Hdd Logical Test - dynabook Satellite C40-J Hardware Overview

Message
Read Hdd Create File
Error.Address=XX
Read Hdd Set File Pointer
Error.Address=XX
Read Hdd Command
Error. Address=XX
Read Hdd Check Size
Error. Address=XX

4-2-2 HDD LOGICAL Test

1) Test contents
This test checks if it can read the files on the first built-in HDD/SSD/eMMC successfully.
Note: The test is only checking those files that have a file size greater than 0 Bytes and less than 1 MBytes.
■ In case of Simple mode
The simple test mode performs a read test on the first 400 files.
■ In case of Detail mode
The detailed test mode performs read test on the first 2000 files.
The status is updated sequen�ally (the file name being verified is displayed in "File Name" dynamically) during the test, the test finished
th
un�litreadslastfile(400 fileforSimplemode,2000
count more than one, the test runs more than one cycle.
2) Test screen
▼ File Name ... The name of the file being verified with full path
3) Test result
■ In case of PASS
"OK" is shown in the "Result" field on the "Diagnos�cs" dialog.
The pass count is shown in the "PASS" field.
■ In case of FAIL
"NG" is shown in the "Result" field on the "Diagnos�cs" dialog.
The pass and error count are shown in the "pass" and "error" fields respec�vely.
The detail of the error is recorded in the log file as follows.
(The following example indicates the case where an error was found in file-A.)
SATELLITE PRO C40-J/C50-J
Explana�on
Failed in opening of HDD/SSD/eMMC driver.
XX is LAB value.
Failed in the HDD/SSD/eMMC file
pointer se�ng command.
XX is LAB value.
Failed in the HDD/SSD/eMMC read
command.
XX is LAB value.
The size read by the HDD/SSD/eMMC read
command does not equal to the specified
size.
XX is LAB value.
th
fileforDetailmode)successfully.Thisistheonecycleofthetest.Ifyousetthepass
Maintenance Manual
3 Diagnostic Programs
Remarks
The HDD/SSD/eMMC driver may not
be normal or installed.
It indicates that a read error occurred
at the specified LBA.
Name of file being verified
3-23
