th
November 1
, 2022
Dynabook Laptop Components Classified as Requiring Selective Treatment
Dynabook would like to communicate the method of identifying and removing components contained
in Dynabook notebook products, including but not limited to the
selective treatment based on the European WEEE Directive, Directive 2012/19/EU of the European
Parliament and of the Council on waste electrical and electronic equipment (WEEE).
All of the instructions provided within this letter can be reviewed in greater detail within
the
Satellite C50-K
Tools Required
In order to remove internal components of the
be required located in Chapter 4 Replacement Procedures of the Dynabook Maintenance
Manual.
For your safety and that of other people in the working environment, it is strongly recommended
that you use electrostatic discharge (ESD) equipment. The proper use of this equipment will
ensure successful repair work and reduce the costs for repairing damaged components.
The equipment and tools required for disassembly and reassembly are:
■
One 2 mm Phillips screwdriver
■
One 4 mm flat-blade screwdriver
■
Torx screw driver
■
Tweezers (for pulling out screws)
■
ESD mats (for the floor and work desks)
■
An ESD wrist strap or heel grounder
■
Anti-static carpets or flooring
■
Air ionizers (for highly electrostatic sensitive areas)
■
A plastic card (in credit card size)
■
A smooth stick (0.43mm, for example: a Pick or PC Mylar)
■
SIM card tray eject pin tool
Table of Contents
(Page 2-3)
(Page 4)
(Page 5-44)
(Page 45-46) AC Adapter, External cables provided with the AC adapter and USB cable
Series Maintenance Manual.
Removing the Lithium Ion Battery (Main Battery, No coin cell battery)
Removing the SSD
Removing LCD, Printed Circuit / Wiring Boards (PCB/ PWB system board)
Satellite C50-K
Satellite C50-K
some tools from the list below may
model, that requires

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Satellite C50-K Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for dynabook Satellite C50-K Series

Summary of Contents for dynabook Satellite C50-K Series

  • Page 1 November 1 , 2022 Dynabook Laptop Components Classified as Requiring Selective Treatment Dynabook would like to communicate the method of identifying and removing components contained in Dynabook notebook products, including but not limited to the Satellite C50-K model, that requires selective treatment based on the European WEEE Directive, Directive 2012/19/EU of the European Parliament and of the Council on waste electrical and electronic equipment (WEEE).
  • Page 2 1. Removing the Lithium Ion Battery (Main Battery, No coin cell battery) Please refer to the information below for instructions regarding the identification and removal of the Lithium ion battery. Further maintenance instructions can be found in section of the Satellite C50-K Maintenance Manual.
  • Page 3 Battery Pack Removing the battery pack Remove the battery pack according to the following procedures and Figure4- 2. CAUTION: When handling the battery pack, use cares not to short circuit the terminals. Do not drop, hit, twist or bend the battery pack. Do not scratch or break up their casing. □...

  • Page 4: Removing The Ssd

    Removing the SSD Removing the SSD Card Remove the SSD Card/WLAN Card/DIMM assembly according to the following procedures and Figure4- 7 □ □ 1. Remove the one M2x3 screw and SSD card from the motherboard Figure4- 7 Removing the SSD Card/WLAN Card/DIMM...
  • Page 5 3. Removing LCD, Printed Circuit / Wiring Boards (PCB/ PWB system board) Beside the LCD and the main PCB, there are further small PCBs and components which are in the scope of the WEEE Directive. The removal of these components is described in detail in the chapter 4 of the associated maintenance manual.
  • Page 6 Replacement Procedures Figure4- 1 Removing the Base Cover.......................... 4-2 Figure4- 2 Removing the Battery Pack ........................4-3 Figure4- 3 Removing the Fan and thermal module ....................4-4 Figure4- 4 Removing the w-lan cable ........................4-4 Figure4- 5 Fan Cable and W-lan Cable ........................4-4 Figure4- 6 Checking the Thermal Pad on Thermal module...................

  • Page 7: Removing The Base Cover

    Base cover Removing the base cover Remove the base cover according to the following procedures and Figure4- 1. 1. Turn the laptop upside down so that the bottom is facing up. □ 2. Remove the six M2x5 screws ,1 (This four screws have angle to fix D cover). □...

  • Page 8: Installing The Base Cover

    Installing the Base Cover Install the base cover according to the following procedures: 1. Align the base cover with the snaps on the logic upper assembly, and gently press downward the edges of the base cover until clicks are heard. Make sure all the snaps are latched and secured. □...

  • Page 9: Removing The Battery Pack

    Battery Pack Removing the battery pack Remove the battery pack according to the following procedures and Figure4- 2. CAUTION: When handling the battery pack, use cares not to short circuit the terminals. Do not drop, hit, twist or bend the battery pack. Do not scratch or break up their casing. □...

  • Page 10: Installing The Battery Pack

    Installing the Battery Pack Install the battery pack according to the following procedures: 1. Seat the battery pack in the correct position on the logic upper assembly and insert the battery □ □ connector □ 2. Tighten the four M2 x 3 screws to secure the battery pack to the logic upper assembly...

