SUPERVISOR 3000
(SU3000)
Optical Turnstile with Motorized Barrier Arms
Installation Instructions
Alvarado Manufacturing Company, Inc.
12660 Colony Street, Chino, CA 91710
Phone: +1 (909) 591-8431
Fax: +1 (909) 628-1403
support@alvaradomfg.com
www.alvaradomfg.com
PUD3628R1-2
