock/Battery Release Latch

    Replacement Procedures 4.12 Battery lock/Battery release latch 4.12.1 Removing the Battery lock/ Battery release latch To remove the battery lock, follow the steps below. 1. Remove the battery lock/battery release latch from the slot while pushing latches inside to release them. Figure 4-7 Removing the Battery lock/ Battery release latch Spring Battery release...

  • Page 110: Figure 4-8 Rtc Battery And Harness

    Replacement Procedures Figure 4-8 RTC battery and harness RTC battery 4.13.1 Removing the RTC battery To remove the RTC battery, follow the steps below. 1. Disconnect the USB2.0(3.0)/Audio board FFC from the connector CN9530 on the system board (FTL5SY*/F4L7SY*) so that the RTC battery is visible. 2.

  • Page 111: Optical Disk Drive

    Replacement Procedures 4.13.2 Installing the RTC battery To install the RTC battery, follow the steps below. 1. Place and stick the RTC battery (with the RTC MYLAR) to the cover assembly. 2. Connect the RTC battery harness to the connector CN8020 on the system board (FTL5SY*/F4L7SY*).

  • Page 112: Figure 4-10 Removing The Optical Disk Drive Assembly (1)

    Replacement Procedures When the optical disk inside the optical disk drive can not be ejected because of some failure, open the disc tray by inserting a slender object (about 15 mm) such as a straightened paper clip into the eject hole near the eject button.

  • Page 113: Hdd/Ssd

    Replacement Procedures 4.14.2 Installing the Optical disk drive To install the Optical disk drive, follow the steps below. 1. When installing a new optical disk drive, set a new ODD bezel to the optical disk drive while securing the latch. 2.

  • Page 114: Figure 4-13 Removing The Hdd/Ssd (2)

    Replacement Procedures Figure 4-13 Removing the HDD/SSD (2) 3. Remove the HDD FFC from the HDD/SSD. Figure 4-14 Removing the HDD/SSD (3) HDD FFC 4. Remove the SSD from the SSD Holder. Maintenance Manual (960-922) 4-19...

  • Page 115: Figure 4-15 Removing The Hdd/Ssd (4)

    Replacement Procedures Figure 4-15 Removing the HDD/SSD (4) 4.15.2 Installing the HDD/SSD To install the HDD/SSD, follow the steps below. To avoid damage, always hold the HDD/SSD only by its sides. To prevent the HDD/SSD from being distorted when installing the HDD/SSD pack into the computer, do not press the center of the HDD/SSD pack.

  • Page 116: Memory Module

    Replacement Procedures 4.16 Memory module 4.16.1 Removing the Memory module To remove the memory module, follow the steps as detailed below: Do not touch the connectors on the memory module or on the computer. Dust or stains on the connectors may cause memory access problems. Never press hard or bend the memory module.

  • Page 117: Figure 4-17 Seating The Memory Module

    Replacement Procedures 4.16.2 Installing the Memory module To install a memory module, follow the steps as detailed below: 1. Align the notch of the memory module with that of the memory slot and gently insert the module into the slot at about a 30 degree angle before holding it down until the latches on either side snap into place.

  • Page 118: Usb2.0(3.0)&Audio Board

    Replacement Procedures 4.17 USB2.0(3.0)&Audio board 4.17.1 Removing the USB2.0(3.0) & Audio board (FTL5U2*/F4L7A3*) To remove the board, follow the steps below. 1. Disconnect USB2.0(3.0)/Audio board FFC from the connector CN9530 on the system board (FTL5SY*/F4L7SY*). Figure 4-18 Removing the USB 2.0(3.0)/Audio board (1) USB2.0(3.0)/ Audio board FFC CN9530...
  • Page 119 Replacement Procedures (PS59* model) Separate the USB2.0 & Audio board (FTL5U2*) while releasing the latch. Figure 4-20 Removing the USB 2.0(3.0)/Audio board (3) Latch 4. Disconnect the USB2.0(3.0)/Audio board FFC from the connector CN9721 on the USB2.0(3.0)&Audio board (FTL5U2*/F4L7A3*) disconnect the FPC from CN9830 on the back of the USB3.0/Audio board (F4L7A3*) (PS59R model).
  • Page 120 Replacement Procedures 4.9.1 Installing the USB 2.0(3.0) &Audio board (PS59* model) When replacing the USB2.0 &Audio board with a new one, stick a new sponge tape (GM9041325111) in place. To install the USB2.0(3.0) &Audio board, follow the steps below. 1. Connect the &Audio board FFC to the connector USB2.0(3.0) CN9721 on the USB2.0(3.0)/Audio board...

  • Page 121: Speakers

    Replacement Procedures 4.18 Speakers 4.18.1 Removing the speakers To remove the speakers, follow the steps below. 1. Disconnect the speaker harness from the connectors CN6330 and CN6331 on the system board. 2. Remove the following screws and then open the sponge tape. 3.

