Pro-Form 700 User Manual page 10

10. Identify the Left Pedal (24), which is marked
with an "L." Using an adjustable wrench, firmly
tighten the Left Pedal counterclockwise into the
left arm of the Crank (21).
Tighten the Right Pedal (not shown) clockwise
into the right arm of the Crank (not shown).
IMPORTANT: Tighten both pedals as firmly
as possible. After using the exercise cycle
for one week, retighten the pedals. For best
performance, keep the pedals tightened.
Adjust the strap on the Left Pedal (24) to the
desired position, and press the end of the strap
onto the tab on the side of the Left Pedal.
Adjust the strap on the Right Pedal (not shown)
in the same way.
11. Make sure that all parts are properly tightened before you use the exercise cycle. Note: After assembly is
completed, some extra parts may be left over. Place a mat beneath the exercise cycle to protect the floor.
All manuals and user guides at all-guides.com
10
10
24 21
Tab
Strap
