F715 Hold Down / Attachment Kit Option
Base Lot Number: _ _ _ _ _ _ _ _ _ _ _ _ _
Purchased Date: ___ / ___ / ______
Dealer's Name:__________________________
Please register your products at:
https://www.bodycraft.com/product-registration/
Assembled Parts List
Owner's Manual
To see in
FULL COLOR
& additional information,
scan this QR code.
Part #
F715-001-ASM
F715-002-ASM
F715-003
F715-004
F715-005
F715-006
Part #
Assembly Hardware
F715-007
BIG WASHER, φ8 - BLACK
F715-008
HEX RECESSED HEAD BOLT, 5/16" x 1-1/4" - BLK
F715-009
HEX BOLT, 1/2" x 4-1/4" - BLACK
F715-010
NYLON LOCK NUT, 1/2" - BLACK
F715-011
FLAT WASHER, 1/2" - BLACK
1
Open your Camera
App and point it at
the QR Code
Assembly Parts list
LEG WEIGHT HOLDER - Assembly
ADJUST TUBE - Assembly
FOAM ROLLER HOLDER
FOAM ROLLER
END CAP, LARGER
END CAP, SMALLER
QTY
1
1
2
4
4
4
QTY
4
4
2
2
4
F715 v1.4
