ASSEMBLY

Assembly requires two persons. Place all parts of the exercise cycle in a cleared area and remove the pack-
ing materials. Do not dispose of the packing materials until assembly is completed.
In addition to the included tools, assembly requires an adjustable wrench and a Phillips
screwdriver .
Use the part drawings below to identify the small parts used in assembly. The number in parentheses below
each drawing refers to the key number of the part, from the PART LIST near the end of this manual. The number
following the parentheses is the quantity needed for assembly. Note: Some small parts may have been pre-
assembled. If a part is not in the hardware kit, check to see if it has been preassembled.
M4 x 15mm Round M5 x 15mm Round
M8 Split Washer M8 Locknut
Head Screw (58)–2 Head Screw (59)–4
(42)–7 (10)–4
M8 x 60mm Button Screw (30)–4
M6 x 15mm Button M8 x 15mm Button
Screw (46)–4 Screw (34)–3
M8 x 73mm Button Screw (33)–2