  • Page 11: Fan And Thermal Module

    Fan And Thermal Module Removing the fan and thermal module Remove the fan and thermal module according to the following procedures and Figure4- 3 & Figure4- 4 CAUTION: When removing the thermal module, keep the following in mind: The thermal module can become very hot during operation. Be sure to let it cool down before starting the repair work.
  • Page 12 Figure4- 3 Removing the Fan and thermal module Figure4- 4 Removing the w-lan cable...

  • Page 13: Installing The Thermal Module

    Installing the thermal module Install the fan and thermal module according to the following procedures: □ Seat the fan in the correct position on the logic upper assembly and insert the fan connector □ and tuck the fan cable into the fan hook 10 .
  • Page 14 Figure4- 6 Checking the Thermal Pad on Thermal module...
  • Page 15 SSD Card/WLAN Card/DIMM Removing the SSD Card/WLAN Card/DIMM Remove the SSD Card/WLAN Card/DIMM assembly according to the following procedures and Figure4- 7 □ □ 1. Remove the one M2x3 screw and Wlan card from the motherboard □ □ 2. Remove the one M2x3 screw and SSD card from the motherboard □...
  • Page 16 Installing the SSD Card/WLAN Card/DIMM Install the SSD Card/WLAN Card/DIMM according to the following procedures: Seat the wlan in the correct position and tighten the one M2 x 3 screw to secure the wlan to the □ □ motherboard assembly Seat the SSD in the correct position and tighten the one M2 x 3 screw to secure the wlan to the □...

  • Page 17: Removing The Speakers

    4.6 Speakers Removing the Speakers Remove the speaker assembly according to the following procedures and Figure4- 8 □ Disconnect the speaker cable from the motherboard □ 1. Gently pull up the speaker assembly and the speaker cable out of the routing channels □...

  • Page 18: Installing The Speakers

    Installing the Speakers Install the speakers according to the following procedures: NOTE: Take care not to pinch the cables. Make sure the routing positions of the cables are correct and do not block any components, such as screw holes. Seat the speakers in the correct position and secure it in place on the logic upper assembly □...

  • Page 19: Removing The I/O Board

    IO Board Removing the IO Board Remove the IO board according to the following procedures and Figure4- 10. □ □ 1. Disconnect the IO board FFC □ 2. Remove one M2x3 screw □ 3. Gently lift up the right edge of the IO board and remove it from the logic upper assembly Figure4- 10 Removing the IO Board...

  • Page 20: Installing The Io Board

    Installing the IO Board Install the IO board according to the following procedures: □ 1. Seat the IO board in the correct position on the logic upper assembly □ 2. Tighten one M2×3 screw to secure the IO board to the logic upper assembly 3.

  • Page 21: Removing The Sensor Board

    Sensor Board Removing the Sensor Board Remove the Sensor board according to the following procedures and Figure4- 11 □ □ 1. Disconnect the sensor board FFC □ 2. Gently pry up the sensor board from the adhesive and remove it from the Upper cover Figure4- 11 Removing the sensor board...

  • Page 22: Installing The Sensor Board

    Installing the Sensor Board Install the Sensor board according to the following procedures: 1. Seat the sensor board in the correct position and secure it in place with adhesives on the upper cover as shown in Figure4- 12. 2. Connect the sensor board FFC to the sensor board. Make sure the FFC are properly engaged and □...

  • Page 23: Removing The Motherboard

    4.9 Motherboard Removing the Motherboard Remove the motherboard according to the following procedures and Figure4- 13 □ 1. Remove four M2x3 screws ,1 securing the motherboard to the logic upper assembly. □ □ □ □ 2. Disconnect the eDP cable ,2/ DCIN cable ,3/sensor board FFC ,5/TP...

  • Page 24: Installing The Motherboard

    Installing the Motherboard Install the motherboard according to the following procedures: 1. Seat the motherboard in the correct position on the logic upper assembly. □ 2. Tighten four M2×3 screw ,1 to secure the motherboard to logic upper assembly as shown in Figure4- 13.

  • Page 25: Removing The Finger Print Module

    4.10 Finger Print Module Removing the Finger Print Module Remove the finger print assembly according to the following procedures and Figure4- 14 □ □ 1. Disconnect the finger print FFC from finger print module 2. Remove the one M2×2 screw securing the finger print bracket to the logic upper □...
  • Page 26 Installing the Finger Print Module Install the finger print module according to the following procedures: □ 1. Seat the finger print in the correct position on the logic upper assembly □ 2. Place the finger print bracket on the logic upper assembly □...

  • Page 27: Removing The Touch Pad Module

    4.11 Touch Pad Module Removing the Touch Pad Module Remove the touch pad assembly according to the following procedures and Figure4- 15 and Figure4- 16. □ □ 1. Disconnect the touch pad FFC from touch pad module □ 2. Peel away the conductive tape ,6 on logic upper assembly from touch pad.
  • Page 28 Figure4- 16 Location of Electronic tape & Conductive tape Installing the Touch Pad Module Install the touch pad module according to the following procedures: □ 1. Seat the touch pad in the correct position on the logic upper assembly □ 2.

