INSTALLATION INSTRUCTION
SB-204_US1.0
Load
Capacity
MAX:
5 kg (11 lbs)
If you have any questions, please feel free to contact our customer support
before returning.
Product Dimensions
5.1"
MAX:
(130mm)
43.3"(1100mm)
MIN:
34"(865mm)
MIN: 5"(127mm)
MAX: 10"(254mm)
1
Advertisement
Related Manuals for Mountup MU9138
Summary of Contents for Mountup MU9138
- Page 1 INSTALLATION INSTRUCTION SB-204_US1.0 Load Capacity MAX: 5 kg (11 lbs) If you have any questions, please feel free to contact our customer support before returning. Product Dimensions 5.1" MAX: (130mm) 43.3"(1100mm) MIN: 34"(865mm) MIN: 5"(127mm) MAX: 10"(254mm)
- Page 2 Safety Caution BEFORE ASSEMBLY ● Please check and make sure all necessary accessories are included and undamaged. If any parts are missing or damaged, do not return the damaged item to your dealer; contact Customer Service. Never use damaged parts. ●...
- Page 3 Install the Base Foot Pad Choose rubber feet or carpet nails according to your floor type. Option 1: Hard Floor If the stand is placed on wooden, cement, tile or other hard floor, install the rubber pads (M) and adjust them to level if the base is not level.
- Page 4 Install the Bottom Tube Insert bottom tube (3) into base (2), then tighten bolts (A) by using Allen key (M-C). Tighten Insert plastic cover (5) into bottom tube (3).
- Page 5 Install the Upper Tube Choose the threading method based on the size of the cord plug. Loosen the knob on upper tube (4). Insert upper tube (4) into bottom tube (3), then tighten bolts (M-A) by using Allen key (M-C). Option 1: Insert through upper tube, pull out from base.
- Page 6 Install the Support Bracket Insert support bracket (1) onto upper tube (4), then tighten bolt (M-B) by using Allen key (M-C). Bottom View NOTE: Align the gap of the tube with the protrusion of the support bracket. Tighten...
- Page 7 Install Speakers 1. Measure the width of your speaker. 2. Loosen the support bracket (1) and adjust the graduated ruler to the width of the speaker. Then lock it. Attention: Speaker width up to 10 in !! Speaker Width e.g. 10 in Loosen Tighten Pull the spring-loaded plate to place the speaker in...
- Page 8 Adjustment 1. Insert the power cord plug into the speaker. 2. Adjust the speaker to the left or right so that it is parallel to the base. 3. Adjust the upper tube height, then tighten the knob bolt. MAX: 43.3"(1100mm) MIN: 34"(865mm) Tighten...
