EXPLODED DIAGRAM 2:

Parts List 2:

No. Description
67 Bearing 6003Z
68 Crank Hole Plug
69 Flange Nut
70 Inner Hexagon Pan Screw M6*10
71 Spring Washer Ring of Axle D17
72 Belt Disk
73 Flywheel
74 Waved Washer Ring D17
75 Nylon Bearing Support D-shaped
Crossed Pan Self-Tapping Screw
76
ST4.2*18
77 Belt 237PJ3
78 Belt 230PJ3
79 Needle Type Sensor Support
80 Crossed Pan Screw M4*10
81 Square Magnetic
82 Magnetic Board
83 Anti-proof Plug
84 Pressed Spring
Qty No.
4 85 Crossed Pan Screw M6*12
2 86 Waved Washer D8
2 87 Hexagon Nut M10*1.0 S17
7 88 Spring Washer Ring of Axle D10
6 89 Flat Washer D10
1 90 Idle Wheel Axle
1 91 Bearing 6202Z
1 92 Spring Washer Ring of Axle D15
2 93 Adjustable Chain Bolt
4 94 U-Shaped Board
1 95 Nylon Nut M6
1 96 Flat Washer D10
1 97 Bearing 6000Z
1 98 Belt Wheel
6 99 Axle
1 100 Waved Washer Ring D10
101L/
1 Chain Cover
R
1 102 Hexagon Nut M10*1.0 S17
Description
Page 6 of 16
Qty
1
1
1
1
1
1
1
1
2
2
2
2
2
1
1
1
2
3