  • Page 122: Sd/Led Board (Ftl5Le*/F4L7Le*)

    Replacement Procedures 4.19 SD/LED board (FTL5LE*/F4L7LE*) /F4L7LE* 4.19.1 Removing the SD/LED board (FTL5LE* To remove the board, follow the steps below. 1. Disconnect the SD/LED board (FTL5LE*) FFC from the connector CN9500 on the system board. Figure 4-23 Removing the SD/LED board (1) SD/LED board CN9500 SD/LED board...

  • Page 123: Wireless Lan Card

    Replacement Procedures Figure 4-25 Removing the SD/LED board (3) CN9600 4.19.2 Installing the SD/LED board To install the SD/LED board, follow the steps below. 1. Connect the SD/LED board (FTL5LE*/F4L7LE*) FFC to the connector CN9600 on the SD/LED board. 2. Set the SD/LED board in place and secure it with the screws. 3.

  • Page 124: Figure 4-26 Removing The Wireless Lan Card (1)

    Replacement Procedures To remove the Wireless LAN card, follow the steps below. 1. Disconnect the Wireless LAN antenna cables from the connector on the Wireless LAN card (black cable from “AUX or “1” and white cable from “Main” or “2”). Figure 4-26 Removing the wireless LAN card (1) Main (2) AUX (1)

  • Page 125: Fan

    Replacement Procedures 4. Arrange the Wireless LAN antenna cables to the guides as below. Figure 4-28 Arrange Wireless LAN antenna cable Guides WLAN antenna cables 5. Connect the Wireless LAN antenna cables to the connectors (black cable to “AUX” or “1” and white cable to “Main” or “2”) on the Wireless LAN card.

  • Page 126: Figure 4-30 Removing The Dc Fan (2)

    Replacement Procedures Figure 4-30 Removing the DC Fan (2) CN5390 3. Disconnect the DC-IN harness from the connector CN8001 on the system board. Release the DC-IN harness from the guides on the fan. Figure 4-31 Removing the DC Fan (3) CN8001 DC-IN harness 4.

  • Page 127: Figure 4-32 Removing The Dc Fan (4)

    Replacement Procedures Figure 4-32 Removing the DC Fan (4) F2.5 x 4.5CT 4.21.2 Installing the DC Fan To install the DC Fan, follow the steps below. 1. Set the fan in place and secure it with the screw. 2. Connect the fan harness to the connector CN3380 on the system board (FTL5SY*/F4L7SY*).

  • Page 128: Fin

    Replacement Procedures Figure 4-34 Arrange LCD harness(for HD Web Camera Model) Guides Figure 4-35 Arrange LCD harness(for IR Camera Model) 4.22 Fin 4.22.1 Removing the Fin To remove the fin, follow the steps below. 1. Remove the following screws and fin. Maintenance Manual (960-922) 4-33...

  • Page 129: Figure 4-36 Removing The Fin

    Replacement Procedures Figure 4-36 Removing the fin M2 x 2.5C BIND HEAD When removing the fin, be sure to remove the screws in the reverse order of the number marked on the fin. 4.22.2 Installing the fin To install the fin, follow the steps below. 1.

  • Page 130: System Board/Lan Module/Power Button Board

    Replacement Procedures 4.23 System board/LAN Module/Power Button board 1. If replacing with a new system board, update the DMI information as described in Chapter 3, Diagnostics. Also update with the Tests and latest BIOS and EC/KBC as described in Appendix G, BIOS Rewrite Procedures, and Appendix H, EC/KBC Rewrite...

  • Page 131: Figure 4-37 Removing The System Board (1)

    Replacement Procedures /LAN Module/Power button 4.23.1 Removing the System board board To remove the system board, follow the steps below. 1. Stand the LCD cover and remove the screws as the following: Figure 4-37 Removing the system board (1) LCD cover M2.5 x 6CT FLAT HEAD 2.

  • Page 132: Figure 4-38 Removing The System Board (2)

    Replacement Procedures Figure 4-38 Removing the system board (2) DC-IN jack 3. Take out the LAN Module from the slot, and then release the LAN harness from the guides, disconnect the LAN harness from the connector CN4050 on the system board (FTL5SY*/F4L7SY*). Figure 4-39 Removing the system board (3) CN4050 LAN harness...

  • Page 133: Figure 4-40 Removing The System Board (5)

    Replacement Procedures Figure 4-40 Removing the system board (5) CN9510 CN9550 CN3260 5. Remove the following the screws and system board, and then lift up the system board carefully. Figure 4-41 Removing the system board (6) M2.5 x 4.5CT 6. Disconnect the Power Button board harness from the connector CN9621 on the Power Button board (FTL5PW*/F4L7PW*).

  • Page 134: Figure 4-42 Removing The System Board (7)

    Replacement Procedures Figure 4-42 Removing the system board (7) CN9621 Power Button board harness Power Button board 7. Disconnect the Power Button board harness from the connector CN9711 on the system board. Figure 4-43 Removing the system board (8) CN9711 Power Button board harness 8.

