- Page 1 Single Monitor Mount Instruction Manual MU4003 75x75 32" 100x100 8kg/17.6lbs If you have any questions , please contact us. V2.0...
-
Page 2: Package Contents
WARNING! If you do not understand these instructions or have doubts about the safety of the installation, assembly or use of this product, please contact us. Before starting assembly, verify all parts are included and undamaged. Improper installation may cause damage or serious injury. -
Page 3: Assembly Steps
ASSEMBLY STEPS STEP 1: Clamp Installation OR Grommet Base Installation OPTION A: Clamp Installation Install the Clamp (C) to the Pole (D) using 3pcs Bolt (G). Tighten using 4mm Allen key (J). Secure stand to the desktop by tightening the plastic knob or by using 6mm Allen key (K). 10-80mm... - Page 4 STEP 1: (Continued) OPTION B: Grommet Base Installation If existing grommet hole comes with a plastic protector, remove it to ensure a at surface before installing the desk mount. Loosen the screw, separate the clamp (C) into two parts. DESK ø...
-
Page 5: Step 2 : Arm Installation
STEP 2 : Arm Installation Install wire clip (E) and swivel arm (B) to the pole (D). Fasten the bolt with supplied 6mm Allen key (K). - Page 6 STEP 3 : Attached Monitor OPTION A: Flat Back Monitor For flat back monitor, secure VESA plate (A) to monitor using screws (M-A or M-C) and washers (M-E). Tighten the screws using 6mm Allen key (K). CAUTION:To select the correct screws (M-A or M-C) for your monitor, you can try to screw it on your monitor by hand.
- Page 7 STEP 4 : Hang Monitor Slide monitor with VESA plate onto mounting bracket. Secure with security bolt (I).
-
Page 8: Step 5: Tilt Adjustment
STEP 5: Tilt Adjustment Tighten or loosen tilt joint using 6mm Allen Key (K). STEP 6: Cable Management Manage cables with installed Wire Clip (E). -
Page 9: Step 7: Tool Management
STEP 7: Tool Management Store 4mm Allen Key (J) and 6mm Allen Key (K) in Wire Clip (E). STEP 8: Adjust as Desired Adjust monitor position and rotation. 90° +45° 360° -45° Note: When tilted, if the monitor sags or does not stay, please fasten the tilting bolt on the mount until the monitor can be held at any angle as needed. -
Page 10: Product Dimensions
Product Dimensions 90° 360°... - Page 12 CAUTION AND MAINTENANCE: • Never allow children to climb, stand, hang, or play on any part of monitor or stand. • This product is intended for indoor use only. Using this product outdoors could lead to product failure and personal injury. •...
