X399
MODEL V2000WM
OUTDOOR WALL MOUNT
Copyright © 1999 Vicon Industries Inc. All rights reserved.
Product specifications subject to change without notice.
Lexan is a registered trademark of General Electric.
Vicon and its logo are registered trademarks of Vicon Industries Inc.
VICON INDUSTRIES INC., 89 ARKAY DRIVE, HAUPPAUGE, NEW YORK 11788
TEL: 516-952-CCTV (2288) FAX: 516-951-CCTV (2288) TOLL FREE: 800-645-9116
UK: 44/(0) 1489-566300 INFOFAX: 1-800-287-1207 WEB: www.vicon-cctv.com
Vicon part no. 8006-8399-02-00
Rev 599 Section 7
Advertisement
Table of Contents
Related Manuals for Vicon V2000WM
Summary of Contents for Vicon V2000WM
- Page 1 Product specifications subject to change without notice. Lexan is a registered trademark of General Electric. Vicon and its logo are registered trademarks of Vicon Industries Inc. VICON INDUSTRIES INC., 89 ARKAY DRIVE, HAUPPAUGE, NEW YORK 11788 TEL: 516-952-CCTV (2288) FAX: 516-951-CCTV (2288) TOLL FREE: 800-645-9116 UK: 44/(0) 1489-566300 INFOFAX: 1-800-287-1207 WEB: www.vicon-cctv.com...
-
Page 5: Installation
Read this manual through completely before attempting installation. The V2000WM Medium-Duty Outdoor Wall Mount is designed to support camera stations weighing up to a total of 35 lb (16 kg), including p an-and-tilt or scanner, camera/lens system, and housing. Constructed of molded Lexan, the V2000WM is suitable for outdoor applications. - Page 6 V2000WM Wall Mount To install the Model V2000WM wall mount, secure the base to the wall with at least four ¼-in. (7 mm) lag screws or bolts. See Figure 1. Do not overtighten screws. Pull screws snug and then tighten ½ turn beyond snug position.
-
Page 7: Maintenance
Caution: Further tightening could damage the unit. Do not overtighten. Figure 2 Installation of V2400AH Adjustable Head Maintenance Model V2000WM does not require any maintenance other than to clean out the drainage holes periodically (refer to Figure 1). Maintenance • • 3 X399 Rev 599 V2000WM Wall Mount... -
Page 8: Shipping Instructions
Shipping Instructions Use the following procedure when returning a unit to the factory: 1. Call or write Vicon for a Return Authorization (R.A.) at one of the locations listed below. Record the name of the Vicon employee who issued the R.A. -
Page 9: Technical Information
Hole provided in bottom of mount for routing cable. Dimensions: Height: 7.4 in. (18.8 cm). Width: 6.0 in. (15.2 cm). Length: 20.9 in. (53.1 cm). Weight: 7.2 lb (3.3 kg). Construction: Molded Lexan. Finish: Gray. Technical Information • • 5 X399 Rev 599 V2000WM Wall Mount...