  • Page 135: Figure 4-44 Removing The System Board (10)

    Replacement Procedures Figure 4-44 Removing the system board (10) Power Button board F2.5 x 4.5CT /LAN Module/Power button 4.23.2 Installing the System board board To install the system board, follow the steps below. 1. Set the Power Button board (FTL5PW*/F4L7PW*) in place and secure it with a screw.

  • Page 136: Keyboard And Click Pad

    Replacement Procedures 6. Connect the LAN harness to the connector CN4050 on the system board. Set the LAN Module in slot, and arrange the LAN Module harness. Be sure not to cover the connector of the Power button board while arranging the LAN Module harness. Figure 4-46 Arrange the LAN harness 7.

  • Page 137: Lcd Assembly

    Replacement Procedures 4.25 LCD assembly 4.25.1 Removing the LCD unit To remove the LCD unit, follow the steps below. 1. Remove the hinge caps while releasing the latches. Figure 4-47 Removing the LCD unit (1) hinge hinge 2. Remove the following screws securing the LCD mask, and then remove the LCD mask while releasing the latches.

  • Page 138: Figure 4-49 Removing The Lcd Unit (3)

    Replacement Procedures Be sure to release the latches follow the arrow order on below figure. 3. Remove the following screws and take out the LCD unit. Be careful that the LCD harness is connected to the connector on the back of the LCD unit. Figure 4-49 Removing the LCD unit (3) S-THIN 2 x 3CS 4.

  • Page 139: Figure 4-50 Removing The Lcd Unit (4)

    Replacement Procedures Figure 4-50 Removing the LCD unit (4) 5. Peel the pull tape and disconnect the LCD harness from the connector on the LCD unit. Maintenance Manual (960-922) 4-44...

  • Page 140: Figure 4-51 Removing The Lcd Unit (5)

    Replacement Procedures Figure 4-51 Removing the LCD unit (5) Open Lock 4.25.2 Installing the LCD unit To install the LCD unit, follow the steps below. 1. Connect the LCD harness to the connector on the LCD unit and secure it with the pull tape and glass tape. When connect the LCD harness, make sure to connect the right and left side at the same time as shown in the figure below.

  • Page 141: Figure 4-52 Installing The Lcd Unit (1)

    Replacement Procedures Figure 4-52 Installing the LCD unit (1) Peel off the separators on the bound & detach tapes, and then set the LCD unit in place. Figure 4-53 Installing the LCD unit (2) 7. Set the left & right hinges. Maintenance Manual (960-922) 4-46...
  • Page 142 Replacement Procedures ■ Be sure to engaging the latches follow the arrow order on below figure. When setting the LCD mask, be careful not to pinch the cables. ■ When replacing the LCD Cover for FHD LCD model, stick a new Al tape on the new cover in place.
  • Page 143 Replacement Procedures When replacing the LCD mask for FHD LCD model, stick two new CU tapes in layers on the LCD mask in place. 9. Set the hinge cap while engaging the latches. Maintenance Manual (960-922) 4-48...

  • Page 144: Camera Module/Wireless Antennas

    Replacement Procedures 4.26 Camera module/Wireless antennas 4.26.1 Removing the Camera module To remove the camera module, follow the steps below. 1. Remove the following screws to release the left hinge. Figure 4-54 Removing the camera module (1) M2.5 x 6B FLAT HEAD S-THIN 2.5 x 4BS S-THIN 2 x 3CS Left hinge...

  • Page 145: Figure 4-55 Removing The Camera Module (2)

    Replacement Procedures Figure 4-55 Removing the camera module (2) M2.5 x 6B FLAT HEAD S-THIN 2.5 x 4BS S-THIN 2 x 3CS Right hinge 3. Disconnect the camera harness from the connector on the camera module. 4. Remove the camera module from the slot of the LCD cover. 5.

  • Page 146: Figure 4-56 Removing The Camera Module (For Hd Web Camera Model)(3)

    Replacement Procedures Figure 4-56 Removing the camera module (for HD Web Camera Model)(3) HD Camera module Figure 4-57 Removing the camera module (for IR Camera Model)(4) IR Camera module Do not reuse the removed camera module. Be sure to use new camera module.

  • Page 147: Figure 4-58 Arrange Wlan Antenna Cables(For Hd Web Camera Model)

    Replacement Procedures 4.26.2 Removing the Wireless antennas To remove the wireless antenna, follow the steps below. 1. Peel off the wireless LAN antennas from the LCD cover. Do not reuse the removed wireless LAN antennas. Be sure to use new wireless LAN antenna.

  • Page 148: Figure 4-59 Arrange Wlan Antenna Cables(For Ir Camera Model)

    Replacement Procedures Figure 4-59 Arrange WLAN antenna cables(for IR Camera Model) 4.26.4 Installing the Camera module To install the camera module, follow the steps below. 1. Peel off a protection sheet from a new camera module. 2. Stick the camera cushion and square cushion on the LCD mask. 3.
  • Page 149 Replacement Procedures 5. Set the right hinge in place and secure it with the screws. 6. Set the left hinge in place and secure it with the screws. Maintenance Manual (960-922) 4-54...

