The Ethernet Interface

The Ethernet interface is used to connect to the Primary port of the Spatial FOG Dual ETH via a
TCP connection. This Ethernet interface can be configured using a web browser if your computer
is on the same network as the Spatial FOG Dual ETH.
The Spatial FOG Dual ETH is configured by default as a DHCP Client so it will automatically obtain
an IP address from your router when connected to the network. You can use your router interface
to determine this IP address. Once you have the IP address you can use a web browser to display
the Ethernet interface configuration screens.
Primary Port IP Address
Primary Port TCP Port Number
Primary Port Ethernet Interface Channel Number
Table 8: TCP Port Connection Values
Parameter
Spatial FOG Dual ETH
Supplementary Reference Manual
Page 24 of 29
Version 1.2
10/09/2019
Assigned by your router
Value
16718
1
