Tolga - 2drw Bedside
Assembly Instructions
Dimensions
Width - 33,6cm
Depth - 39cm
Height - 52,8cm
Important
– Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, please visit: www.argos-support.co.uk
or email: Help@ClickSpares.co.uk (quoting your original order number)
Alternatively, call the Spares Helpline on: 0370 112 1928
For any other queries please contact the Customer Helpline on: 0345 640 2020
- Please keep for future reference
464/8231
OAK
455/6419
BLUE
461/6720
PINK
MAX.
20kg
Tip : To prevent damage,
we recommend that you
carton(s) it was packed in.
464/8231
455/6419
461/6720
build your unit on the
Issue 1 - 04/11/15
Advertisement
Related Manuals for Argos Tolga 2drw Bedside
Summary of Contents for Argos Tolga 2drw Bedside
- Page 1 Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, please visit: www.argos-support.co.uk or email: Help@ClickSpares.co.uk (quoting your original order number) Alternatively, call the Spares Helpline on: 0370 112 1928...
-
Page 2: Handy Hints
Safety and Care Advice Important – Please read these instructions fully before starting assembly • Check you have all the • During assembly do not stand • To reduce components and tools listed or put weight on the product, the likelihood of on the following pages. - Page 3 Components - Panels If you have damaged or missing components, 03456 400 800 call the Customer Helpline: Please check you have all the panels listed below Top x 1 Drawer Base x 2 Back x 1 (371 x 306 x 18mm) (343 x 267 x 2.5mm) (331 x 452 x 2.5mm) P1978...
-
Page 4: Tools Required
Components - Fittings Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required. FK1011 FK1010 FK1012 15mm 12mm Locking screw x 12 Locking nut x 4 Large locking nut x 8... - Page 5 Assembly Instructions Step - 1 Insert large locking nuts C into plinth 6. Make sure the ‘arrow’ on locking nuts C points towards the hole in the edge of 6. Put drop of glue K into the 2 holes of plinth 6. Put dowels G into the holes of plinth 6.
- Page 6 Assembly Instructions Step - 3 Attaching runners a: Fix runner left part A L on left side 5 as shown usesing 10mm fixing screw drawer E into left side 5. Note: look carreful for the right postion. Finished front edge Screw 24mm locking screw A into left side 5.
- Page 7 Assembly Instructions Step - 5 Attaching panels Put drop of glue K into the 2 holes of left side 5 and right side 7 on the bottom of the sides. Position left side 5 and right side 7 onto plinth 6 and top 1.
- Page 8 Assembly Instructions Step - 7 Preparing drawer Insert locking nuts B into left drawer side 8 and right drawer side 0. Make sure the ‘arrow’ on locking nuts B points towards the hole in the edge of 8 and 0. Put drop of glue K into the 3 holes of left drawer side 8 and right drawer side 0.
- Page 9 Assembly Instructions Step - 9 Position drawer onto drawerfont 4. Use a screwdriver to turn lockingnuts clockwise to lock. Do this step twice Step - 10 Turn over drawer. Fix runner left part B M on left drawer side 8 as shown using 12,5mm pozi screw D.
- Page 10 Assembly Instructions Step - 10 Fix runner left part B M and runner right part B O using screw D. Slide drawer base support I in corner as shown and fix them, using the attached nail. Step - 11 Inserting drawers as shown.