  • Page 150: Appendix A Handling The Lcd Module

    Appendix A Handling the LCD Module A.1 Precautions for handling the LCD module The LCD module can be easily damaged during assembly or disassembly. Observe the following precautions when handling the LCD module: 1. When installing the LCD module in the LCD cover, be sure to seat it so that it is properly aligned and maximum visibility of the display is maintained.
  • Page 151 Handling the LCD Module 3. If the panel’s surface gets dirty, wipe it with cotton or a soft cloth. If it is still dirty, try breathing on the surface to create a light condensate and wipe it again. If the surface is very dirty, we recommend a CRT cleaning agent. Apply the agent to a cloth and then wipe the panel’s surface.
  • Page 152 Handling the LCD Module 6. CMOS-LSI circuits are used in the module, so guard against damage from electrostatic discharge. Be sure to wear a wrist or ankle ground when handling the module. 7. Do not expose the module to direct sunlight or strong ultraviolet rays for long periods.
  • Page 153 Handling the LCD Module 9. Do not disassemble the LCD module. Disassembly can cause malfunctions. 10. If you transport the module, do not use packing material that contains epoxy resin (amine) or silicon glue (alcohol or oxide). These materials can release gas that can damage the panel’s polarization. Maintenance Manual (960-922)

  • Page 154: Appendix B Board Layout

    Appendix B Board Layout Rev.02 B.1 SYSTEM board (FTL5SY*/F4L7SY*) Front View Figure B-1 System board (FTL5SY*/F4L7SY*) layout (front) CN8021 CN9711 CN1810 CN5690 CN4800/CN4811 CN4801 Table B-1 System board (FTL5SY*/F4L7SY*) connectors and ICs (front) Number Name SATA ODD interface connector CN1810 Power Button board interface connector CN9711 Battery interface connector...

  • Page 155: System Board (Ftl5Sy*/F4L7Sy*) Back View

    Board Layout B.2 SYSTEM board (FTL5SY*/F4L7SY*) Back View Figure B-2 System board (FTL5SY*/F4L7SY*) layout (back) CN2630/ CN6330 CN2631 CN8001 CN4050 CN5390 CN3380 CN1400 CN1410 CN1920 CN9510 CN9550 CN8020 CN1900 CN9530 CN6331 CN3260 CN9500 CN9710 Table B-2 System board (FTL5SY*/F4L7SY*) connectors and ICs (back) Number Name LCD+Web Camera interface connector...

  • Page 156: Usb 2.0/Audio Board (Ftl5U2*/F4L7A3*) Front View

    Board Layout Memory A connector CN1400 Memory B connector CN1410 DC-IN interface connector CN8001 USB3.0/Audio board (F4L7A3*) interface connector CN9710 B.3 USB 2.0(3.0)/Audio board (FTL5U2*/F4L7A3*) Front View Figure B-3 USB2.0(3.0)/Audio board (FTL5U2*/F4L7A3*) layout (front) CN4941/CN4942 CN9721 CN4942/CN4941 J6451 Table B-3 USB2.0(3.0)/Audio board (FTL5U2*/F4L7A3*) connectors (front) Number Name USB 2.0...

  • Page 157: Usb2.0/Audio Board (Ftl5U2*) Back View

    Board Layout B.4 USB2.0/Audio board (FTL5U2*) Back View Figure B-4 USB2.0/Audio board (FTL5U2*) layout (back) USB3.0/Audio board (F4L7A3*) Back View Figure B-5 USB3.0/Audio board (F4L7A3*) layout (back) CN9830 Table B-4 USB3.0/Audio board (F4L7A3*) connectors (back) Number Name SYSTEM board (F4L7SY*) interface connector CN9830 Maintenance Manual (960-922)

  • Page 158: Power Button Board (Ftl5Pw*/F4L7Pw*) Front View

    Board Layout Rev.02 B.6 Power Button board (FTL5PW*/F4L7PW*) Front View Figure B-6 Power Button board (FTL5PW*/F4L7PW*) layout (front) B.7 Power Button board (FTL5PW*/F4L7PW*) Back View Figure B-7 Power Button board (FTL5PW*/F4L7PW*) layout (back) CN9621 Table B-5 Power Button board (FTL5PW*/F4L7PW*) connectors (back) Number Name SYSTEM board (FTL5SY*/F4L7SY*) interface...