  • Page 29: Lcd Assembly

    4.12 LCD Assembly Removing the LCD Assembly Remove the LCD assembly according to the following procedures and Figure4- 17 and Figure4- 18 1. Pull the W-LAN cables and edp cable out of the routing channels as shown in □ □ Figure4- 17 □...
  • Page 30 Figure4- 17 W-LAN /edp Cables Routing Channel Figure4- 18 Removing the LCD Assembly...

  • Page 31: Installing The Lcd Assembly

    Installing the LCD Assembly Install the LCD assembly according to the following procedures: 1. Place the logic upper assembly upside down so that the bottom is facing up. 2. Rotate the LCD hinges to a 180-degree angle and seat the LCD assembly in the correct position on the logic upper assembly, and the cables must be placed inside the hook of hinge □...

  • Page 32: Removing The Bezel

    4.13 Bezel Removing the Bezel Remove the Bezel according to the following procedures and Figure4- 19. 1. Place the LCD assembly right-side up so that the top is facing up. 2. Insert a smooth, flat instrument into the gap between the Bezel and the LCD cover as shown in Figure4- 19, and then gently twist the instrument to pry up the Bezel from the LCD cover.

  • Page 33: Installing The Bezel

    Installing the Bezel Install the Bezel according to the following procedures: 1. Place the Bezel on the LCD cover assembly. Make sure the tabs on the back of the Bezel align with the slots in the LCD cover assembly. 2. Gently press down edges around the Bezel until clicks are heard. Make sure all the snaps are latched and secured.

  • Page 34: Panel Assembly

    Panel Assembly 4.14 Removing the Panel Assembly Remove the panel Assembly according to the following procedures and Figure4- 20 and Figure4- 21 and Figure4- 22 and Figure4- 23 □ 1. . Pull up the adhesive from LCD cover ,1 as shown in Figure4- 20 □...
  • Page 35 Figure4- 20 Removing the Panel Adhesive Figure4- 21 Removing the Panel Assembly...
  • Page 36 Figure4- 22 Disconnecting the eDP Cables FFC from Camera FPC Assembly Figure4- 23 Disconnecting the Cables from Panel Assembly...
  • Page 37 Installing the Panel Assembly Install the panel assembly according to the following procedures: 1. Place the panel assembly upside down so that the bottom is facing up. 2. Connect the eDP cable to the panel connector and lock it with lock bar, then adhere the mylar □...
  • Page 38 Figure4- 24 Removing the Release Paper of Panel Adhesive Figure4- 25 Panel assembly explanation...

  • Page 39: Removing The Antenna Module

    Antenna Module 4.15 Removing the Antenna module NOTE: Antenna module is fastened by adhesives. Remove it slowly and carefully. Remove the Antenna module according to the following procedures and Figure4- 26 □ 1. Removing the Antenna cable from the adhesive and remove it from the Hinge □...
  • Page 40 Installing the Antenna Module Install the Antenna module according to the following procedure: 1. Seat the Antenna module_A in the correct position and secure it in place with adhesives □ behind it. □ 2. Pasting the Cu-Foil_A in the correct position. □...

  • Page 41: Camera Module

    Camera Module 4.16 Removing the Camera Module NOTE: Camera module is fastened by adhesives. Remove it slowly and carefully. Remove the camera module according to the following procedures andFigure4- 27. □ 1. Gently pry up the camera module and remove it from the LCD cover *Camera module is fixed by adhesive on the LCD cover.
  • Page 42 LCD Hinges 4.17 Removing the LCD Hinges Remove the LCD hinges according to the following procedures and Figure4- 28 □ 1. Remove the six M2×2.5 screws securing the LCD hinges □ 2. Remove the two M2×3 screws securing the LCD hinges Figure4- 28 Removing LCD Hinges...

  • Page 43: Installing The Lcd Hinges

    Installing the LCD Hinges Install the LCD hinges according to the following procedures: □ 1. Tighten the six M2×2.5 screws to secure the LCD hinges to the hinge cover assembly. □ 2. Tighten the two M2×3 screws to secure the LCD hinges to the hinge cover assembly.
  • Page 44 Installing the Panel Assembly Install the panel assembly according to the following procedures: 1. Seat and adhere the Hinges in the correct position on the LCD cover assembly as shown in Figure4- 28 (Tighten the six M2×2.5 screws). 2. Seat and adhere the antennas in the correct position on the LCD cover assembly as shown in Figure4- 28 (.
  • Page 45 AC Adapter, External cables provided with the AC adapter and USB cables The AC adapter as well as all external cables provided with the notebook including the AC adapter cables and USB cables should be segregated and sent for shredding. The following components contained within the AC adapter potentially contain hazardous substances and require special handling: Printed Circuit Board >10 cm...
  • Page 46 Conventional type AC adapter AC Adapter with casing removed AC adapter printed circuit board AC adapter capacitor...
