Product Introduction - Voxelab Aries User Manual

11
2
4
5
7
1. Y-axis Guide Rod
5. Clip
9. USB Stick Input
13. Turbofan Baffle
17. Drive assembly

Product Introduction

13
12
1
8
9
2. X-axis Guide Rod
6. Limit position assembly
10. Power Voltage Switch
14. Power Switch
14
10
3. Z-axis Guide Rod
7. Nut
11. LED Light
15. Power Input
07
16
15
3
6
4. Build Plate
8. Touch Screen
12. Nozzle
16. Spool installation port
17