  • Page 159: Sd/Led Board (Ftl5Le*/F4L7Le*) Front View

    Board Layout B.8 SD/LED board (FTL5LE*/F4L7LE*) Front View Figure B-8 SD/LED board (FTL5LE*/F4L7LE*) layout (front) CN9600 Table B-6 SD/LED board (FTL5LE*/F4L7LE*) connectors and ICs (front) Number Name SYSTEM board (FTL5SY*/F4L7SY*) interface CN9600 connector B.9 SD/LED board (FTL5LE*/F4L7LE*) Back View Figure B-9 SD/LED board (FTL5LE*/F4L7LE*) layout (back) IS2140 Table B-7 SD/LED board (FTL5LE*/F4L7LE*) connectors and ICs (back) Number...

  • Page 160: Pin Assignments

    Appendix C Pin Assignments C.1 SYSTEM board (FTL5SY*/F4L7SY*) C.1.1 CN1400 Memory A connector (260-pin) Table C-1 CN1400 Memory A connector (260-pin) Maintenance Manual (960-922)
  • Page 161 Pin Assignments Pin No. Signal Name Pin No. Signal Name MSMRST-B1N 1R2-B1V XACK0-B1N 1R2-B1V XACK0-B1P 1R2-B1V XACK1-B1N 1R2-B1V XACK1-B1P 1R2-B1V ACKE0-B1P 1R2-B1V ACKE1-B1P 1R2-B1V AODT0-B1P 1R2-B1V AODT1-B1P 1R2-B1V ACS0-B1N ADQS6-B1N ACS1-B1N ADQS6-B1P ADQS5-B1N ADQS5-B1P AACT-B1N ADQS2-B1N ABG0-B1P ADQS2-B1P ABG1-B1P ADQS0-B1N AMA00-B1P ADQS0-B1P AMA01-B1P...
  • Page 162 Pin Assignments Pin No. Signal Name Pin No. Signal Name ADQ53-B1P ADQ33-B1P ADQ46-B1P ADQ37-B1P ADQ43-B1P ADQ35-B1P ADQ44-B1P ADQ38-B1P ADQ41-B1P ADQ32-B1P ADQ47-B1P ADQ36-B1P ADQ42-B1P ADQ29-B1P ADQ40-B1P ADQ24-B1P ADQ45-B1P ADQ25-B1P ADQ19-B1P ADQ30-B1P ADQ18-B1P ADQ28-B1P ADQ21-B1P ADQ27-B1P ADQ17-B1P ADQ26-B1P ADQ23-B1P ADQ31-B1P ADQ22-B1P ADQ13-B1P ADQ20-B1P ADQ10-B1P ADQ16-B1P...
  • Page 163 Pin Assignments Pin No. Signal Name Pin No. Signal Name Maintenance Manual (960-922)
  • Page 164 Pin Assignments Pin No. Signal Name Pin No. Signal Name 1R2-B1V 1R2-B1V 1R2-B1V 1R2-B1V 1R2-B1V 1R2-B1V 1R2-B1V 1R2-B1V 1R2-B1V 1R2-B1V 1R2-B1V 1R2-B1V 1R2-B1V 1R2-B1V 1R2-B1V 1R2-B1V AVREFCA-B0V 2R5-B2V 2R5-B2V 1R2-B1V 1R2-B1V SMBCLK-P3P 1R2-B1V SMBDAT-P3P 0R6-P0V SIG26375 Maintenance Manual (960-922)

  • Page 165: Table C-2 Cn1410 Memory B Connector (260-Pin

    Pin Assignments C.1.2 CN1410 Memory B connector (260-pin) Table C-2 CN1410 Memory B connector (260-pin) Pin No. Signal Name Pin No. Signal Name MSMRST-B1N 1R2-B1V XBCK0-B1N 1R2-B1V XBCK0-B1P 1R2-B1V XBCK1-B1N 1R2-B1V XBCK1-B1P 1R2-B1V BCKE0-B1P 1R2-B1V BCKE1-B1P 1R2-B1V BODT0-B1P 1R2-B1V BODT1-B1P 1R2-B1V BCS0-B1N BDQS7-B1N...
  • Page 166 Pin Assignments Pin No. Signal Name Pin No. Signal Name BDQ56-B1P BDQ41-B1P BDQ33-B1P BDQ40-B1P BDQ39-B1P BDQ42-B1P BDQ36-B1P BDQ47-B1P BDQ32-B1P BDQ44-B1P BDQ35-B1P BDQ45-B1P BDQ38-B1P BDQ18-B1P BDQ37-B1P BDQ22-B1P BDQ34-B1P BDQ17-B1P BDQ02-B1P BDQ21-B1P BDQ05-B1P BDQ23-B1P BDQ03-B1P BDQ19-B1P BDQ01-B1P BDQ16-B1P BDQ04-B1P BDQ20-B1P BDQ00-B1P BDQ14-B1P BDQ07-B1P BDQ09-B1P BDQ06-B1P...
  • Page 167 Pin Assignments Pin No. Signal Name Pin No. Signal Name Maintenance Manual (960-922)
  • Page 168 Pin Assignments Pin No. Signal Name Pin No. Signal Name 1R2-B1V 1R2-B1V 1R2-B1V 1R2-B1V 1R2-B1V 1R2-B1V 1R2-B1V 1R2-B1V 1R2-B1V 1R2-B1V 1R2-B1V 1R2-B1V 1R2-B1V BVREFCA-B0V 2R5-B2V 2R5-B2V SMBCLK-P3P SMBDAT-P3P 1R2-B1V 0R6-P0V 1R2-B1V SIG26508 1R2-B1V 1R2-B1V 1R2-B1V 1R2-B1V Maintenance Manual (960-922)

