9. Identify the Left Pedal (24), which is marked
with an "L."
Using an adjustable wrench, firmly tighten the
Left Pedal counterclockwise into the Left
Crank Arm (66).
Tighten the Right Pedal (not shown) clockwise
into the right arm of the Crank (not shown).
Adjust the strap on the Left Pedal (24) to the
desired position, and press the end of the strap
onto the tab on the side of the Left Pedal.
Adjust the strap on the Right Pedal (not
shown) in the same way.
10. Make sure that all parts are properly tightened before you use the exercise bike. Note: After assembly
is completed, some extra parts may be left over. Place a mat beneath the exercise bike to protect the floor.
All manuals and user guides at all-guides.com
10
9
Strap
24
Tab
66
