Flat/Incline/Decline Bench
F705
To see in
Open your Camera
FULL COLOR
App and point it at
the QR Code
& addition information,
scan this QR code
Base Serial Number: _ _ _ _ _ _ _ _ _ _ _ _ _
Purchased Date: ___ / ___ / ______
Dealer's Name:__________________________
Please register your products at:
https://www.bodycraft.com/product-registration/
Owner's Manual
F705 v1.4
1
Advertisement
Table of Contents
Related Manuals for BodyCraft F705
Summary of Contents for BodyCraft F705
- Page 1 & addition information, scan this QR code Base Serial Number: _ _ _ _ _ _ _ _ _ _ _ _ _ Purchased Date: ___ / ___ / ______ Dealer’s Name:__________________________ Please register your products at: https://www.bodycraft.com/product-registration/ Owner’s Manual F705 v1.4...
- Page 2 Your BODYCRAFT machine has all the quality and design elements to make your workout extremely efficient and comfortable. Your new unit is a serious cardio machine that will keep you motivated, challenged and within reach of your fitness goals.
-
Page 3: Table Of Contents
Table of Contents Page Page Product Safety Information Product Safety ……………………………………………………………... Important Notes, Recommended Tools & Cleaners …………………….. Product Overview Machine Dimensions & Adjustments ……………...……………………... Assembly Parts List ………………………………………………………… How to Assemble Product Assembly Instructions ..........…………... Maintenance & Repairs Parts Exploded View .………………………………….…………………… Detailed Parts Lists ………….……………………………………….…….. -
Page 4: Product Safety
It is imperative that you retain this Assembly Instructions and be sure all warning labels are legible and intact. Replacement Assembly Instructions and labels are available from BODYCRAFT. If you are unsure about the proper use of the BODYCRAFT strength machine call your local BODYCRAFT dealer or our Customer Service Department. Contact BODYCRAFT at 800-990-5556 or support@bodycraft.com... -
Page 5: Important Notes, Recommended Tools & Cleaners
Important Notes, Recommended Tools & Cleaners Important Notes and Tips: Before assembly, read all instructions thoroughly and preview diagrams to help make the installation easier. 2. Make sure all parts are accounted for and in proper condition before beginning assembly. See the parts list. -
Page 6: Machine Dimensions& Adjustments
Machine Dimensions& Adjustments Top View ¾ View Side View Front View Overall Dimensions 28.5”W x 52.1”D x 20.4”H 0° Flat 85° Incline -18° Decline... -
Page 7: Assembly Parts List
Assembly Parts List Part # Assembly Parts List F705-001-ASM MAIN FRAME - Assembly F705-002-ASM BENCH HANDLE - Assembly F705-003-ASM BACK SUPPORT - Assembly F705-004-ASM SEAT SUPPORT - Assembly F705-005 HANDLE F705-006 SEAT PAD F705-007 BACK PAD F705-008-ASM REAR STABILIZER - Assembly... -
Page 8: Product Assembly Instructions
Product Assembly TEP 1a: Main Frame Attach Rear Stabilizer - Assembly (8-ASM) to the Main Frame - Assembly (1-ASM) using: ● Two HEX BOLTS, 1/2" X 4" (10) ● Four FLAT WASHERS, 1/2" (14) ● Two NYLON NUTS, THICK, 1/2" (15) TEP 1b: Front Handlebar Attach Bench Handle - Assembly (2-ASM) to the Main Frame - Assembly (1-ASM) using:... - Page 9 Product Assembly TEP 2a: Seat Support Attach SEAT SUPPORT - Assembly (4-ASM) to the MAIN FRAME - Assembly (1-ASM) using: ● One HEX BOLT, 1/2" x 5" (11) ● Two FLAT WASHERS, 1/2" (14) ● One NYLON NUT, THICK, 1/2" (15) Recommended Tools TIP: Fully tighten both HEX BOLTS...
- Page 10 Product Assembly TEP 3a: Seat Pad Attach SEAT PAD (6) to the SEAT SUPPORT - Assembly (4-ASM) using: ● Two HEX BOLTS, 3/8" x 2-1/2" (12) Please Hand Tighten All ● Two SPRING WASHERS, 3/8" (31) Bolts Until End of STEP 3 ●...
-
Page 11: Parts Exploded View
Parts Exploded View... -
Page 12: Detailed Parts Lists
F705-006 SEAT PAD F705-007 BACK PAD F705-008 REAR STABILIZER F705-009 HEX BOLT, 1/2" x 2-3/4" - BLACK F705-010 HEX BOLT, 1/2" x 4" - BLK F705-011 HEX BOLT, 1/2" x 5" - BLK F705-012 HEX BOLT, 3/8" x 2-1/2" - BLK F705-013 FLAT WASHER, 3/8"... -
Page 13: Information Needed Prior To Contacting Customer Support
Heart Rate Monitoring Device & Exercise Tips... -
Page 14: Product Warranty
If the item exhibits such a defect, BODYCRAFT will, at its option, repair or replace it without cost for parts. Shipping and handling charges may apply. (BODYCRAFT may require return of the part(s) or photographic evidence of the damaged part(s) prior to replacement.) Serial number is required. -
Page 15: Product Warranty Registration
The information you provide will never be distributed to any other individuals or agencies for any purpose. If you prefer to mail your warranty card, have the owner of the product complete the information below and return it to BODYCRAFT within 30 days from the date of equipment installation.
