As described above, the intervals of ver�cal lines and horizontal lines are iden�cal
"Z".All grids made by adjacent ver�cal lines and horizontal lines are congruent
squares.
(4) Grada�onal colored circles are drawn at each corner as the following order:
Blue circle at the upper le� corner
Green circle at the upper right corner
Red circle at the lower right corner
White circle at the lower le� corner
For the blue circle, it is drawn gradually smaller and less brightly as follows:
across = diagram of the circle = 5*Z;
(x1, y1) = (0, 0); , (x2, y2) = (across, across);
blue = 255;
for ( I = across/2; I > 1; I--)
{
Pen_Color = RGB (0, 0, blue--);
Brush_Color = RGB (0, 0, blue--); ....(C) Ellipse(x1++, y1++, x2--, y2--);
}
(0, 0)
For other color circled circles, the followings are for "(A)", "(B)" and "(C)" besides the
posi�ons: Green : green = 255; , Pen_Color = RGB(0, green--, 0); , Brush_Color = RGB(0,
green--, 0);
Red : red = 255; , Pen_Color = RGB(red--, 0, 0); , Brush_Color = RGB(red--, 0, 0);
White: red = green = blue = 255; ,
Pen_Color = RGB(red--, green--, blue--); , Brush_Color = RGB(red--, green--, blue--);
