8.10 Connector Pin-out
Power supply and signal connections are made through a 13 pin Glenair Mighty Mouse connector.
The part number for the connector on the unit is 801-011-07M8-13PA. The part number for the
recommended cable connector is 801-007-16M8-13SA. The connector provides a reliable and
rugged connection to Spatial FOG Dual ETH under demanding conditions and is rated to IP68 in
the mated condition.
3
Illustration 1: View into the connector on the unit