  • Page 169: Table C-3 Cn1900 Sata Hdd Interface Connector (25-Pin

    Pin Assignments C.1.3 CN1900 SATA HDD interface connector (25-pin) Table C-3 CN1900 SATA HDD interface connector (25-pin) Pin No. Signal Name Pin No. Signal Name ZSTTHD-E1P ZSTTHD-E1N ZSTRHD-E1N ZSTRHD-E1P SHDDT1-E3N DVSLP1-E3P Maintenance Manual (960-922) C-10...

  • Page 170: Table C-4 Cn1920 Sata Hdd Interface Connector (60-Pin

    Pin Assignments C.1.4 CN1920 PCIe SSD interface connector (60-pin) Table C-4 CN1920 SATA HDD interface connector (60-pin) Pin No. Signal Name Pin No. Signal Name ZETSS0-E1N ZETSS0-E1P XSSDPCI-E0N XSSDPCI-E0P PEDET-P3P SSDXRQ-P3N PLTRS0-E3N ZERSS3-E1N ZERSS3-E1P ZETSS3-E1N ZETSS3-E1P ZERSS2-E1N ZERSS2-E1P ZETSS2-E1N ZETSS2-E1P DVSLP2-E3P SHDDT2-E3N ZERSS1-E1N...

  • Page 171: Table C-5 Cn1810 Sata Odd Interface Connector (13-Pin

    Pin Assignments C.1.5 CN1810 SATA ODD interface connector (13-pin) Table C-5 CN1810 SATA ODD interface connector (13-pin) Pin No. Signal Name Pin No. Signal Name ZSAODT-E1P ODD-E5V ZSAODT-E1N ODD-E5V ODDATT-S3N ZSAODR-E1N ZSAODR-E1P Maintenance Manual (960-922) C-12...

  • Page 172: Table C-6 Cn2631/Cn2630 Wlan Interface Connector

    Pin Assignments C.1.6 CN2631/CN2630 WLAN interface connector Table C-6 CN2631/CN2630 WLAN interface connector Pin No. Signal Name Pin No. Signal Name WLAN-E3V ZUSBBT-E3N WLAN-E3V ZETWL-E1P ZETWL-E1N CLRST1-E3N ZERWL-E1P CLDAT1-E1P ZERWL-E1N XCLCK1-E1P XPEWL-E0P XPEWL-E0N XSUSCK-E3P WLXRQ-P3N PLTRS0-E3N PEWAKE-E3N BTRFON-S3P WLRFON-S3P WLDET-P3N WLAN-E3V WLAN-E3V ZUSBBT-E3P...

  • Page 173: Table C-7 Cn3260 Kb Interface Connector(34-Pin

    Pin Assignments C.1.7 CN3260 KB interface connector(34-pin) Table C-7 CN3260 KB interface connector(34-pin) Pin No. Signal Name Pin No. Signal Name NUMLED-P5N KBSC06-S3N KBSC08-S3N CAPLED1-P5N KBSC10-S3N KBSC01-S3N KBRT06-S3N KBSC11-S3N KBRT02-S3N KBSC07-S3N KBRT03-S3N KBSC15-S3N KBRT05-S3N KBSC12-S3N KBRT01-S3N KBSC13-S3N KBRT04-S3N KBSC14-S3N KBRT07-S3N KBRT00-S3N KBSC00-S3N KBSC17-S3N...

  • Page 174: Table C-9 Cn4050 Lan Interface Connector (8-Pin

    Pin Assignments C.1.9 CN4050 LAN(RJ45) interface connector (8-pin) Table C-9 CN4050 LAN interface connector (8-pin) Pin No. Signal Name Pin No. Signal Name SIG26820 SIG26813 SIG26819 SIG26814 SIG26818 SIG26821 SIG26816 SIG26815 C.1.10 CN4800/CN4811 USB3.0 interface connector (9-pin) Table C-10 CN4800/CN4811 USB3.0 interface connector (9-pin) Pin No.
  • Page 175 Pin Assignments Pin No. Signal Name Pin No. Signal Name LHDMHP-S5P XLHDCK-P3N HDMRGB-P5V XLHDCK-P3N LHDSDA-P5P XLHDCK-P3N LHDSCL-P5P XLHDCK-P3N XLHDCK-P3N XLHDCK-P3N XLHDCK-P3N XLHDCK-P3N Maintenance Manual (960-922) C-16...

