SETTING UP HARDWARE

Chapter 5 – Setting Up Hardware

Models with cellular capability have a micro SIM slot, you'll need a micro (3FF) SIM card from your network

provider.

Note:

-LNA3 models work on both Verizon and AT&T networks. The device detects the carrier based on

your SIM card.

To install the SIM card:

With the contact side facing down, align the notched edge as shown on the following image and slide the

SIM card completely into the SIM holder.

To remove the SIM card, push the SIM card in. The device ejects the SIM card.

To connect the antenna:

Finger-tighten the antenna to the SMA antenna connector on your device.

To cable the device:

Connect the Ethernet cable to the Ethernet port on the device and to your computer.

Connect the power supply to the device's power jack and plug it into an electrical outlet. When the

operating system is fully loaded, the STATUS LED blinks.

Conduit

AP MTCAP2-LNA3-915 and MTCAP2-915 Hardware Guide
