Advanced Navigation Spatial FOG Dual ETH Reference Manual page 13

Pin
1
2
3
4
5
6
7
8
9
10
11
12
13
Table 5: Pin allocation table
8.11 Spatial FOG Dual Evaluation Cable Harness
Advanced Navigation does not offer any pre-terminated evaluation cable harness for the Spatial
FOG Dual ETH variant.
Spatial FOG Dual ETH
Supplementary Reference Manual
Page 12 of 29
Version 1.2
10/09/2019
Function
GPIO 2 -
Auxiliary RS232 Rx
Signal Ground
Power Ground
Power Supply
Ethernet Tx-
GPIO 2 +
GPIO 1 +
GPIO 1 -
Auxiliary RS232 Tx
Ethernet Rx+
Ethernet Rx-
Ethernet Tx+