  • Page 176: Table C-13 Cn5390 Lcd/Webcam Interface Connector

    Pin Assignments C.1.13 CN5390 LCD/Webcam interface connector Table C-13 CN5390 LCD/Webcam interface connector Pin No. Signal Name Pin No. Signal Name DMICIN-P3P XDMCLK-Codec ZEDPA1-P1P CAMDET-P3N ZEDPA1-P1N SIG28323 ZEDPA2-P1P SIG28322 ZEDPA2-P1N ZEDPA3-P1P PVT-EFV ZEDPA3-P1N PVT-EFV PVT-EFV BLEN-E3P BKLPWM-P3P EDPHPD-P3P PNL-P3V PNL-P3V PNL-P3V ZEDPAU-P1N ZEDPAU-P1P...

  • Page 177: Table C-14 Cn5391 Ir Camera Harness Interface Connector (4-Pin

    Pin Assignments C.1.14 CN5391 IR Camera Harness interface connector Table C-14 CN5391 IR Camera Harness interface connector (4-pin) Pin No. Signal Name Pin No. Signal Name C.1.15 CN6331 Tweeter Speaker interface connector (4-pin) Table C-15 CN6331 Tweeter Speaker interface connector (4-pin) Pin No.
  • Page 178 Pin Assignments Pin No. Signal Name Pin No. Signal Name SIG30417 C.1.19 CN9530 FTL5U2* * interface connector /F4L7A3* FTL5U2* /F4L7A3* Table C-19 CN9530 interface connector Pin No. Signal Name Pin No. Signal Name ZUSBP2-E3N(SIG80968) ZUSBP2-E3P(SIG80967) ZUSBP4-E3P(SIG80966) ZUSBP4-E3N(SIG80965) EMICB-P3V(SLEEVB- P3V) TYCID-E5N(NC) EMICB-P3V(SLEEVB- P3V) USBON2-S3P...
  • Page 179 Pin Assignments C.1.20 CN9500 FTL5LE*/F4L7LE* interface connector Table C-20 CN9500 FTL5LE*/F4L7LE* interface connector Pin No. Signal Name Pin No. Signal Name SDCD-P3V SDCD-P3V ZUSBHB-E3P PWLEWH-M5N RFLED-M5N BAT1OR-M5N PWLEOR-M5N BAT1WH-M5N SDCD-P3V ZUSBHB-E3N C.1.21 CN9711 FTL5PW*/F4L7PW* interface connector Table C-21 CN9711 FTL5PW*/F4L7PW* interface connector Pin No.

  • Page 180: Table C-23 Cn8021 Battery (9 Pin

    Pin Assignments Table C-23 CN8021 Battery (9 pin) Pin No. Signal Name Pin No. Signal Name SIG30415 ESCL-S3P ESDA-S3P SIG30415 BDET-S3N SIG30414 C.1.24 CN9550 Fingerprint sensor interface connector (6 pin) Table C-24 CN9550 Fingerprint sensor interface connector (6 pin) Pin No. Signal Name Pin No.

  • Page 181: Usb 2.0/Audio Board (Ftl5U2*/F4L7A3

    Pin Assignments C.2 USB 2.0(3.0)/Audio board (FTL5U2*/F4L7A3*) C.2.1 CN9721 FTL5SY*/F4L7SY* interface connector Table C-25 CN9721 FTL5SY*/F4L7SY* interface connector Pin No. Signal Name Pin No. Signal Name ZUSBP2-E3N ZUSBP2-E3P ZUSBP4-E3P ZUSBP4-E3N SLEEVE-PXP SIG51 SLEEVE-PXP USBON2-S3P SLEEVE-PXP USBOC2-E3N SLEEVE-PXP EMCINL-PXP HEADR-PXP USBON4-S3P RING2-PXP USBOC4-E3N RING2-PXP...

  • Page 182: Table C-26 Cn4941/Cn4942 Usb2.0(3.0) Interface Connector

    Pin Assignments C.2.2 CN4941 USB2.0(3.0) interface connector Table C-26 CN4941/CN4942 USB2.0(3.0) interface connector Pin No. Signal Name Pin No. Signal Name SIG244 ZUSBP2-E3N SIG210 US3PS2-E5V ZU3D2R-E1P ZU3D2R-E1N ZUSBP2-E3P C.2.3 CN4942 USB2.0(3.0) interface connector Table C-27 CN4942(CN4941 USB2.0(3.0) interface connector Pin No. Signal Name Pin No.

  • Page 183: Sd/Led Board (Ftl5Le*/F4L7Le

    Pin Assignments C.3 SD/LED board (FTL5LE*/F4L7LE*) C.3.1 CN9600 FTL5SY*/F4L7SY* interface connector Table C-29 CN9600 FTL5SY*/F4L7SY* interface connector Pin No. Signal Name Pin No. Signal Name SDCD-P3V SDCD-P3V SDCD-P3V PWLEWH-M5N ZUSFMC-E3P ZUSFMC-E3N PWLEOR-M5N RFLED-M5N BAT1WH-M5N BAT1OR-M5N C.4 Power button board (FTL5PW*/F4L7PW*) C.4.1 CN9621 FTL5SY*/F4L7SY* interface connector...

