8.8 Electrical Specifications
Parameter
Input Supply Voltage
Input Protection Range
Rx Differential Threshold
Tx Voltage Low
Tx Voltage High
Tx Short Circuit Current
Rx Threshold Low
Rx Threshold High
Active Antenna Supply Voltage
Antenna Supply Current
Table 4: Electrical specifications
8.9 Power Consumption
Refer to the Spatial FOG Dual Reference Manual.
Supplementary Reference Manual
Minimum
Power Supply
9 V
-40 V
RS422
-0.2 V
RS232
5 V
0.6 V
GNSS Antenna
4.8 V
Spatial FOG Dual ETH
Page 10 of 29
Version 1.2
10/09/2019
Typical
-5.4 V
5.4 V
1.2 V
1.5 V
Maximum
36 V
100 V
-0.05 V
-5 V
±60 mA
2.0 V
5 V
150 mA