  • Page 184: Scan Codes

    Appendix D Keyboard Scan/Character Codes D.1 Scan Codes Table D-1 Scan codes (set 1 and set 2) Code set 1 Code set 2 Keytop Note Make Break Make Break ‘ ~ 7 & Maintenance Manual (960-922)
  • Page 185 Keyboard Scan/Character Codes Code set 1 Code set 2 Keytop Note Make Break Make Break BkSp Caps Lock 3A ‘ “ Enter Shift (L) No.102 key 56 Maintenance Manual (960-922)
  • Page 186 Keyboard Scan/Character Codes Code set 1 Code set 2 Keytop Note Make Break Make Break , < . > Shift (R) Ctrl F0 14 F0 11 Alt (L) Space F0 29 ALT (R) E0 38 E0 F0 11 E0 B8 E0 11 E0 52 E0 D2...
  • Page 187 Keyboard Scan/Character Codes Code set 1 Code set 2 Keytop Note Make Break Make Break F0 78 F0 07 PrintSc Pause — — — — E0 5B E0 DB E0 1F E0 F0 1F E0 5D E0 DD E0 2F E0 F0 2F Notes: 1.

  • Page 188: Table D-2 Scan Codes With Left Shift Key

    Keyboard Scan/Character Codes Table D-2 Scan codes with left Shift key Code set 1 Code set 2 Keytop Make Break Make Break E0 AA E0 35 E0 B5 E0 2A E0 F0 12 E0 4A E0 F0 4A E0 12 E0 AA E0 52 E0 D2 E0 2A E0 F0 12 E0 70...

  • Page 189: Table D-3 Scan Codes In Numlock Mode

    Keyboard Scan/Character Codes Table D-3 Scan codes in Numlock mode Code set 1 Code set 2 Keyt Make Break Make Break E0 2A E0 52 E0 D2 E0 AA E0 12 E0 70 E0 F0 70 E0 F0 12 E0 2A E0 53 E0 D3 E0 AA E0 12 E0 71 E0 F0 71 E0 F0 12...

  • Page 190: Table D-6 No.124 Key Scan Code

    Keyboard Scan/Character Codes Table D-6 No.124 key scan code Code set 1 Code set 2 Shift Make Break Make Break E0 2A 37 E0 B7 7C E0 F0 7C E0 F0 12 Prt Sc Common AA E0 12 Ctrl + E0 F0 7C Shift + E0 F0 7C...

  • Page 191: Key Layout

    Appendix E Key Layout E.1 Japan (JP) Keyboard (+10 key) Figure E-1 JP keyboard Maintenance Manual (960-922)

  • Page 192: Rgb Monitor Loopback Connector

    Appendix F Wiring diagrams F.1 RGB Monitor Loopback Connector Figure F-1 RGB Monitor Loopback Connector (1) RED GREEN (2) GREEN BLUE (3) BLUE MNTID2 (4) (4) MNTID2 (5) GND (6) GND (7) GND (8) GND (9) NC (10) (10) GND MNTID1 (11) (11) MNTID1 MNTID0 (12)

  • Page 193: Lan Loopback Connector

    Wiring diagrams F.2 LAN Loopback Connector Figure F-2 LAN Loopback Connector (1) TX+ (2) TX- (3) RX+ (4) (Not used) (5) (Not used) (6) RX- (7) (Not used) (8) (Not used) Maintenance Manual (960-922)

  • Page 194: Bios Rewrite Procedures

    Appendix G BIOS Rewrite Procedures This Appendix explains how to rewrite the system BIOS program when you update the system BIOS. G.1 Tools To rewrite the BIOS, you need the following tool: BIOS/EC/KBC rewriting disk ■ G.2 Rewriting the BIOS 1.

  • Page 195: Ec/Kbc Rewrite Procedures

    Appendix H EC/KBC Rewrite Procedures This Appendix explains how to rewrite the EC/KBC system program when you update the EC/KBC system. It is necessary to rewrite the EC/KBC system program when the following changes are made. 1. Replacing of system board 2.

  • Page 196: Rewriting The Ec/Kbc (For Ps59R Model

    EC/KBC Rewrite Procedures 1. Rewrite the EC/KBC only when instructed by a diagnostic disk release notice. 2. Connect the AC adaptor to the computer when you rewrite the EC/KBC. 3. Do not turn off the power while you are rewriting the EC/KBC. If the rewrite fails, it might be impossible to start up the computer.

  • Page 197: Reliability

    Appendix I Reliability The following table shows MTBF (Mean Time Between Failures) in maximum configuration. Table I-1 MTBF Time (hours) 5884 (PS59* model) 7874 (PS59R model) Maintenance Manual (960-922)

This manual is also suitable for:

Tx seriesEx seriesBx seriesAx seriesAz 5 seriesBz 5 series ... Show all

Table of Contents
